Webbing sling
Polyester Flat Webbing Sling
Double ply polyester flat webbing sling with reinforced lifting eyes, built to European Standard EN 1492-1 and supplied with a CE declaration of conformity.
- Standard
- EN 1492-1
- Material
- High tensile polyester PES, AA class
- Safety factor
- 5:1, 6:1, 7:1 or 8:1
- Ply
- Single or double
- Elongation
- Below 7 percent at working load
- Width
- 25 mm to 300 mm depending on capacity
Full specification, standards and testing detail below. CAD files are available on request via WhatsApp.
Product Overview
What The Polyester Flat Webbing Sling Is
The flat webbing sling is the workhorse of soft slinging. A flat woven polyester band with a sewn eye at each end spreads the load over a wide contact area, so it lifts painted, machined and coated surfaces without the marking that a chain or wire rope sling leaves behind.
Carl Stahl China supplies flat webbing slings in AA class high tensile polyester, single or double ply, with reinforced lifting eyes and a sewn label carrying the working load limit, the standard and the batch data. Effective working length, colour, ply and safety factor are all built to the order.
Key Benefits
Why Buyers Choose This Product
Protects The Load Surface
The wide flat band spreads contact pressure, so finished, painted and polished surfaces arrive without pressure marks or scoring.
Light Enough To Rig By Hand
A polyester sling weighs a fraction of the chain or wire rope sling of the same capacity, so riggers can position it without a second lift.
Instantly Readable Capacity
The EN colour code tells the operator the working load limit before they read the label, which removes the most common cause of overload.
Low Elongation Under Load
Elongation stays below 7 percent at working load, so the load lifts predictably instead of stretching and settling.
Application Scenarios
Where It Is Used And Who It Is For
Application Scenarios
- Machine tool and press installation where a machined surface must not be marked
- Loading and unloading of steel structures, tanks and vessels
- Precast concrete and stone handling on site
- Shipyard and offshore module handling
- General workshop and warehouse lifting up to 10 t
Who It Is For
- Lifting equipment distributors who resell to industry under their own brand
- Rigging houses assembling sling sets for construction and plant hire
- Machine builders shipping equipment with matched lifting gear
- Safety and PPE wholesalers supplying European markets
Problems It Solves
The Sourcing Problems This Product Removes
Chain slings leave marks on finished workpieces
Solution. A flat polyester band spreads contact pressure over its full width and does not bite into paint, plating or machined faces.
Riggers cannot tell one sling from another on site
Solution. The EN colour code makes the working load limit visible at a distance, so the wrong sling is not picked up by mistake.
Imported slings arrive without usable paperwork
Solution. Every sling ships individually bagged with a CE declaration of conformity, and material and test certificates are available on request at order time.
Sling lengths never match the lift
Solution. Effective working length is made to the order rather than sold in fixed steps, so the sling suits the actual geometry of the lift.
Technical Features
Construction Standards And Specification
- Double PES webbing with reinforced lifting eyes
- Material: high tensile polyester PES, AA class
- Safety factor 5:1, 6:1, 7:1 or 8:1
- Single or double ply
- Standard: European Standard EN 1492-1
- Low elongation below 7 percent
- Effective working length made to the order
- Colour coded to the EN colour scheme
- OEM brand and marking, and modification to local standards where required
- Standard
- EN 1492-1
- Material
- High tensile polyester PES, AA class
- Safety factor
- 5:1, 6:1, 7:1 or 8:1
- Ply
- Single or double
- Elongation
- Below 7 percent at working load
- Width
- 25 mm to 300 mm depending on capacity
- Length
- Made to the customer requirement
- Packing
- Individual plastic bag with CE declaration of conformity
- Lead time
- 30 to 45 days depending on order quantity and season
Specifications
Working Load Limits And Dimensions
| WLL | Colour | Straight 1.0 | Choke 0.8 | Basket to 7° 2.0 | Basket 7–45° 1.4 | Basket 45–60° 1.0 | 2 slings straight to 45° 1.4 | 2 slings choke to 45° 1.12 | 2 slings straight 45–60° 1.0 | 2 slings choke 45–60° 0.8 |
|---|---|---|---|---|---|---|---|---|---|---|
| 1000 kg | Violet | 1000 | 800 | 2000 | 1400 | 1000 | 1400 | 1120 | 1000 | 800 |
| 2000 kg | Green | 2000 | 1600 | 4000 | 2800 | 2000 | 2800 | 2240 | 2000 | 1600 |
| 3000 kg | Yellow | 3000 | 2400 | 6000 | 4200 | 3000 | 4200 | 3360 | 3000 | 2400 |
| 4000 kg | Grey | 4000 | 3200 | 8000 | 5600 | 4000 | 5600 | 4480 | 4000 | 3200 |
| 5000 kg | Red | 5000 | 4000 | 10000 | 7000 | 5000 | 7000 | 5600 | 5000 | 4000 |
| 6000 kg | Brown | 6000 | 4800 | 12000 | 8400 | 6000 | 8400 | 6720 | 6000 | 4800 |
| 8000 kg | Blue | 8000 | 6400 | 16000 | 11200 | 8000 | 11200 | 8960 | 8000 | 6400 |
| 10000 kg | Orange | 10000 | 8000 | 20000 | 14000 | 10000 | 14000 | 11200 | 10000 | 8000 |
| WLL | Colour | Width mm | Eye length mm | Item code 1 m | Item code 3 m | Item code 6 m |
|---|---|---|---|---|---|---|
| 1000 kg | Violet | 25 / 30 / 50 | 200 | JLE-1001 | JLE-1003 | JLE-1006 |
| 2000 kg | Green | 50 / 60 | 250 | JLE-2001 | JLE-2003 | JLE-2006 |
| 3000 kg | Yellow | 75 / 90 | 300 | JLE-3001 | JLE-3003 | JLE-3006 |
| 4000 kg | Grey | 100 / 120 | 375 | — | JLE-4003 | JLE-4006 |
| 5000 kg | Red | 125 / 150 | 500 | — | JLE-5003 | JLE-5006 |
| 6000 kg | Brown | 150 / 180 | 600 | — | JLE-6003 | JLE-6006 |
| 8000 kg | Blue | 200 / 240 | 700 | — | JLE-8003 | JLE-8006 |
| 10000 kg | Orange | 250 / 300 | — | — | JLF-0003 | JLF-0006 |
Lifting Methods
Mode Factors For Each Hitch
The working load limit on the label applies to a straight lift. Multiply it by the mode factor for the hitch and the angle of inclination before selecting the sling.
Materials And Manufacturing
Materials, Process And Quality Control
Materials
- AA class high tensile polyester PES yarn, chosen for low elongation and high abrasion resistance
- Polyester sewing thread matched to the webbing so the seam ages with the band
- Woven label carrying WLL, standard, material, length and batch number
Manufacturing Process
- Yarn selection and weaving of AA class polyester webbing
- Cutting to the ordered effective working length
- Sleeve or eye reinforcement and multi row lock stitching
- Label sewing with WLL, colour code, standard and batch data
- Sample proof loading, packing in individual plastic bags
Quality Control
- Incoming inspection of AA class polyester yarn and thread
- Width, ply and stitch pattern checked against the production drawing
- Label content verified against the order before sewing
- Sample proof loading to the declared safety factor
- Every sling individually bagged with its CE declaration of conformity
Certifications And Customisation
What We Certify And What We Can Change
Certifications
- CE declaration of conformity supplied with every sling
- ISO 9001 certified manufacturing partners
- SGS audited supply chain
Customisation Options
- Effective working length to the millimetre
- Single or double ply
- Safety factor 5:1, 6:1, 7:1 or 8:1
- OEM brand woven or printed on the webbing
- Own label layout and batch numbering
- Protective sleeves at the eyes or along the body
- Modification to local standards on request
Comparison
How It Compares With Other Products
| Flat webbing sling | Round sling | Wire rope sling | |
|---|---|---|---|
| Surface protection | Very good, wide flat contact | Very good, soft body | Poor, can score the load |
| Weight | Light | Light | Heavy |
| Capacity range | 1 t to 10 t colour coded | 1 t to 100 t on request | Wide |
| Cut resistance on sharp edges | Needs edge protection | Needs edge protection | Better |
| Standard | EN 1492-1 | EN 1492-2 | Other |
Use Guide
How To Use The Polyester Flat Webbing Sling Safely
- Read the label and confirm the working load limit before every lift, and confirm it again against the colour code.
- Reduce the capacity for the lifting method and the angle of inclination using the mode factors in the table above.
- Never lift over a sharp edge without a protective sleeve or edge protector.
- Withdraw any sling with a cut, a chemical burn, a damaged eye or an unreadable label.
- Keep personnel clear of the load and out of the line of the sling while the slack is taken up.
- Store the sling clean, dry and out of direct sunlight when it is not in use.
FAQ
Polyester Flat Webbing Sling FAQ
What does the safety factor mean on a webbing sling?
It is the ratio between the minimum breaking force of the sling and its working load limit. A 7:1 sling breaks at seven times its marked working load limit. We build to 5:1, 6:1, 7:1 or 8:1 according to the market you sell into.
Can you weave our own brand into the webbing?
Yes. OEM brand marking on the webbing and a customer specific label layout are both standard options, and the label content can be modified to local standards where required.
What is the minimum order quantity?
Order quantity depends on width and capacity. Send the sizes and quantities you need to [email protected] and we will confirm the minimum for that combination.
How long does production take?
Normally 30 to 45 days depending on the order quantity and the season.
Is a certificate supplied with the slings?
Every sling is packed in a plastic bag with a CE declaration of conformity. Material and test certificates can be issued when they are requested at the time of order.
