Seal Eco Thermal Sealer
The Seal Eco is a thermal sealer designed for small to mid-size clinics that need to wrap instruments in sterilization pouches or reels with consistent, reliable seals.
Overview
What The Seal Eco Is For
The Seal Eco is a thermal sealer designed for small to mid-size clinics that need to wrap instruments in sterilization pouches or reels with consistent, reliable seals. A 12 mm-wide sealing seam holds under pressure test, and the machine maintains temperature and pressure automatically during continuous use. It fits on a bench or counter with a compact footprint and operates on 220 V or 110 V, making it suitable for clinics with limited space and variable power supplies.
80+Countries with users
5+Patented technologies
1800Days of aging test
12Months warranty
Key Benefits
Why Clinics Choose The Seal Eco
12 mm-wide sealing seam remains intact after 3 seconds of pressure test, with no risk of burning or scorching
Constant temperature heating and automatic pressure adjustment maintain seal quality during continuous operation
Rapid preheating in 2 to 3 minutes reduces downtime between pouches
Hidden sliding blade protects the user from injury during operation
Roll holder supports up to three different roll widths simultaneously, increasing efficiency
Flexible width adjustment allows sealing of pouches from 5 cm to 30 cm wide
Application Scenarios
- Wrapping dental handpieces and hand instruments in sterilization pouches before loading into a Novo Pro sterilizer
- Sealing instrument reels for use in aesthetic clinics that sterilize reusable cannulas and needles
- Creating sealed packs in veterinary practices for surgical instruments used between animals
- Producing consistent pouches in tattoo and piercing studios where sterility is required for each session
- Maintaining a record of seal integrity by using the same machine for every pack, reducing variability
Who It Is For
- Dental clinics and stomatology departments wrapping instruments for sterilization
- Aesthetic and cosmetic clinics that sterilize reusable tools and needles
- Veterinary practices preparing sealed surgical packs in-house
- Tattoo and piercing studios requiring sterile packaging for each client
- Dental equipment distributors needing a reliable sealer for demonstration or resale
Problems It Solves
What Goes Wrong Without It
- Inconsistent seals from manual or low-end sealers can fail during sterilization, leading to contamination
- Manual adjustment of temperature and pressure leads to variation between users and shifts
- Exposure to sharp edges during loading or unloading increases the risk of injury
- Lack of automatic signals means staff may miss the end of a seal cycle, causing delays
- Single roll holders require frequent changeovers, slowing down the reprocessing workflow
Technical
Technical Features And Specifications
- 12 mm-wide sealing seam with integrity tested under 3 seconds of pressure
- Constant temperature heating with automatic pressure regulation for consistent performance
- Rapid preheating in 2 to 3 minutes, ready for use after power-on
- Hidden sliding blade design for user safety during operation
- Roll holder supports up to three different roll widths at once, including 5 cm, 7.5 cm, 10 cm, 15 cm, 20 cm, 25 cm, and 30 cm
- Automatic beep signal indicates completion of each seal cycle
- Overheat protection built into the system to prevent damage
- Microcomputer control system manages sealing parameters and adjusts in real time
- Optional condensation system available for environments with high humidity
- Intelligent sealing system maintains performance under continuous use
| Seal Width | 12 mm |
|---|---|
| Preheating Time | 2-3 min |
| Voltage Frequency | 220 V, 110 V, 150 Hz, 60 Hz |
| Consumption Power | 100 W |
| Overheat Protection | Yes |
| Phase Number | Single phase |
| Fuse Specification | 2-5 x 20 T8A |
| Service Environment | Indoor use, altitude less than 3000 m, ambient temperature 5 to 40 degrees, relative humidity 85% RH, maximum fluctuation ±10% |
| Gross Weight | 7.5 kg |
| Net Weight | 1.23 kg |
| Maximum Bearing Width | 300 mm |
| Conformity | Low Voltage Directive 2014/35/EU, Electromagnetic Compatibility Directive 2014/30/EU, Machinery Safety Directive 2006/42/EC |
| Roll Width Support | 5 cm, 7.5 cm, 10 cm, 15 cm, 20 cm, 25 cm, 30 cm |
| Number of Rolls Supported | 3 at once |
| Sealing Temperature | Automatically adjusted |
| Sealing Pressure | Automatically adjusted |
| Sealing Speed | Quick sealing, no fixed time given |
| Control System | Microcomputer |
| Optional Features | Condensation system, instrument tray |
Materials
- Stainless steel shell for durability and cleanability
- Hidden sliding blade made of hardened steel
- Microcomputer control unit
- Aluminium roll holder with adjustable guides
How It Is Used In The Workflow
- Prepare the sterilization pouch or reel by placing it on the sealing bed
- Adjust the width guide to match the pouch width, from 5 cm to 30 cm
- Place the pouch or reel into the machine with the open end facing the sealing bar
- Press the start button; the machine preheats and begins sealing automatically
- The beep signal confirms the seal is complete
- Remove the sealed pouch or reel and store it for sterilization
- Use the optional condensation system if humidity is high in the room
Quality Control
- Every unit undergoes an 1800-day aging test before shipment
- Seal integrity is verified through a 3-second pressure test on every unit
- Automatic temperature and pressure regulation ensures consistent performance across cycles
- Overheat protection activates if internal temperature exceeds safe limits
- The control system logs operational data during aging and testing
Certifications And Conformity
- EN 13060 small steam sterilizer
- IEC 61010-1
- IEC 61010-2-040
Options
Configuration And Customization
Optional condensation system for high humidity environments
Optional instrument tray for holding sealed pouches during workflow
Multi-language interface available upon request
OEM and ODM builds available for distributors, discussed case by case
Comparison
How The Seal Eco Compares
| Compared With | What Changes |
|---|---|
| Manual heat sealer | The Seal Eco maintains consistent temperature and pressure; manual sealers vary by user and can burn or under-seal |
| Single-roll sealer | The Seal Eco supports three roll widths at once, reducing changeover time and increasing throughput |
| Seal Eco LED | The LED variant has a simpler interface; the Seal Eco includes automatic signals and a hidden blade for safety |
| Centralized packaging | Sending pouches out adds transport risk and delays; the Seal Eco allows on-site sealing with immediate use |
Use Guide
Running The Seal Eco Day To Day
- Place the machine on a stable, dry bench with adequate clearance for ventilation
- Ensure the power supply matches the voltage and frequency listed on the label
- Adjust the width guide to match the pouch or reel width before sealing
- Use only sterilization bags designed for thermal sealing
- Do not operate the machine without a pouch in place to avoid damage
- Clean the sealing bar after every 100 cycles with a soft cloth and mild detergent
- Replace the roll when the remaining length is less than 20 meters
FAQ
Seal Eco Questions
What is the seal width on the Seal Eco
The Seal Eco produces a 12 mm-wide sealing seam, tested to remain intact under 3 seconds of pressure.
Can the machine handle different roll widths at once
Yes, the roll holder supports up to three different roll widths simultaneously, including 5 cm, 7.5 cm, 10 cm, 15 cm, 20 cm, 25 cm, and 30 cm.
How long does it take to preheat
The machine preheats in 2 to 3 minutes, ready for use after power-on.
Is the blade safe to use
Yes, the blade is hidden and only exposed during roll loading, reducing the risk of injury.
What power supply does it need
The Seal Eco operates on 220 V or 110 V, 150 Hz or 60 Hz, single phase, with a consumption power of 100 W.
Can it be used in high humidity
Yes, but the optional condensation system is recommended for environments with high humidity to prevent moisture interference.
Do you supply OEM or ODM versions
Yes. Joident offers OEM and ODM builds for distributors. Contact us by email or WhatsApp to discuss requirements.
