Aluminium, copper and iron base
Metal Core PCB
When the heat has to leave the board rather than the enclosure, the base metal and the bonding method matter more than the copper weight.
Published capability limits
- Thermal conductivity 1–398 W/m·K
- Aluminium / copper AC 500–4000 V
- Post-bonding and pre-bonding
- Sweat soldering and conductive adhesive
- Press-fit and embedded coin (I, T, U)
Categories that sit inside this window
5 catalogue categories, 34 boards in total.
Representative builds
Metal Core PCB
2.0mm Thickness CFAF-06 Fingerprint-Proof 2oz Single Side Iron-Based PCB
- LayersSingle Layer (Max 64 Layers)
- Base materialIron-Based
- Finished thickness2.0 mm (Max 8mm)
Metal Core PCB
Standard Double Side 3.0W/㎡•K BERGQUIST Aluminum-Based ENIG MC PCB
- Layers2 Layers (Max 64 Layers)
- Base materialBERGQUIST Aluminum-Based
- Finished thickness1.0 mm (Max 8mm)
Metal Core PCB
UV 398w/m.k Thermoelectric Separation AC2500-4000V 2oz Copper-Based PCB
- Layers2 Layers (Max 64 Layers)
- Base materialCopper-Based
- Finished thickness1.6 mm (Max 8mm)
HDI PCB
8 Layers 1+N+1 Structure (L1-2;L2-7;L7-8) 4/1/1/4oz Thick-Copper HDI PCB
- Layers8 Layers (Max 64 Layers)
- Base materialFR4 TG170
- Finished thickness2.0 mm (Max 8mm)
Metal Core PCB quoted in 6 hours
Gerber plus a stack-up note is enough to start. If the design sits outside the window above, we will say so and propose the change that brings it back in.
