6 boards in this category
Choosing the laminate brand is choosing the electrical behaviour of the board. These parts were built on stock we hold, so Dk, Df and Tg are a design decision rather than a lead-time.
Ranges below are computed from the 6 boards listed on this page, not from a marketing sheet.
| Built to | Range across this category |
|---|---|
| Layer counts built | 4–12 |
| Base materials | Doosan DS7402, EMC-EM280H, FR4 TG170, IT150GSTC, S1150G, SYTech S1165 |
| Surface finishes | ENIG 1u, ENIG 1u + Hard Gold (Gold Finger), ENIG 2u |
| Solder mask colours | Green |
| Special processes | Buried Capacitance, Hard Gold (Gold Finger) & HDI, POFV |
| Finished thickness | 1.0–2.0 mm |
Send Gerber plus a drill file and a stack-up note. Quotation comes back within 6 hours, with DFM comments attached.
