Jib Cranes
2 Ton Jib Crane
A 2 ton jib crane with a load capacity of 250 kg to 2000 kg and a 360 degree slewing range, offered in wall-mounted, free-standing, column-mounted, mast-type and portable mountings.
Product Overview
A 2 ton jib crane with a load capacity of 250 kg to 2000 kg and a 360 degree slewing range, offered in wall-mounted, free-standing, column-mounted, mast-type and portable mountings. Wireless remote control is available to ease loading tasks, and the mounting choice is what adapts the crane to the building: mast type needs no building structure at all, while portable is light enough to be moved where it is needed.
Key benefits
Why Buyers Choose This Specification
Capacity From 250 kg Upward
The range starts at 250 kg, so one crane family covers both light repeated handling and the occasional full 2000 kg lift without changing supplier.
No Building Structure Needed
The mast type mounting does not rely on a wall or column. In leased units and steel-frame sheds that is often the only workable option.
Portable Where the Work Moves
The portable mounting is lightweight and moves easily, so a single crane can serve several temporary lifting points instead of buying one per position.
Wireless Remote Control
Remote control eases the loading task and lets the operator stand where the load can actually be seen.
Application scenarios
Where It Is Used
- Machine tending where parts are loaded and unloaded all shift
- Assembly cells lifting sub-assemblies into fixtures
- Maintenance work lifting motors and gearboxes off equipment
- Goods-in and despatch handling of heavy cartons and drums
- Temporary lifting points served by the portable mounting
- Bays with no suitable wall or column, using the mast type mounting
Who it is for
The Buyers This Product Suits
Small and Medium Workshops
A 250 kg to 2000 kg jib crane is often all a workshop needs, and it costs a fraction of a bay crane and its runway.
Tenants Who Cannot Modify the Building
Mast type and portable mountings avoid fixing anything to the landlord's structure.
Operations With Several Lifting Points
A portable jib serves multiple positions rather than requiring a fixed crane at each.
Problems it solves
What It Fixes
Manual Lifting at Workstations
Loads between 250 kg and 2000 kg are the range where manual handling stops being possible and injuries start. A jib crane covers exactly that band.
Walls That Cannot Carry a Crane
Mast type mounting is specified precisely because it needs no building structure for support.
One Crane Locked to One Position
The portable mounting is lightweight and moves easily, which spreads the cost across several work areas.
Specifications
Published Figures For This Product
Every value below comes from our own product specification. Where a figure is not published we leave it out rather than estimating it.
| Load Capacity | 250 kg to 2000 kg |
|---|---|
| Slewing Range | 360 degrees |
| Mounting Options | Wall-mounted, free-standing, column-mounted, mast-type, portable |
| Control | Wireless remote control available |
| Mast Type | Does not need a building structure for support |
| Portable Type | Lightweight and easily moved |
| Grade | Five mounting options |
Packing and documents
How It Ships And What Comes With It
Packing And Loading
Shipping volume for this item depends on the configuration and capacity you select, so no fixed container figure is published. Confirm the specification and the destination and a loading plan is issued with the quotation, rather than a figure we cannot support.
Documentation On File
- Cranes and Material Handling · Jib Cranes Specification Sheet15.2 KB
- Catalogue · Full Product Catalogue154.0 KB
Sourcing And Inspection
This product is supplied through TrueGlow Imaging, working with manufacturing partners whose facilities are visited and verified rather than taken on trust. In-process quality control and delivery supervision are available so goods are inspected before the container is sealed. Certifications quoted on this page are those stated on the product specification and belong to that product range rather than to our trading entity, so ask for the certificate covering your specific item.
Handling guide
Getting It Right First Time
Step 1
Confirm the heaviest load, then check it against the 250 kg to 2000 kg range.
Step 2
Choose the mounting from the building: wall, column, free-standing, mast or portable.
Step 3
Set the radius needed at the workstation and check clearance through the full 360 degree slew.
Step 4
Decide on wireless remote control before the hoist is specified.
Step 5
Verify the floor slab thickness for free-standing, mast type and portable mountings.
Comparison
How It Compares In Our Range
Five mountings, chosen by what the building can carry.
| Wall Mounted | Saves the most floor space, but transfers the load into the wall. |
|---|---|
| Column Mounted | Installed on existing pillars, so it is space-efficient. |
| Free Standing | Does not need additional support such as walls. |
| Portable | Lightweight and easily moved between lifting points. |
| Mast Type | Does not need a building structure for support. |
FAQ
2 Ton Jib Crane Questions
What is the load capacity?
250 kg to 2000 kg, which covers 2 ton duty.
How far does it slew?
360 degrees, so the hook reaches anywhere in the circular working area.
Which mounting should we choose?
Wall and column mountings save the most space; mast type and free standing need no wall; portable suits several temporary positions. Send a photo of the area on WhatsApp and one is recommended.
Is remote control included?
A wireless remote control method is available for this crane. Confirm it with the order so the hoist is supplied to match.
Do we need to modify the building?
Not with the mast type or portable mountings, which are designed to work without building support.
What is the lead time?
Lead time depends on the mounting and hoist selected. Confirm capacity, radius and mounting to get a firm date with the quotation.
Related products
Other Products Buyers Look At
Industries
Sectors That Use This Product
Warehousing and Heavy Industry
Lifting from 250 kg to 360 tons, indoors on a runway or outdoors on legs.
Metal Fabrication and Machine Shops
Custom parts, tooling and the cranes that move them around the shop.
Food Packaging Lines
Depalletizing to palletizing, balanced against the filler in the middle.
Further reading
Guides That Cover This Product
Choosing a Jib Crane Mounting for Your Building
Six mounting types exist because the building constrains the crane more often than the load does. Wall, column, free-standing, articulating, mast and portable each solve a different constraint.
Quote 2 Ton Jib Crane
Send the capacity or size you need, the quantity and the destination, and we will confirm the configuration, the lead time and a loading plan.
