Bulletproof Steel Sheet
Armoxs 500 Quenched and Tempered Bulletproof Steel Plate
A 500 class ballistic plate supplied cut to panel size for vehicle and building armoring
Armoxs 500 bulletproof steel plate is a quenched and tempered ballistic plate in the 500 hardness class, also sold as armor steel sheet or ballistic steel plate. Vehicle armoring workshops and security fabricators specify it when a drawing calls out a 500 class plate and the buyer needs that call-out filled from stock rather than from a long import route. Fixing holes and cut to size work are done on a laser machine or a water jet before shipment, which removes the problem of a hardened panel that a general fabrication shop cannot drill. Thickness is supplied from 2mm to 100mm against customized panel sizes.
- Product Name — Armoxs 500 Bulletproof Steel Plate
- Also Known As — Ballistic steel plate armor steel plate bulletproof steel sheet
- Thickness — 2-100mm
- Sheet Thickness Range — 2.3mm to 100mm
- Size — Customized size
Why It Is Specified
Key Benefits of Armoxs 500 Bulletproof Steel Plate
Fills a 500 Class Call-Out From Stock
Drawings that name a 500 class ballistic plate can be quoted directly against this item. Buyers stop waiting on a single import source to reopen.
Stated Strength of 1250 MPa Yield and 1600 MPa Tensile
Yield strength is stated at 1250 MPa and tensile strength at 1600 MPa. That property set is described as giving greater multi hit capacity than other steel.
Hardness in the 500-600 HB Band
Ballistic steel is quoted at 500-600 HB where structural steel may reach only half of that. That difference is why the panel section can stay thin enough to fit inside a door or body panel.
Cutting Problem Handled Before Delivery
As ballistic capability rises the ease of folding welding and cutting falls. All fixing holes and profiles are cut here on laser or water jet so the panel arrives ready to install.
Quoted Against Published Protection Levels
The plate is offered against FB4+ FB5 FB6 FB7 NIJ IIIA NIJ III NIJ IV STANAG 4569 Level 1 and Level 2 and GA-3 to GA-6. Your order references the same level as the project specification.
Panel Sizes Rather Than Full Plates
Size is customized against your drawing. A vehicle kit can be ordered as a set of numbered panels instead of plates you have to nest and cut.
Problems It Solves
What This Material Removes From Your Process
A Single Source for a 500 Class Plate
Projects written around one branded 500 class plate stall when that source is slow or unavailable. An equivalent 500 class quenched and tempered plate keeps the fabrication schedule moving.
Hardened Panels That Resist Shop Tooling
Drilling and shearing a plate in the 500-600 HB band destroys ordinary tooling. Holes and profiles are cut on laser or water jet here so no hard machining lands on your shop floor.
Thickness Chosen Without Reference to the Level
Ballistic performance at a given thickness follows hardness, so thickness cannot be picked in isolation. Quoting against the named protection level ties the two decisions together.
Offcuts From Nesting Vehicle Kits
Cutting a vehicle kit from full plates leaves scrap you pay for and store. Cut to size panel supply against your drawing removes that waste from the order.
Application Scenarios
Where It Is Used
Armored Cars and Personnel Carriers
Body panels floors and door skins on armored personnel carriers combat vehicles and money transport vehicles.
Armor Doors and Ballistic Windows
Door leaves wall linings and ballistic window frames in buildings built to a protection specification.
Bank Counters and Confidential Safes
Counter fronts and safe bodies where a thin hard panel has to fit inside existing cabinet work.
Marine Craft and Helicopters
Submarines landing craft anti-smuggling boats and helicopters fitted with protection panels in the structure.
Armor Plate Shields and Vests
Armor plate armor shields ballistic helmets and vest plates cut from thin gauge material.
Who It Is For
Buyers Who Specify This Product
- Vehicle armoring workshops buying numbered panel kits for car and carrier bodies
- Security contractors sourcing a 500 class plate for armor doors and ballistic windows
- Safe and bank counter manufacturers ordering thin protection panels to cabinet dimensions
- Defense and police procurement buyers matching an order to an NIJ FB STANAG 4569 or GA level
- Shipyards fitting protection panels into patrol and anti-smuggling craft
- Distributors replacing a single import source for 500 class ballistic plate
Technical Data
Specifications and Technical Features
Values below come from the product data published by Shandong Tianyu Metal Products. Confirm the exact grade and size against your order.
| Product Name | Armoxs 500 Bulletproof Steel Plate |
|---|---|
| Also Known As | Ballistic steel plate armor steel plate bulletproof steel sheet |
| Thickness | 2-100mm |
| Sheet Thickness Range | 2.3mm to 100mm |
| Size | Customized size |
| Technique | Q+T quenched and tempered |
| Hardness | 500-600 HB |
| Yield Strength | 1250 MPa |
| Tensile Strength | 1600 MPa |
| Protection Level | FB4+ FB5 FB6 FB7 NIJ IIIA NIJ III NIJ IV STANAG 4569 Level 1 Level 2 GA-3 GA-4 GA-5 GA-6 |
| Application | Armor plate armor car |
| Processing Service | Bending welding decoiling cutting punching |
| Surface | Nature or painted |
| Place of Origin | China |
Technical Features
- Q+T quenched and tempered delivery condition
- Ballistic hardness band 500-600 HB
- Yield strength 1250 MPa
- Tensile strength 1600 MPa
- Plate 2-100mm thick with armor steel sheet quoted from 2.3mm to 100mm
- Protection levels FB4+ FB5 FB6 FB7 NIJ IIIA NIJ III NIJ IV STANAG 4569 Level 1 and Level 2 GA-3 to GA-6
- Fixing holes and cutting to size performed on laser machine or water jet
- Nature or painted surface
- Protection levels quoted to NIJ IIIA NIJ III and NIJ IV
- Protection levels quoted to FB4+ FB5 FB6 and FB7
- Protection levels quoted to STANAG 4569 Level 1 and Level 2 and GA-3 to GA-6
Materials
- Quenched and tempered ballistic steel in the 500 hardness class
- Ballistic composition fixed during steelmaking for the 500 hardness class
- Plate and sheet stock covering 2-100mm thickness
Certification
- Test report supplied with the plate
Manufacturing
How It Is Made and Processed
Steelmaking to the ballistic composition
Hot rolling to the ordered thickness
Quenching and tempering to the 500-600 HB band
Laser or water jet profiling of each numbered panel
Laser or water jet cutting of fixing holes
Nature or painted surface finishing
Panel marking against the drawing number
Packing and loading for export
Quality Control
Checks Before It Ships
- Test report issued for the plate supplied
- Hardness verified in the 500-600 HB band
- Thickness checked against the ordered size before profiling
- Panel outlines and hole centers compared with the supplied drawing
- Painted or nature finish confirmed before the panels are marked
- Panel count and marking checked against the packing list
Customization
What We Can Change on Your Order
- Numbered panel kits profiled to your vehicle or door drawing
- Fixing hole positions cut on laser or water jet before shipment
- Thickness selected across the 2-100mm range panel by panel
- Nature or painted surface as ordered
- Protection level confirmed against the level written in your specification
Comparison
Armoxs 500 Bulletproof Steel Plate Against the Alternatives
| Structural steel plate | Structural steel hardness may be only half of the 500-600 HB band quoted here so it cannot be substituted at the same thickness. |
|---|---|
| Higher hardness ballistic plate | Moving up in hardness improves performance at the same thickness but costs more and folds welds and cuts less easily. |
| Imported branded 500 class plate | The 500 class quenched and tempered specification is filled from stock with panels profiled before shipment instead of plate delivered for you to cut. |
| Layered mild steel panels | A single quenched and tempered panel avoids the weight and fixing complexity of building up protection from mild steel layers. |
Use Guide
Specifying Handling and Welding Notes
- Issue the panel drawing with hole centers so profiling is completed before dispatch
- Plan fixings as bolted connections and keep welding away from the protected face where possible
- Select thickness and protection level together rather than one after the other
- Expect reduced folding welding and cutting ease compared with structural plate
- Number the panels on the drawing so the kit can be marked and checked on arrival
- Ask for the test report with the shipment for the project record
Questions Buyers Ask
Armoxs 500 Bulletproof Steel Plate FAQ
What hardness is Armoxs 500 plate supplied at?
The ballistic steel is quoted at 500-600 HB. Structural steel may reach only half of that, which is why structural plate is not a substitute at the same thickness.
What thickness can you supply?
Plate is supplied from 2mm to 100mm and armor steel sheet from 2.3mm to 100mm, with size customized to your panel drawing.
Which protection levels does it cover?
It is quoted against FB4+, FB5, FB6, FB7, NIJ IIIA, NIJ III, NIJ IV, STANAG 4569 Level 1 and Level 2, and GA-3 to GA-6. Send the level in your specification and we will confirm thickness.
Can the plate be welded and folded?
Ease of folding, welding and cutting decreases as ballistic capability increases. Hole cutting and sizing are therefore done here on a laser machine or a water jet.
What strength values are stated?
The stated yield strength is 1250 MPa and the stated tensile strength is 1600 MPa.
Will you cut a full vehicle panel set?
Yes. Send the drawing and the panels are profiled and hole cut on laser or water jet, then marked to the drawing numbers before packing.
Is a test report included?
Yes. A test report is issued for the Armoxs 500 bulletproof steel plate supplied with the order.
