Sausage Guns
16 inch and 9 inch guns for 400 ml and 600 ml foil sausage packs, with three, seven or nine bearings
Sausage packs cut packaging waste and cost per litre, which is why curtain wall and facade crews moved to them. These eleven models cover that shift: aluminium and PP barrels from 440 g to 880 g, push forces from 90 KG to 270 KG, and bearing counts from three to nine.
The range
All 11 Models In This Family
The problem
What This Family Is Built To Solve
The complaint about sausage guns is always the same, that the barrel deforms or the rod binds halfway through a pack and the operator has to fight it for the last 100 ml. More bearings on the rod is the direct answer: friction drops, the pull gets lighter, and the pack empties completely. The nine-bearing JS8633 and JS8634 exist for crews running sealant all day.
Who buys these
Who This Range Is For
Curtain Wall And Facade Contractors
Run structural sealant continuously and need a gun whose pull weight does not tire an operator over a shift.
Sealant And Adhesive Brands
Sell 600 ml sausages and want a branded applicator to go with them, in their own barrel colour.
Industrial Tool Wholesalers
Supply professional crews and need the three-, seven- and nine-bearing tiers so they can price by duty level.
Why these
What Makes This Range Different
Three, Seven Or Nine Bearings
Bearings sit at the friction points on the rod. JS8622-B has three and delivers 180 KG; JS8626 has seven and delivers 200 KG; JS8634 has nine and delivers 250 KG. Same barrel format, three clearly different duty levels.
Anodised Aluminium Barrels
The JS8608, JS8613, JS8622 and JS8626 series barrels are thickened aluminium tube with an anodising process, which raises surface hardness as well as giving the colour. Barrels are available in more than ten anodised colours.
Hard Alloy Dispensing Plates
The plate that pushes the pack was upgraded from iron to a thicker hard alloy across the professional models. That is what lets JS8634 hold 250 KG push force without the plate dishing.
Two Barrel Materials
Aluminium for crews who value stiffness and finish; integrated injection-moulded PP on JS8623-A and JS8623-B for buyers who want a barrel that survives being dropped off a scaffold.
Application
Where These Tools Are Used
- Structural silicone on unitised curtain wall panels
- Weather sealing of facade joints at height
- High-volume glazing in aluminium window and door plants
- Expansion joint sealing on concrete structures
Industries
Trades That Specify This Family
Glass And Curtain Wall
Sealant guns and vacuum lifters for crews who handle and seal glass all day
Construction Sealing And Waterproofing
Cartridge, sausage and powered guns for joint sealing and waterproofing trades
Window And Door Manufacturing
Glazing, perimeter foaming and gap filling for window and door plants and installers
Further reading
Guides Related To This Family
How To Read Caulking Gun Force Ratings
Push force, maximum tolerance and drive ratio describe three different things. Confusing them is the most common reason a gun fails in the field.
Cartridge Or Sausage Which Sealant Gun To Stock
Sausage packs cut cost per litre and packaging waste; cartridges are simpler and universally stocked. The right answer depends on who your customer is.
How Many Bearings Does A Sausage Gun Need
Bearing count is the single clearest indicator of duty level on a sausage gun. Three, seven and nine are genuinely different tools.
FAQ
Sausage Guns Questions
Do these guns take 400 ml and 600 ml sausages?
The 16 inch models take 600 ml packs and the 9 inch JS8607-9 takes the shorter 400 ml pack. JS8623-A and JS8623-B are 16 inch 600 ml. Each product page lists the barrel length in the model name.
How many bearings do I actually need?
For occasional work, three is enough. For a crew running several packs a day, seven or nine noticeably reduces trigger effort and empties the pack more completely. The nine-bearing JS8634 also adds a stainless steel push rod and a dust cap.
Can the barrel be anodised in our brand colour?
Yes. Anodising gives more than ten colours and can be supplied with a frosted texture. Laser engraving or screen printing on the barrel is available in the same operation.
What is the difference between an aluminium and a PP barrel?
Aluminium is stiffer and takes an anodised finish, so it looks and feels like a professional tool. Injection-moulded PP, used on JS8623-A and JS8623-B, is more forgiving of impact and lands at a lower price point.
How do these pack for a full container?
Most 16 inch models are one piece per inner box, 20 pieces per carton, at a carton size of 60.8 x 54 x 35.5 cm. JS-8607 and JS-8607-9 pack two pieces per inner box, 24 per carton.
Is anti-drip standard on this range?
Yes, every model in this category has a drip prevention function. On JS8613 it is automatic; on JS8608-A and JS8608-B the output ratio is adjustable from the rear attachment.
Get A Quote On Sausage Guns
Send the models and quantities and we will confirm minimums, carton sizes and a real production date.
