Corrugated Print Packaging Mailer Box Strong 5 Layers Paper
Corrugated shipping and mailing cases specified by flute rather than sold as one generic board, covering A, C, B and E flutes, the finer F sheet and combinations such as AB, BC and BBC. Construction runs from single corrugated three-layer board through double corrugated five-layer to triple wall, and boxes are printed CMYK plus PMS and finished before die cutting. Distributors, ecommerce sellers and fashion accessory suppliers order it in A5, A4 and A6 mailer dimensions or to their own internal measurements.
What This Product Gives You
- Choosing the flute rather than accepting a house board is how you stop paying for strength the parcel never needed
- Triple wall construction is available where a five layer case still crushes under stacked pallets
- A5, A4 and A6 mailer formats fit courier rate bands without designing a box from scratch
- Fine F flute holds a crisp printed surface on a board that still carries a shipping load
- Combination flutes such as AB, BC and BBC balance cushioning against stacking strength in one wall
- An optional clear PET or PLA window lets a shipper double as a retail display case
Where It Is Used and Who Buys It
Application Scenarios
- Ecommerce order despatch in A5, A4 and A6 mailer sizes
- Wholesale distribution of fashion accessories and apparel
- Export cartons that must survive stacked sea freight
- Retail-ready shipping cases with a die-cut window
- Subscription and promotional mailings
Who It Is For
- Distributors shipping mixed pallet loads
- Ecommerce operations standardising on courier-friendly formats
- Export managers specifying board for long sea transit
- Fashion and accessory suppliers despatching to retail
- Packaging engineers who specify board by flute and wall count
What Goes Wrong Without It
- A single house board means light goods carry the cost of heavy board and heavy goods are under-protected
- Boxes drawn without reference to courier bands land in a higher rate than necessary
- Five layer board still fails when export pallets are double stacked, and only triple wall fixes it
- Coarse flute shows through the printed liner and a branded box looks corrugated rather than finished
- Shipping cases with no window have to be opened to identify the contents in a warehouse
Technical Features
- Flute types A, C, B, E and the finer F sheet, plus combinations such as AB flute, BC flute and BBC flute
- Single corrugated three-layer board, double corrugated five layer board and triple wall corrugated board
- Flute classification by ridge shape as U-shaped, V-shaped or UV shaped
- CMYK plus PMS printing, printed the same as your layout
- Printing handling including matt lamination, varnishing, stamping, embossing, glossy lamination, UV coating and gold foil
- Optional clear PET or PLA window, die-cut logos and promotional slits
Specification
| Paper Type | Corrugated board |
|---|---|
| Flute Types | A, C, B, E, F and combinations AB, BC, BBC |
| Wall Construction | Single wall three-layer, double wall five layer, triple wall |
| Ridge Shape | U-shaped, V-shaped or UV shaped |
| Popular Sizes | A5, A4 and A6 mailer dimensions |
| Colour | CMYK plus PMS, printed same as your layout |
| Printing Handling | Matt lamination, varnishing, stamping, embossing, glossy lamination, UV coating, gold foil |
| Window Option | Clear PET or PLA window, die-cut logos, promotional slits |
| Size Input | Exact internal dimensions as length x width x height in cm or inches |
| Certificate | ISO9001 / ISO14001 / GMI |
| Trade Terms | FOB, CIF, EXW, DDP |
| Typical Order Quantity | 500 pcs to 5000 pcs |
Materials and Manufacturing Process
Materials
- Corrugated board
- Triple wall corrugated board
- Clear PET window film
- PLA window film
Manufacturing Process
- Flute and wall selection against the load
- Die line drawn from the internal dimensions supplied
- CMYK plus PMS printing of the liner
- Lamination, UV coating and foil finishing
- Die cutting, window fitting and creasing
- Flat packing and palletising
How This Job Is Checked
- Flute and wall count confirmed against the stated parcel weight before production
- Internal dimensions checked against the length x width x height supplied by the customer
- PDF proof approved before the liner is printed
- Each case checked for crease alignment, liner delamination and clean die cut edges
- Photographs of the finished cases sent for approval before shipment
What You Can Change
- Flute selected from A, C, B, E, F or a combination such as AB, BC or BBC
- Single, double or triple wall construction
- A5, A4 or A6 mailer format, or your own internal dimensions
- Clear PET or PLA window, die-cut logo or promotional slit
- CMYK plus PMS printing with matt or glossy lamination
- Trade term chosen from FOB, CIF, EXW or DDP
Compared With the Alternatives
| Alternative | How This Compares |
|---|---|
| Single wall stock carton | Specifying the flute and wall count matches board to load, though a stock carton is available immediately with no tooling |
| Rigid plastic shipping case | Corrugated is recyclable and far cheaper per trip, while a plastic case is reusable on a closed loop route |
| Padded envelope | A corrugated case protects rigid and fragile goods, but an envelope is lighter and cheaper for flat soft items |
Getting the Best Result
- Provide exact internal dimensions as length x width x height in cm or inches, not the outer size
- State the packed weight and whether pallets are double stacked so the flute and wall count can be chosen
- Use E or F flute where print quality matters and B, C or a combination where stacking strength does
- Specify a PET or PLA window only where the contents need to be identified without opening the case
- Supply artwork as PDF, AI, PSD or JPEG at 300dpi minimum with fonts outlined
- Allow 15-18 days for sea shipping and 3-4 working days by express or air when planning arrival
Other Products in This Group
Tin Case Safety Metal Tinplate Case 3D Logo For Golf Tee Pack
Tin Boxes Jars Unique Design Metal Empty Round Circle .35mm
Custom Box Printing Pillow Box Gift Packaging 4C Printed
Printing Boxes Unique Free Design BIO Paper Soap Bar 350gsm
Corrugated Print Packaging Mailer Box Strong 5 Layers Paper FAQ
Which flute should I choose?
A, C and B flutes carry stacking load, E and the finer F sheet give a smoother printed surface, and combinations such as AB, BC and BBC balance the two in one wall.
What is the difference between three-layer and five layer board?
Three-layer is single wall corrugated and five layer is double wall. Triple wall corrugated board is available where double wall is still not enough.
Do you make standard mailer sizes?
Yes, A5, A4 and A6 mailer dimensions are popular formats. Custom internal sizes are cut to the measurements you supply.
Can I have a window in a shipping box?
Yes, a clear PET or PLA window, and die-cut logos or promotional slits are also available.
What quantities do you produce?
Runs commonly go from 500 pcs to 5000 pcs. Larger volumes are priced on the confirmed quantity.
What certificates apply?
ISO9001, ISO14001 and GMI as stated on the product specification.
What are your payment terms?
PayPal, bank transfer or Western Union, with a 30-50% deposit before production and the balance before shipment.
Quote Corrugated Print Packaging Mailer Box Strong 5 Layers Paper
Send the quantity, size and finish. Digital samples run in 1-2 working days and custom sample cost is refunded once the bulk order is confirmed.
