Jib Cranes
Up to 6 Ton Jib Crane
A jib crane range for 3 to 6 ton duty with a rated loading capacity of 0.25 to 10 tons and a 360 degree slewing range.
Product Overview
A jib crane range for 3 to 6 ton duty with a rated loading capacity of 0.25 to 10 tons and a 360 degree slewing range. Arms are adjustable to the application, the boom is horizontal so the hook covers a circular working area, and electric, manual and pneumatic hoisting configurations are all available. Six mounting types are offered: wall-mounted, column mounted, free-standing, articulating, mast type and portable.
Key benefits
Why Buyers Choose This Specification
Six Mounting Types Against One Duty
Wall-mounted saves floor space, column mounted is space efficient, free-standing gives accurate positioning, articulating gives precise positioning, mast type provides a stable base, and portable moves easily. The mounting, not the tonnage, is usually what the site actually constrains.
Full 360 Degree Slew
A complete circle of rotation means the crane can pick from a delivery point and place on a machine without the load being handed over or the crane repositioned.
Three Hoisting Configurations
Electric, manual and pneumatic. Pneumatic matters where electric hoists are not permitted; manual is often the right answer for a few lifts a day.
Adjustable Arms
The arms adjust to fit the required reach rather than forcing the workstation layout to match a fixed boom length.
Application scenarios
Where It Is Used
- Machine loading and unloading at a single workstation
- Feeding parts onto and off a production machine within a circular reach
- Workshop repair bays lifting assemblies off equipment
- Goods-in areas unloading heavy items from pallets
- Confined cells where an overhead crane cannot reach
- Temporary lifting points using the portable mounting type
Who it is for
The Buyers This Product Suits
Workstations With Repeated Lifts
A jib crane covering a circular area is faster than a shared overhead crane for a single operator doing the same lift all shift.
Plants Where Electric Hoists Are Restricted
Pneumatic hoisting configurations are available where compressed air is preferred to an electric hoist.
Sites Without Suitable Wall or Column Steel
Free-standing and mast type mountings do not rely on building structure.
Problems it solves
What It Fixes
Waiting for the Overhead Crane
A single workstation competing for a shared bay crane loses time on every lift. A jib crane gives that station its own hook.
Reach That Does Not Match the Cell
Adjustable arms and six mounting types mean the crane fits the cell rather than the cell being rearranged.
Operator Fatigue on Repeated Lifts
Wireless remote control is available, which removes the pendant and the walking that goes with it.
Specifications
Published Figures For This Product
Every value below comes from our own product specification. Where a figure is not published we leave it out rather than estimating it.
| Rated Loading Capacity | 0.25 to 10 tons |
|---|---|
| Working Duty | 3 to 6 tons |
| Slewing Range | 360 degrees |
| Boom | Horizontal boom covering a circular area |
| Arms | Adjustable to application |
| Hoisting Configurations | Electric, manual, pneumatic |
| Mounting Types | Wall-mounted, column mounted, free-standing, articulating, mast type, portable |
| Control | Wireless remote control available |
| Grade | Six mounting types |
Packing and documents
How It Ships And What Comes With It
Packing And Loading
Shipping volume for this item depends on the configuration and capacity you select, so no fixed container figure is published. Confirm the specification and the destination and a loading plan is issued with the quotation, rather than a figure we cannot support.
Documentation On File
- Cranes and Material Handling · Jib Cranes Specification Sheet15.2 KB
- Catalogue · Full Product Catalogue154.0 KB
Sourcing And Inspection
This product is supplied through TrueGlow Imaging, working with manufacturing partners whose facilities are visited and verified rather than taken on trust. In-process quality control and delivery supervision are available so goods are inspected before the container is sealed. Certifications quoted on this page are those stated on the product specification and belong to that product range rather than to our trading entity, so ask for the certificate covering your specific item.
Handling guide
Getting It Right First Time
Step 1
Fix the mounting type first from the building and floor: wall, column, free-standing, mast or portable.
Step 2
Measure the working radius needed, then set the arm length inside that.
Step 3
Choose the hoist configuration: electric for frequent lifts, manual for occasional, pneumatic where required.
Step 4
Check the wall, column or foundation can take the overturning moment at full reach.
Step 5
Confirm whether wireless remote control is required before the electrical package is fixed.
Comparison
How It Compares In Our Range
Which mounting type suits which constraint.
| Wall-Mounted | Saves space. Needs a wall or structure able to carry the moment. |
|---|---|
| Column Mounted | Space efficient. Mounts to an existing building column. |
| Free-Standing | Accurate positioning without relying on building structure. |
| Articulating | Precise positioning, with a jointed arm that reaches round obstacles. |
| Mast Type | Stable base, no building structure required. |
| Portable | Easily moveable to temporary lifting points. |
FAQ
Up to 6 Ton Jib Crane Questions
What is the actual capacity range?
The rated loading capacity is 0.25 to 10 tons, which covers the 3 to 6 ton duty comfortably.
How far does the crane rotate?
360 degrees, so the hook covers a full circular area.
Can we have a pneumatic hoist?
Yes. Electric, manual and pneumatic hoisting configurations are all available.
Is remote control available?
A wireless remote control method is available, which reduces operator fatigue on repeated lifts.
Can the arm length be changed?
The arms are adjustable to fit the reach your application requires.
What do you need from us to quote?
Capacity, required radius, mounting type and whether the hoist should be electric, manual or pneumatic. Send those on WhatsApp for a same-week quotation.
Related products
Other Products Buyers Look At
Industries
Sectors That Use This Product
Warehousing and Heavy Industry
Lifting from 250 kg to 360 tons, indoors on a runway or outdoors on legs.
Metal Fabrication and Machine Shops
Custom parts, tooling and the cranes that move them around the shop.
Food Packaging Lines
Depalletizing to palletizing, balanced against the filler in the middle.
Further reading
Guides That Cover This Product
Choosing a Jib Crane Mounting for Your Building
Six mounting types exist because the building constrains the crane more often than the load does. Wall, column, free-standing, articulating, mast and portable each solve a different constraint.
Quote Up to 6 Ton Jib Crane
Send the capacity or size you need, the quantity and the destination, and we will confirm the configuration, the lead time and a loading plan.
