Rigid-Flex PCB
Rigid-flex removes connectors from the assembly, which only pays off if the flexible zone and the transition are built to a controlled dimension.
Published capability limits
- 2–24 layers
- Book / air-gap / fly-tail
- Unsymmetrical and semi-flex
- Width of flexible zone 3 mm (min)
- Dimension accuracy ±0.05 mm (min)
Categories that sit inside this window
1 catalogue categories, 6 boards in total.
Representative builds
Rigid-Flex PCB
4 Layers 1+N+1 Structure (L1-2;L2-3;L3-4) Small Format ENIG HDI Rigid-Flex PCB
- Layers4 Layers (Max 64 Layers)
- Base materialFR4 S1000-2M
- Finished thickness1.6 mm (Max 8mm)
Rigid-Flex PCB quoted in 6 hours
Gerber plus a stack-up note is enough to start. If the design sits outside the window above, we will say so and propose the change that brings it back in.
