SC Fast Connector (Ref 284)

Name: SC Fast Connector (Ref 284)
Brand: Ever Expresslink
SKU: sc-fast-connector-284

Field Assembly/Fast Connector

SC Fast Connector (Ref 284) is part of the field assembly/fast connector range built by Ever Expresslink Limited in Ningbo, China. It is built on the SC (Subscriber Connector) interface.

Mechanical field termination without a fusion splicer

Interested in SC Fast Connector (Ref 284)

Email the model and quantity with your destination country. We reply with pricing, lead time and a datasheet.

Request A Quote Request A Sample

Product Overview

SC Fast Connector (Ref 284) is part of the field assembly/fast connector range built by Ever Expresslink Limited in Ningbo, China. It is built on the SC (Subscriber Connector) interface.

It is the workhorse of FTTH and passive optical distribution: a technician can seat a port blind, inside a closure, wearing gloves, without rotating anything. SC bodies clip together into duplex pairs. Check polarity before you clip, because a reversed duplex clip is easy to build and hard to spot in a cabinet.

It is one of 6 items in this range. A typical application is restoring a broken patch cord in a live cabinet. What the range is built to give you there: consistent factory-polished end face inside every connector.

The problem it addresses is fusion splicers that are too expensive to put in every van. A practical note that applies across this range: insert until the fiber visibly bows slightly, then lock the mechanism. Specifications for a particular configuration are confirmed on the quotation rather than assumed from the designation.

Key Benefits

Supplied as SC Fast Connector (Ref 284), so the part you receive matches the designation you ordered against
No fusion splicer, no power and no splice protection sleeve needed
Termination in minutes rather than a splicing setup cycle
Re-usable versions let a failed termination be corrected on the spot
Visual confirmation of fiber insertion on designs that provide it

Problems It Solves

Emergency restoration where a splicer is not available
Training burden for crews who only terminate occasionally
Re-work when a field termination fails and has to be redone
Fusion splicers that are too expensive to put in every van

Application Scenarios

Enterprise backbone links
Enterprise fiber repairs by non-specialist staff
Terminating a subscriber drop at the premises
Restoring a broken patch cord in a live cabinet
MDU riser terminations where a splicer cannot be set up

Who It Is For

FTTH drop installation crews
Broadband service call technicians
Building and MDU cabling contractors
Maintenance crews doing emergency restoration

Technical Features

SC (Subscriber Connector) interface
SC bodies clip together into duplex pairs. Check polarity before you clip, because a reversed duplex clip is easy to build and hard to spot in a cabinet.
Designs for 250 µm, 900 µm and drop cable
SC and FC bodies in UPC and APC polish
Factory-polished fiber stub inside the connector
Mechanical splice with index-matching gel

Materials

Zirconia ceramic ferrule with pre-polished stub
Index-matching gel
Mechanical splice element
Thermoplastic housing and boot

Specifications

Product Designation	SC fast connector
Product Family	Field Assembly/Fast Connector
Connector Interface	SC (Subscriber Connector)
Manufactured In	Ningbo, China
Warranty	One year against defects in materials and workmanship

Values shown are those carried by the product designation. Dimensional and optical values for a specific order are confirmed on the quotation.

Manufacturing Process

Stub fiber termination and polish in the factory
End-face inspection of every stub
Mechanical splice element assembly
Gel dosing and sealing
Function sampling and packing

Quality Control

Stub end-face inspection before assembly
Trial field termination and loss measurement per lot
Mechanical splice retention force sampling
Gel presence and sealing verified
Packing count verified before dispatch

Customization Options

SC or FC body
UPC or APC polish
Fiber acceptance for 250 µm, 900 µm or drop cable
Kitted with cleaver and cleaning consumables
Private-label packaging for rollout programs

Compared With Other Options

LC	LC is half the footprint and doubles port density; SC is easier to handle in a crowded closure
FC	FC's threaded nut resists vibration; SC is faster to patch and re-patch

Use Guide

Handling SC Fast Connector (Ref 284)

Before You Order

Use a precision cleaver; cleave angle is the main cause of high loss here
Clean the fiber with a lint-free wipe before insertion
Insert until the fiber visibly bows slightly, then lock the mechanism

In Service

Verify with a visual fault locator or power meter before closing up
On reusable versions, re-cleave rather than reusing a damaged fiber end
Record which terminations were mechanical rather than fusion spliced

FAQ

Questions About SC Fast Connector (Ref 284)

What do you need from us to quote SC Fast Connector (Ref 284)?

The quantity, the destination and anything that has to match on your side: connector and polish at each end, fiber mode and core size, and length where the item is an assembly. If you are matching a part you already buy, send the sample and we will quote against it.

Can SC Fast Connector (Ref 284) be supplied with a different connector interface?

Yes. SC (Subscriber Connector) is what this designation carries, and the same family is stocked across the other mainstream connector standards. Tell us the port you have to mate with and we will confirm the equivalent part.

Do I need special tools?

A precision cleaver and the matching hand tool. No power, no fusion splicer and no heat-shrink oven. Cleaver quality has a direct effect on the loss you achieve.

Are APC versions available for PON drops?

Yes. APC fast connectors are supplied for PON and RF-over-glass paths where back reflection matters, and they are color coded green as usual.

How does a fast connector compare with a fusion splice?

A fusion splice normally gives lower and more predictable loss, and it is what you want on backbone and distribution work. A fast connector trades a little loss for speed and for not needing a splicer, which is often the right trade on a subscriber drop.
