30 boards in this category
Choosing the laminate brand is choosing the electrical behaviour of the board. These parts were built on stock we hold, so Dk, Df and Tg are a design decision rather than a lead-time.
Ranges below are computed from the 30 boards listed on this page, not from a marketing sheet.
| Built to | Range across this category |
|---|---|
| Layer counts built | 2–14 |
| Base materials | Arlon 25FR, Arlon 25N, Arlon AD1000, Arlon AD300C, CLTE-AT, F4BM+FR4 TG170, F4BTMS220, ITEQ IT150DA … |
| Surface finishes | ENIG 1u, ENIG 2u, Immersion Silver, OSP |
| Solder mask colours | Black, Green, Matte Black, Matte Green, Red |
| Special processes | Blind Via, Blind Via (L1-L2), Buried Capacitance, Buried Via (L3-L4), Hybrid Lamination, POFV |
| Finished thickness | 0.8–2.7 mm |
Send Gerber plus a drill file and a stack-up note. Quotation comes back within 6 hours, with DFM comments attached.
