EHWHA Pin Plate Holder
Pin plate holder matched to EHWHA frames, the part that carries the plate on the chain.
View Details
Pin Plates
Pin Plate For Monforts Stenters Type 2
The second Monforts base profile we hold, for frames whose holder seat differs from Type 1.
Product Overview
This is the second of the two Monforts pin plate profiles we manufacture. The pin work is the standard arrangement, two rows at three to four pins per centimetre with pins about 5 mm long, thickened at the base so the cloth does not touch the hot base plate.
What separates it from the Type 1 plate is the base profile where it meets the holder. Monforts frames of different ages take different seats, and a plate that only nearly fits will rock under the press wheel and bend its own pins.
Key Benefits
- Second Monforts seat profile, covering frames the Type 1 plate does not fit
- Standard 5 mm two-row pin arrangement at 3 to 4 pins per cm
- Supports the higher fabric tension and speed that pinning allows
- Supplied with matching holders so the plate and seat are renewed together
Who It Is For
- Monforts users who have found the common profile does not seat on their holders
- Maintenance stores holding pin plates for a mixed Monforts fleet
- Engineers who need each frame's spec recorded and repeatable
Problems It Solves
- A plate that rocks on the holder and bends pins within a shift
- Two Monforts generations in one plant being served by one wrong specification
- Pin height stepping between plates because profiles have been mixed
Application Scenarios
- Older or newer Monforts frames whose holder seat differs from the common profile
- Plants running Monforts machines of two generations side by side
- Bed renewal where the existing plates are too worn to measure reliably
Technical Features
- Alternative Monforts seat profile
- Pins approximately 5 mm, two rows, 3 to 4 pins per cm
- Pins thickened at the base for heat separation
- Silver and yellow finish
Specifications
| Machine | Monforts stenter, alternative seat profile |
|---|---|
| Pin length | approx 5 mm |
| Pin rows | 2 |
| Pin density | approx 3-4 pins/cm |
| Finish | silver and yellow |
| Origin | Zhejiang, China |
| Lead time | within 7 days for standard items |
| Origin | Shaoxing, Zhejiang, China |
Quality Control
- Seat gauge check against the reference holder for this profile
- Pin height and straightness measured plate by plate
- Sample fitted and press-wheel tested before batch release
Customisation Options
- Profile reproduced from your sample plate
- Pin density and length adjusted to your article
- Marked per machine so a mixed fleet does not get mixed spares
Certifications. We make no certification claim for this part. The original company statement is that products comply with international quality standards; no certificate is named and none is asserted here. Ask us directly if your procurement process requires documentation.
Comparison With Other Options
Type 1 and Type 2 carry the same pin work; only the seat differs. Deciding between them from a model number is guesswork. Deciding from a sample plate takes one courier and removes the problem permanently.
Use Guide
Send a sample plate from each Monforts frame and label them by machine
Store the two profiles separately and mark the shelf by machine number
Fit and check that each plate sits flat with no rock before running
Check seat wear on the holder at the same time
Renew a whole section rather than individual plates where possible
FAQ
Questions About Pin Plate For Monforts Stenters Type 2
Why are there two Monforts profiles?
Because the holder seat is not the same across Monforts frame generations. Rather than guess, we hold both and match from a sample.
What if neither profile fits?
Then we cut to your sample. That is normal work for us and it is how most non-standard orders start.
Is the pin arrangement different between the two types?
No. Both carry the standard two rows at three to four pins per centimetre with pins about 5 mm long.
Can I mix the two profiles on one machine?
You should not. Mixing seats gives stepped pin height along the bed, which shows on the cloth.
Do you mark the plates?
We can mark by machine on request, which is worth doing if you run a mixed Monforts fleet.
Delivery time?
7 days for stock profiles. Cut-to-sample is quoted once the sample arrives.
Related Products
Other Parts In This Family
LK Pin Plate Holder For Stenter Chains
Chain-mounted holder that carries the pin plate on LK stenter frames.
View Details
Bruckner Stenter Chain With Pin Plate Section
Complete Bruckner chain section with pin plates and holders already mounted.
View Details
Bruckner Stenter Pin Plate Assembly
Pin plate supplied assembled with its Bruckner holder, ready to fit to the chain.
View DetailsRelated Reading
Guides That Cover This Part
What Is a Stenter Machine and How Does It Work
The stenter heat-sets and dries fabric by stretching it to width and holding it there under controlled heat.
Key Parts of a Stenter Machine
Entry section, clip or pin chains, rails, heating chambers, exhaust, blowers, temperature control, width adjustment and weft straightener.
Pin Stenter or Clip Stenter Which To Use
Clips leave no pin marks and suit thicker fabrics; pins hold more tension and run faster, to 100 m per minute.
Send A Sample And We Will Match The Profile
Seat profiles and geometry changed across frame generations, so the part itself is more reliable than a model number. We identify it and quote the matching specification.
