Optical Modules PCB
Transceiver boards where insertion loss budget and mechanical registration are decided by the laminate and the etch, not by the layout.
What this application demands of the board
TU-872SLK class low-loss material (Dk 3.8, Df 0.008)
Impedance tolerance to ±5%
Line width and space accuracy ±5%
Small format panelisation with tight outline tolerance
Categories used for optical modules
Examples from production
High Speed PCB
EMC-EM828 (DK3.7; DF0.008)+FR4 ISOLA370HR 4 Layers Hybrid Lamination PCB
- Layers4 Layers (Max 64 Layers)
- Base materialEMC-EM828 + ISOLA370HR
- Finished thickness1.6 mm (Max 8mm)
High Speed PCB
16 Layers TU-872 (DK3.8; DF0.008) HASL Lead-Free High Speed PCB
- Layers16 Layers (Max 64 Layers)
- Base materialTUC TU-872
- Finished thickness2.8 mm (Max 8mm)
Small Format PCB
3mil Line Width/Spacing Small Format Double Side FR4 TG150 Transformers PCB
- Layers2 Layers (Max 64 Layers)
- Base materialFR4 TG150
- Finished thickness2.0 mm (Max 8mm)
Multilayer PCB
6 Layers Optical Modules TU-872SLK (DK3.8; DF0.008) TUC ENIG High Speed PCB
- Layers6 Layers (Max 64 Layers)
- Base materialTUC TU-872SLK
- Finished thickness1.6 mm (Max 8mm)
Building for optical modules?
Send the requirement — dielectric, thermal, qualification standard — and we will come back with a manufacturable stack-up and a price.
