85+ RF laminate types
High Frequency PCB
RF work lives or dies on the laminate. We hold the Rogers, Arlon, Taconic, Isola, Nelco and F4B families in stock so Dk and Df are a design choice, not a lead-time.
Published capability limits
- More than 85+ laminate types
- Rogers / Arlon / Taconic / Isola / Nelco / F4B series
- Materials can be specified by the customer
- Impedance tolerance ±5% (min)
Categories that sit inside this window
8 catalogue categories, 60 boards in total.
Representative builds
High Frequency PCB
ITEQ IT150DA (DK3.56; DF0.0047) Double Side Immersion Gold 1u PCB
- Layers2 Layers (Max 64 Layers)
- Base materialITEQ IT150DA
- Finished thickness1.0 mm (Max 8mm)
Multilayer PCB
14 Layers Rogers 4350B+FR4 TG170 Hybrid Lamination POFV ENIG Rigid PCB
- Layers14 Layers (Max 64 Layers)
- Base materialRogers 4350B+FR4 TG170
- Finished thickness2.0 mm (Max 8mm)
High Frequency PCB
Taconic TLY-5 DK 2.2 Double Side 1.0mm High Frequency Immersion Silver PCB
- Layers2 Layers (Max 64 Layers)
- Base materialTaconic TLY-5
- Finished thickness1.0 mm (Max 8mm)
High Frequency PCB
Arlon AD1000 (DK10.2; DF0.0023) Immersion Silver 2.45mm Thickness PCB
- Layers2 Layers (Max 64 Layers)
- Base materialArlon AD1000
- Finished thickness2.45 mm (Max 8mm)
High Frequency PCB quoted in 6 hours
Gerber plus a stack-up note is enough to start. If the design sits outside the window above, we will say so and propose the change that brings it back in.
