Blue horizontal close coupled centrifugal pump with flanged suction and discharge

11 models horizontal and vertical 1.5 to 1500 m3/h

Horizontal And Vertical Centrifugal Pumps To 1500 m3/h

Single stage end suction pumps for clear water, hot water, thermal oil and chemical duties, in close coupled and coupled versions, with cast iron, stainless steel or bronze wetted parts.

Request A Quote See The 11 Models

The Range

Eleven Models Split Between Horizontal And Vertical Mounting

The SKW and SKS families mount horizontally, the SKG family mounts inline and vertically. Within each family the suffix marks the duty: H for chemical, R for hot water, S for high temperature, Y for oil.

SKG vertical inline centrifugal pump with motor mounted above the casing

Vertical centrifugal pump

SKG Vertical Centrifugal Pump

Vertical inline pump for clear water where floor space is scarce.

View specifications →
SKGH vertical chemical pump with stainless casing and inline flanges

Vertical centrifugal pump

SKGH Vertical Chemical Pump

Vertical inline pump with stainless wetted parts for corrosive liquids.

View specifications →
SKGR vertical hot water pump with inline flanges and motor above

Vertical centrifugal pump

SKGR Hot Water Pump

Vertical inline pump for hot water circulation to 120 degrees.

View specifications →
SKGY vertical centrifugal oil pump with inline flanged connections

Vertical centrifugal pump

SKGY Centrifugal Oil Pump

Vertical inline pump for petroleum products to 750 cSt.

View specifications →
SKS horizontal water pump with coupling guard and motor on a baseplate

Horizontal centrifugal pump

SKS Horizontal Water Pump

Traditional coupled end suction pump with the seal serviceable in place.

View specifications →
Blue SKW horizontal close coupled centrifugal pump with flanged suction and discharge

Horizontal centrifugal pump

SKW Horizontal Centrifugal Pump

Close coupled end suction pump for clear water to 1500 m3/h and 150 m head.

View specifications →
SKWH horizontal chemical pump with stainless casing on a base frame

Horizontal centrifugal pump

SKWH Horizontal Chemical Pump

Stainless horizontal pump for corrosive liquids to 120 degrees.

View specifications →
SKWR horizontal hot water pump with flanged connections and motor

Horizontal centrifugal pump

SKWR Horizontal Hot Water Pump

Horizontal pump for pressurised hot water circulation to 120 degrees.

View specifications →
SKWY horizontal oil pump with flanged connections on a blue base frame

Horizontal centrifugal pump

SKWY Horizontal Oil Pump

Horizontal pump for gasoline kerosene and diesel to 750 cSt.

View specifications →

Who Buys This Line

  • Building services contractors on pressure boosting, heating and chilled water circuits
  • Municipal water supply and drainage projects
  • Fire protection installers who need a pump that holds head at a fixed duty
  • Chemical plants moving corrosive liquids that need stainless wetted parts
  • Thermal oil system builders working above the range of a water pump

Problems It Solves

The pump room is too small for a coupled set

The SKW family is close coupled with no separate coupling or baseplate, which cuts the footprint against an ordinary horizontal set with a coupling and frame.

The liquid is hotter than a standard pump allows

Standard water pumps stop around 80 degrees. The R, S and Y models carry higher temperature limits, up to 350 degrees on thermal oil versions in the high temperature line.

Vibration and noise in an occupied building

Dynamically balanced impellers and direct coupling reduce vibration, which protects bearings and keeps plant rooms under a building quieter.

Why This Line

Why These Pumps Get Specified

Hydraulics Across A Wide Band

1.5 to 1500 m3/h with heads to 150 m and drives to 160 kW means one family covers most water and process duties rather than forcing a change of supplier at the edges.

Seal Choice Not Seal Default

Mechanical seal with hard alloy rotating and stationary faces, or packing gland where the liquid and the maintenance regime favour it.

Materials To Match The Liquid

Casing and impeller in cast iron, stainless steel or bronze. Chemical versions run stainless wetted parts throughout.

Application Scenarios

Where These Pumps Are Installed

Pressure Boosting In High Buildings

Municipal supply pressure rarely reaches the upper floors. A centrifugal set holds the duty point without cycling the pump on and off.

Heating And Cooling Circulation

Cold and warm water circulation with steady head and low noise, matched to the resistance of the circuit rather than oversized.

Long Distance Transfer And Irrigation

Clear water and liquids with similar physical properties over long pipe runs, where head loss rather than flow sets the model.

Industries Served By This Line

Selection Guide

How To Pick The Right Model In This Line

Fix The Duty Point

Flow in m3/h and total head in metres including static lift and pipe losses. Guessing high here is what causes throttled valves and wasted power later.

Name The Liquid

Clear water, hot water, thermal oil, chemical. Temperature and specific gravity decide the material and the seal, not the flow.

Choose The Mounting

Horizontal for plant rooms with floor space, vertical inline where the pump sits directly in the pipe run and space is tight.

Confirm Motor And Connection

380 to 415 V three phase at 50 or 60 Hz is standard. Flanged connections are sized from the caliber, up to 500 mm on the largest model.

Answers

Centrifugal Pumps FAQ

What is the difference between the SKW and SKS families?

SKW is a direct coupled pump with the motor and pump body integrated, so it takes less floor space. SKS is the traditional arrangement with a coupling between motor and pump, which makes the seal easier to service without disturbing the motor.

How high can the liquid temperature be?

80 degrees Celsius on the standard water models. The hot water models are rated higher and the thermal oil models in the high temperature line run to 350 degrees. Always state the working temperature in the enquiry.

Can the pump handle liquid with solids?

These are clear liquid pumps with a free passage of a fraction of a millimetre. For sludge or liquid with fibre and solids use the rubber lobe or progressing cavity lines instead.

What seal is fitted as standard?

A mechanical seal with hard alloy rotating and stationary rings. Packing gland is available where the plant prefers to service a gland rather than change a cartridge.

Is the motor included?

Yes. Pumps are quoted as a set with the motor rated for the duty point, in 380 to 415 V three phase, 50 or 60 Hz. Tell us the site voltage and frequency with the enquiry.

Engineering Notes

Guides For This Line

Send Flow And Head And Get A Model Back

With the duty point, the liquid and the temperature we can name the model, the impeller trim and the motor rating in one reply.
