Blending Tank
A mixing and blending tank from 500 L to 30,000 L in SUS304 or SUS316L, built as a vertical single layer, double layer PU insulated or three layer dimple jacket tank.
Product Overview
A mixing and blending tank from 500 L to 30,000 L in SUS304 or SUS316L, built as a vertical single layer, double layer PU insulated or three layer dimple jacket tank. Six agitator types are available: paddle, anchor, propeller, frame, side and eccentric. It is used as a flavour milk mixing tank, UHT milk mixing tank, fruit juice blending tank, beverage blending tank and juice mixing tank.
Key benefits
Why Buyers Choose This Specification
Six Agitator Types to Choose From
Paddle, anchor, propeller, frame, side and eccentric agitators each suit a different viscosity and mixing duty. Getting the agitator wrong is the most common reason a blending tank underperforms.
Three Shell Constructions
Single layer where no temperature control is needed, PU insulated where it must be held, three layer dimple jacket where it must be heated or cooled actively.
Designed and Manufactured to Requirement
The tank is designed and built to the customer's specification rather than selected from a range, which matters when it has to fit an existing plant layout.
500 L to 30,000 L
One design family covers a small flavour batch and a bulk beverage blend.
Application scenarios
Where It Is Used
- Blending flavoured milk before UHT treatment
- Mixing UHT milk formulations
- Fruit juice blending to a target brix
- Beverage blending with sugar and additives
- Reconstituting powdered ingredients into liquid
- Batch preparation ahead of filling
Who it is for
The Buyers This Product Suits
Dairy Processors
Flavour milk and UHT milk mixing are named applications, and both need controlled temperature during blending.
Juice and Beverage Producers
Blending to a consistent brix and flavour profile is what makes each batch match the last.
Plants With Varied Viscosities
Six agitator types mean the same supplier can cover thin juice and viscous blends.
Problems it solves
What It Fixes
Ingredients Not Fully Dispersing
Choosing the right agitator type for the viscosity is what solves it, and six options are available.
Temperature Drifting During Blending
PU insulated and three layer dimple jacket constructions hold or actively control the batch temperature.
Tanks That Do Not Fit the Plant
Design and manufacture follow the customer's requirements, including dimensions and connections.
Specifications
Published Figures For This Product
Every value below comes from our own product specification. Where a figure is not published we leave it out rather than estimating it.
| Product Model | HTK-JBG-01 |
|---|---|
| Product Volume | 500 L to 30,000 L, customised |
| Material | SUS304 / SUS316L |
| Structures | Vertical single layer; double layer PU insulated; three layer dimple jacket |
| Agitator Types | Paddle, anchor, propeller, frame, side, eccentric |
| Applications | Flavour milk, UHT milk, fruit juice, beverage and juice blending |
| Minimum Order | One unit |
| Production Capacity | 100 units per month |
| Grade | SUS304 / SUS316L |
Packing and documents
How It Ships And What Comes With It
Packing And Loading
Shipping volume for this item depends on the configuration and capacity you select, so no fixed container figure is published. Confirm the specification and the destination and a loading plan is issued with the quotation, rather than a figure we cannot support.
Documentation On File
- Dairy and Liquid Processing · Dairy Processing Machinery Specification Sheet53.2 KB
- Catalogue · Full Product Catalogue154.0 KB
Sourcing And Inspection
This product is supplied through TrueGlow Imaging, working with manufacturing partners whose facilities are visited and verified rather than taken on trust. In-process quality control and delivery supervision are available so goods are inspected before the container is sealed. Certifications quoted on this page are those stated on the product specification and belong to that product range rather than to our trading entity, so ask for the certificate covering your specific item.
Handling guide
Getting It Right First Time
Step 1
Specify product viscosity and the ingredients to be dispersed before choosing the agitator.
Step 2
Decide whether the batch needs insulation only or active heating and cooling.
Step 3
Size the tank to your filling batch, allowing freeboard for agitation.
Step 4
Choose SUS316L for acidic juice and aggressive cleaning chemistry.
Step 5
Include the tank in the CIP circuit and verify agitator cleaning coverage.
Comparison
How It Compares In Our Range
Three shell constructions for different temperature duties.
| Vertical Single Layer | No insulation or jacket. Lowest cost, for ambient blending. |
|---|---|
| Double Layer PU Insulated | Holds batch temperature without actively changing it. |
| Three Layer Dimple Jacket | Active heating or cooling through the jacket plus insulation to keep it there. |
FAQ
Blending Tank Questions
What volumes are available?
500 L to 30,000 L, customised.
Which agitator types can be fitted?
Paddle, anchor, propeller, frame, side and eccentric agitators, among others.
What tank structures are available?
Vertical single layer, double layer PU insulated, and three layer dimple jacket.
Which materials are available?
SUS304 or SUS316L.
What is it used for?
Flavour milk mixing, UHT milk mixing, fruit juice blending, beverage blending and juice mixing.
What is the minimum order?
One unit, with a production capacity of 100 units per month.
Related products
Other Products Buyers Look At
Industries
Sectors That Use This Product
Dairy Processing
From the milking parlour to the sealed pack, with the cleaning system that keeps it legal.
Brewing and Beverage
Fermentation, bright tank, pasteurisation and filling for beer water and soft drinks.
Food Packaging Lines
Depalletizing to palletizing, balanced against the filler in the middle.
Further reading
Guides That Cover This Product
Pasteurisation Versus UHT for Liquid Dairy
Three thermal profiles, three different machines and three different distribution models. Which one your plant needs is decided by shelf life and cold chain, not by capacity.
Specifying a CIP System That Actually Cleans
A cleaning cycle that runs without flow cleans nothing and reports success. Conductivity monitoring, flow switches and return pump selection are what make CIP verifiable.
Quote Blending Tank
Send the capacity or size you need, the quantity and the destination, and we will confirm the configuration, the lead time and a loading plan.
