Hand Pallet Truck

Model BF-III hand pallet truck, the most standard and popular model with a capacity of 2500 kg to 3500 kg, economical, easy to control and easy to handle.

Request A Quote Talk To An Engineer Email Us

Model: BF-III
Capacity: 2500 kg to 3500 kg
Steering wheel: 200 mm, with 80 mm fork wheel, available
Wheel material: Nylon, polyurethane or rubber, single fork roller or tandem fork rollers
Fork length: 800 mm, 900 mm, 1000 mm or 1100 mm
Pump: Integrated, without welding

Full specification, standards and testing detail below. CAD files are available on request via WhatsApp.

Product Overview

What The Hand Pallet Truck Is

The hand pallet truck is the piece of equipment that moves the pallet the last twenty metres. The BF-III is the standard and most popular model in the range, built around an integrated pump without welding so there are no leaking problems where a welded joint would normally fail.

The frame force is more reasonably distributed and the strength is more reliable than earlier designs, the supporting base is thicker to prevent bending, and the forks are heavy in section. Fork lowering speed is controllable and an overload valve prevents overloading.

Key Benefits

Why Buyers Choose This Product

No Welded Pump Joints To Leak

The integrated pump has no welding, which removes the joint that leaks first on a conventional truck.

Thicker Base Resists Bending

The new type supporting base is thicker, which is what prevents the bending problem that ends the life of a pallet truck.

Controlled Lowering

Fork lowering speed is controllable and an overload valve prevents the truck being loaded beyond its rating.

Easy To Service

The handle seat has a hole that makes installation of the control chain far more convenient.

Application Scenarios

Where It Is Used And Who It Is For

Application Scenarios

Warehouse and distribution centre pallet movement
Loading bay and container stuffing work
Production line feeding and finished goods movement
Retail back of house handling

Who It Is For

Warehouses and distribution operations
Manufacturers moving pallets between lines and stores
Distributors of warehouse handling equipment
Export buyers looking for a standard economical model

Problems It Solves

The Sourcing Problems This Product Removes

Pallet truck pumps leak at the welded joints

Solution. The integrated pump is made without welding, so there are no leaking problems from that source.

Supporting bases bend under repeated loading

Solution. The new type supporting base is thicker specifically to prevent the bending problem.

Forks lower too fast and jar the load

Solution. Fork lowering speed is controllable, and an overload valve protects against overloading.

Fork sizes never match the pallet

Solution. Fork lengths of 800 mm, 900 mm, 1000 mm and 1100 mm are available, and special widths and lengths are made to the customer requirement.

Technical Features

Construction Standards And Specification

Hot sale model BF-III, most popular and economical, easy control and handle
Most standard and popular model with capacity 2500 kg to 3500 kg
Supporting base: the new type is thicker in case of bending problems
Strong forks with heavy thickness
Integrated pump without welding, no leaking problems
Frame force is more reasonable and the strength is more reliable
Handle seat has a hole, more convenient for installation of the control chain
Fork lowering speed is controllable, with an overload valve to avoid overloading
Fork pedal release
Quick lift double speed lifting available

Model: BF-III
Capacity: 2500 kg to 3500 kg
Steering wheel: 200 mm, with 80 mm fork wheel, available
Wheel material: Nylon, polyurethane or rubber, single fork roller or tandem fork rollers
Fork length: 800 mm, 900 mm, 1000 mm or 1100 mm
Pump: Integrated, without welding
Pump colour: Black painting
Options: Quick lift double speed lifting, fork pedal release

Materials And Manufacturing

Materials, Process And Quality Control

Materials

Pressed and welded steel frame and forks
Integrated hydraulic pump unit
Nylon, polyurethane or rubber wheels

Manufacturing Process

Fork and frame pressing and welding
Pump unit assembly and pressure testing
Wheel and roller fitting
Load testing to the rated capacity
Painting and packing

Quality Control

Pump pressure tested on every unit
Lift and lower function tested through the full stroke
Overload valve setting verified
Rated load test applied before packing
Paint and marking inspection

Certifications And Customisation

What We Certify And What We Can Change

Certifications

ISO 9001 certified manufacturing partners
Test certificates available when requested at the time of order

Download the certificate pack →

Customisation Options

Fork length 800 mm, 900 mm, 1000 mm or 1100 mm
Special width and length made to the customer requirement
Nylon, polyurethane or rubber wheels
Single fork roller or tandem fork rollers
Quick lift double speed lifting
Steering wheel 200 mm with 80 mm fork wheel
OEM branding

Get A Custom Solution

Use Guide

How To Use The Hand Pallet Truck Safely

Confirm the fork length and width suit the pallets in use before ordering.
Pump the handle to raise the forks only after they are fully inserted into the pallet.
Use the release lever to lower under control rather than dropping the load.
Keep the load within the rated capacity. The overload valve protects the pump but is not a licence to overload.
Check the wheels and rollers for flats and debris at regular intervals.
