Zirconia Ceramic Parts
Zirconia Ceramic Rods and Shafts
94.4 percent zirconia rod with 0.5 micron crystal size and low minimum order
A ceramic rod is only as good as its microstructure. These rods run 94.40% zirconia content at 6.0 g/cm3 with a crystal size of 0.5 microns, zero gas permeability and zero water absorption, which is what allows a slender rod to be ground straight and stay straight. Size and colour are customized, and the minimum order is deliberately low so a single machine trial does not need a production run.
Key Benefits
- Crystal size of 0.5 microns supports a fine ground surface on slender sections
- Density 6.0 g/cm3 with zero porosity and zero water absorption
- High strength and impact resistance for shafts, guides and grinding media
- Non-magnetic and corrosion resistant for instrument and food equipment
- Low minimum order quantity, with size and colour customized
Problems It Solves
- Steel shafts corroding or magnetising in instrument and dosing equipment
- Rods bowing or scoring in abrasive guiding duty
- High minimum order quantities blocking a small machine trial
Who It Is For
- Instrument builders needing non-magnetic shafting
- Machine designers replacing hard chrome guide rods
- Buyers running a first trial before a production commitment
Application Scenarios
Ceramic shafts and guide rails in precision machinery
Optical fibre sleeves and ferrules
Grinding media in mills and dispersers
Plungers and dispensing valve components
Technical Features
- Zirconia content 94.40%, density 6.0 g/cm3
- Crystal size 0.5 microns
- Gas permeability 0 and water absorption 0%
- White body, size and colour customized
Manufacturing Process
Raw material preparation, forming, surface grinding, internal and external diameter grinding and precision CNC machining are all carried out in house.
Materials
- Zirconia
Specifications
| Material | Zirconia |
|---|---|
| Colour | White, customized |
| Size | Customized |
| Density | 6.0 g/cm3 |
| Zirconia content | 94.40% |
| Crystal size | 0.5 um |
| Gas permeability | 0 |
| Water absorption | 0% |
| Minimum order quantity | Low MOQ |
Figures are taken from the published product specification. Values not listed are marked TBC and confirmed against your drawing before quotation.
Quality Control
- Diameter and straightness checked along the rod length
- Surface inspected for grinding defects
- Inspection report issued to your drawing on request
Certifications
No third party certification documents are published for this product. Every shipment is inspected to your drawing with an inspection report issued. Certification status is TBC and confirmed on request.
Customization Options
- Diameter, length and surface finish to your drawing
- Customized colour
- Ends ground square, chamfered or radiused as required
Comparison With Other Ceramics
Alumina rods cost less and are harder, but a slender alumina rod breaks easily. Zirconia is the choice whenever the rod is long relative to its diameter or has to survive handling, since it is the tougher body.
Use Guide
- Specify straightness over the full length, not only the diameter tolerance
- Support long rods at intervals in the fixture rather than clamping at the ends only
- Store rods horizontally on a padded rack to avoid edge chipping
Industries Using This Part
Related Solutions
Related Application Notes
Zirconia Ceramic Rod FAQ
What is the zirconia content?
94.40%, at a density of 6.0 g/cm3 with a crystal size of 0.5 microns.
Is there a high minimum order?
No. Low minimum order quantity is one of the listed features, so a trial quantity is possible.
Can rods be supplied in other colours?
Yes, customized colour and customized size are both available.
Is the rod porous?
No. Gas permeability is 0 and water absorption is 0%.
What is the lead time?
Samples in 4 to 7 working days, production 15 to 30 days if not in stock, according to dimension and quantity.
Do you work from drawings?
Yes. Our main business is OEM and ODM. Please show us your drawing.
