11 boards in this category
Choosing the laminate brand is choosing the electrical behaviour of the board. These parts were built on stock we hold, so Dk, Df and Tg are a design decision rather than a lead-time.
Ranges below are computed from the 11 boards listed on this page, not from a marketing sheet.
| Built to | Range across this category |
|---|---|
| Layer counts built | 2–14 |
| Base materials | CLTE-AT, RT/Duroid 5880, Ro3003+FR4 IT180A, Ro4835+FR4 IT180A, Rogers 4003c, Rogers 4350B, Rogers 4350B+FR4 TG170, Rogers AD250C … |
| Surface finishes | ENIG 1u, ENIG 2u, Immersion Silver |
| Solder mask colours | Green, Matte Black, Matte Green, Red |
| Special processes | Blind Via, Blind Via (L1-L2), Buried Capacitance, Buried Via (L3-L4), POFV |
| Finished thickness | 1.0–2.0 mm |
Send Gerber plus a drill file and a stack-up note. Quotation comes back within 6 hours, with DFM comments attached.
