mmWave Radar PCB
Automotive and industrial radar front ends built on specified PTFE and ceramic-filled laminates, with blind vias placed to keep the feed network clean.
What this application demands of the board
Rogers, Arlon, Taconic and SYTech RF laminates held in stock
Dk as low as 2.20 with Df 0.0009 available
Blind via structures for antenna feed isolation
Hybrid lamination of RF layers onto an FR4 carrier
Categories used for mmwave radar
Examples from production
High Frequency PCB
ITEQ IT150DA (DK3.56; DF0.0047) Double Side Immersion Gold 1u PCB
- Layers2 Layers (Max 64 Layers)
- Base materialITEQ IT150DA
- Finished thickness1.0 mm (Max 8mm)
Multilayer PCB
14 Layers Rogers 4350B+FR4 TG170 Hybrid Lamination POFV ENIG Rigid PCB
- Layers14 Layers (Max 64 Layers)
- Base materialRogers 4350B+FR4 TG170
- Finished thickness2.0 mm (Max 8mm)
High Frequency PCB
Taconic TLY-5 DK 2.2 Double Side 1.0mm High Frequency Immersion Silver PCB
- Layers2 Layers (Max 64 Layers)
- Base materialTaconic TLY-5
- Finished thickness1.0 mm (Max 8mm)
High Frequency PCB
4 Layers Blind Via SYTech SCGA-500 GF220 (DK2.20; DF0.0009) Radar PCB
- Layers4 Layers (Max 64 Layers)
- Base materialSYTech SCGA-500 GF220
- Finished thickness1.6 mm (Max 8mm)
Building for mmwave radar?
Send the requirement — dielectric, thermal, qualification standard — and we will come back with a manufacturable stack-up and a price.
