Stainless Steel Coil
Stainless Steel Coil and Strip in 201 304 316 and 430
Corrosion resistant coil and strip for food kitchen chemical and architectural work
Stainless steel coil is a ferrous alloy strip containing a minimum of approximately 11% chromium, which is the composition that stops the iron rusting and also gives the material heat resistant properties. It is specified by cookware and cutlery makers, appliance manufacturers, food plant fabricators and architectural metalworkers who need corrosion resistance and steel strength in the same part. Grades run from 201 through 304 310 316 409 410 420 and 430, so an austenitic grade for a wet food line and a hardenable martensitic grade for a blade edge come off the same order. Surface finish is set at the time of ordering from NO.1 through 2B BA HL Embossed and 8K, which removes the polishing step a fabricator would otherwise have to buy in separately.
- Product Name — Stainless steel coil and strip
- Place of Origin — China
- Standards — BS EN GB AISI ASTM DIN JIS
- Material — SS201 SS304 SS316 SS430 SS410 SS420
- Grade — 201 304 310 316 430 409 410 420
Why It Is Specified
Key Benefits of Stainless Steel Coil
Chromium Content That Prevents Rusting
A minimum of approximately 11% chromium prevents the iron from rusting and also gives the alloy heat resistant properties, which is why the material is used without any surface coating.
Eight Grades From One Stock List
201 304 310 316 409 410 420 and 430 are held together, so a project that mixes an austenitic body with a hardenable trim part does not need two suppliers.
Finish Set Before It Reaches Your Shop
NO.1 2B BA HL Embossed and 8K are available on release, so the coil arrives at the finish the part needs instead of going out for polishing.
Safe for Food Contact Surfaces
The alloy is not harmed by the acids in many foods and is not porous, so it does not release metal or a metallic taste into the product.
Easy to Clean and Steam Disinfect
Corrosion resistance, ease of steam cleaning and disinfection and the absence of a surface coating are the reasons stainless is used in kitchens and food processing plants.
Thin Gauge Through to Plate
Thickness from 0.1mm to 100mm covers thin strip for pressed utensils and heavy section for tank and industrial equipment work.
Problems It Solves
What This Material Removes From Your Process
Coated Steel Failing in Wash Down Areas
Painted and plated steel breaks down where surfaces are steam cleaned and disinfected daily. Stainless carries its corrosion resistance in the alloy and has no surface coating to lose.
Paying for Polishing After Delivery
Sending material out for a BA HL or 8K finish adds a step and a handling risk. Coil is released at the ordered finish so the part goes straight into production.
Grade Substituted Between 201 304 and 316
These grades are not interchangeable in a chloride or acid duty. The order names the grade and the mill test certificate documents what was supplied.
Buying Sheet When the Part Needs Strip
Cutting sheet into strip wastes material on a press shop feed. Coil is slit to the strip width the press needs and supplied as coil or strip.
Metallic Taste and Contamination Risk
Porous or coated materials can pass metal into food. Stainless is not porous and is not harmed by the acids in many foods.
Application Scenarios
Where It Is Used
Cookware and Tableware Production
Pressed pans, pots and cutlery blanks where the material does not scratch or dent as easily as other cookware materials and keeps its luster.
Food Processing and Kitchen Equipment
Worktops, hoods, tanks and conveyor framing in food processing plants and commercial kitchens where steam cleaning and disinfection are routine.
Surgical and Medical Instruments
Instrument blanks in hardenable grades where the part has to hold an edge and survive repeated sterilization.
Major Appliances and Electrical Goods
Appliance skins, drums and panels where the visible surface finish is part of the product and has to arrive unmarked.
Chemical Water and Paper Plant Equipment
Vessels, ducting and structural parts in paper mills, chemical plants and water treatment plants handling acid alkali and salt media.
Storage Tanks and Tanker Bodies
Storage tanks and oil tanker sections carrying chemicals and food products where a coated steel tank would not be acceptable.
Who It Is For
Buyers Who Specify This Product
- Cookware and cutlery manufacturers buying thin strip in a set finish for pressing and deep drawing
- Food and beverage plant fabricators buying 304 and 316 coil for tanks hoods and wash down structures
- Appliance makers buying wide coil with a controlled visible finish for panels and drums
- Chemical and water treatment contractors buying corrosion resistant coil for vessels and ducting
- Architectural metalworkers buying HL and 8K finish coil for cladding handrails and interior panels
- Service centers decoiling stainless coil into strip for regional press shops
Technical Data
Specifications and Technical Features
Values below come from the product data published by Shandong Tianyu Metal Products. Confirm the exact grade and size against your order.
| Product Name | Stainless steel coil and strip |
|---|---|
| Place of Origin | China |
| Standards | BS EN GB AISI ASTM DIN JIS |
| Material | SS201 SS304 SS316 SS430 SS410 SS420 |
| Grade | 201 304 310 316 430 409 410 420 |
| Thickness | 0-100mm with the 0.1mm-100mm range or customized as required |
| Width | From 1500mm or customized as required |
| Size | 1000*2000mm 1220*2440mm or customized size |
| Technique | Solid |
| Surface | NO.1 2B BA Embossed HL 8K |
| Application | Cookware cutlery surgical instruments major appliances vehicles construction material |
| Processing Service | Bending welding decoiling cutting punching |
| Certificate | Mill test certificate |
| Sample | Available |
Technical Features
- Grades 201 304 310 316 409 410 420 and 430 with SS201 SS304 SS316 SS430 SS410 and SS420 designations
- Thickness 0.1mm to 100mm or customized as required
- Sheet sizes 1000*2000mm and 1220*2440mm or customized
- Width from 1500mm or customized as required
- Surface finishes NO.1 2B BA Embossed HL and 8K
- Produced to BS EN GB AISI ASTM DIN and JIS standards
- Contains a minimum of approximately 11% chromium with carbon from 0.03% to greater than 1.00%
- Processing covers bending welding decoiling cutting and punching
Materials
- Ferrous alloy containing a minimum of approximately 11% chromium
- Carbon content from 0.03% to greater than 1.00% depending on the grade
- Alloying additions including nitrogen aluminium silicon sulfur titanium nickel copper selenium niobium and molybdenum
- Austenitic grades 201 304 310 and 316 for corrosion resistant fabrication
- Ferritic and martensitic grades 409 410 420 and 430 for appliance trim and hardenable parts
Certification
- Mill test certificate supplied with the coil
Manufacturing
How It Is Made and Processed
Melting and alloying to the ordered grade chemistry
Rolling to the ordered coil thickness
Annealing and pickling for the NO.1 condition
Cold rolling and skin passing for 2B and BA finishes
Mechanical finishing for HL Embossed and 8K surfaces
decoiling to the ordered coil or strip width
Cutting to sheet size where the order calls for it
Interleaved packing to protect the finished surface for export
Quality Control
Checks Before It Ships
- Grade chemistry confirmed against the ordered designation
- Thickness checked across the ordered 0.1mm to 100mm range
- Surface finish inspected against the ordered NO.1 2B BA Embossed HL or 8K condition
- Coil and strip width verified before banding
- Sheet dimensions checked against 1000*2000mm 1220*2440mm or the customized size
- Mill test certificate issued for the supplied grade
Customization
What We Can Change on Your Order
- Grade selected from 201 304 310 316 409 410 420 and 430
- Thickness set anywhere from 0.1mm to 100mm
- Slit to the coil or strip width your press line takes
- Cut to 1000*2000mm 1220*2440mm or a customized sheet size
- Surface finish ordered as NO.1 2B BA Embossed HL or 8K
- Bending welding decoiling cutting and punching carried out before shipment
Comparison
Stainless Steel Coil Against the Alternatives
| Painted or coated carbon steel | Stainless carries corrosion resistance in the alloy with no surface coating, so steam cleaning and disinfection do not strip its protection. |
|---|---|
| Aluminium cookware and panels | Stainless does not scratch or dent as easily, is not harmed by the acids in many foods and is not porous so it does not pass a metallic taste into food. |
| Galvanized steel coil | Galvanized coil protects the base steel with a sacrificial zinc layer, where stainless resists acid alkali and salt media directly and can be cut without exposing bare steel. |
| Buying sheet and cutting strip in house | Coil cut to width feeds a press line continuously and removes the offcut created when strip is cut out of standard sheet. |
Use Guide
Specifying Handling and Welding Notes
- Choose 316 over 304 where chloride or salt exposure is expected and keep 201 for dry interior work
- Select the finish at the order stage because polishing a formed part costs more than buying the finish on the coil
- Use the hardenable 410 and 420 grades where an edge or a wear face has to be heat treated after forming
- Keep stainless away from carbon steel tooling grinding dust and storage racks to avoid iron contamination on the finished surface
- Leave the protective interleaving in place until the part is formed to protect BA HL and 8K surfaces
- Ask for the mill test certificate with the shipment so the grade and chemistry are on record for the food or chemical duty
Questions Buyers Ask
Stainless Steel Coil FAQ
Which stainless grades do you supply in coil?
201 304 310 316 409 410 420 and 430, listed as SS201 SS304 SS316 SS430 SS410 and SS420. Name the grade on the enquiry and it is quoted against the standard you work to.
What thickness and sheet sizes are available?
Thickness from 0.1mm to 100mm, with standard sheet sizes of 1000*2000mm and 1220*2440mm or a customized size. Coil width starts from 1500mm.
Which surface finishes can I order?
NO.1 2B BA Embossed HL and 8K. The finish is applied before shipment so the part does not have to be polished after forming.
How much chromium is in the material?
Stainless contains a minimum of approximately 11% chromium, and carbon runs from 0.03% to greater than 1.00% depending on the grade. The mill test certificate states the actual chemistry.
Is the material suitable for food contact equipment?
It is used in kitchens and food processing plants because it resists corrosion, is easy to steam clean and disinfect, carries no surface coating, is not porous and is not harmed by the acids in many foods.
Can you slit the coil into strip for our press line?
Yes. Decoiling and cutting are part of the processing service, so coil can be slit to the strip width your line takes or cut to sheet.
Do you send a mill test certificate and can we get a sample?
A mill test certificate is issued for the supplied grade, and samples are available. Tell us the grade thickness and finish you want to evaluate.
Go Deeper
Industries and Guides Related to This Product
Construction and Infrastructure
Construction and infrastructure buyers order steel by the part it becomes: mild steel plate for base plates gussets and stiffeners
Read more
Automotive and Transport
Vehicle and trailer components fail on fatigue, not on a single overload, so the grade behind each part matters more than the pric
Read moreNeed a Price on Stainless Steel Coil
Send the grade, thickness, width and quantity you need together with your destination port. A cutting list or drawing gets you a firmer number.
