Warp Knitting Spare Parts
Guide Bar Frames And Ball Bearings
Guide bar frames, ball bearings and machine axes.
What This Part Does On The Machine
The guide bar frame carries the guide bar and transfers the swing and shog motion to it. Its bearings decide how much lost motion there is between the drive and the guide, and lost motion at that point becomes a fabric fault.
Ball bearings in this range are listed by bore and outside diameter, for example 10x43, 12x43, 12x70, 18x60, 18x65, 25x85 and 25x110, including copper cage and double layer types. Machine axes are listed with them.
Where It Is Used
Karl Mayer warp knitting machines and compatible machines.
What To Send With Your Enquiry
- Machine brand and machine type.
- Bearing bore and outside diameter, or the old bearing marking.
- Whether the copper cage or double layer type is fitted.
- Quantity required.
Category At A Glance
| Parts listed | 28 |
|---|---|
| Bearing sizes listed | 10x43, 12x43, 12x70, 18x60, 18x65, 25x85, 25x110 |
| Bearing variants | Copper cage, double layer |
| Related parts | Guide bar frames, machine axes |
Talk To Us About This Range
Send the machine details and a photograph and we will confirm the exact item.
Machine Applications
All 28 Parts In This Category
Listed with the reference used on the original Huaxiatex catalogue. Click any part for its full page.
How We Handle This Range
Consolidated Spare Parts Supply
One source across elements, bars, lubrication, drive and patterning.
Read MoreOther Categories In Warp Knitting Spare Parts
Oil Bellows And Oil Cups
One, three and five layer oil bellows, cups, bases and rings.
22 parts listed
Tension Plates
Tension plates and tension springs in 12 to 26 pin formats.
14 parts listed
Needle Belts
Karl Mayer, KS and LIBA needle belts in 40 and 80 pin formats.
4 parts listed
Needle Covers
Needle covers by length, plus butterfly plates and press covers.
34 parts listed
Flizers, Sliders And Rods
Flizers, sliders, connecting rods and rod bowls.
16 parts listed
Steel Wire Ropes
Steel wire ropes from 12cm to 30cm, wires, locks and hooks.
17 parts listed
Weft Hooks
Weft hooks listed by part number.
8 parts listed
Chain Links And Pattern Discs
Pattern discs and chain links for Karl Mayer and LIBA.
7 parts listedGuide Bar Frames And Ball Bearings FAQ
How are the bearings sized on this site?
By bore and outside diameter in millimetres, written as bore x outside diameter.
How do I tell a worn bar frame bearing from a worn guide?
Rock the guide bar by hand with the machine stopped. Play at the frame is felt as a knock, a worn guide is not.
How do I confirm the part fits my machine?
Send the machine brand, the machine type and the gauge together with a photograph of the old part. Where a number is cast or stamped on the part, send that as well. We match against the reference used on this site and confirm before anything is produced or shipped.
Can you supply a small quantity?
Yes. The original company statement is that quick delivery is done for any order, even for a small order size. Send the quantity you actually need and we will quote it.
Which countries do you ship to?
Products have been exported worldwide, covering Europe, Asia, Africa and the Middle East.
How do I get a price?
Send the part reference, the gauge and the quantity by WhatsApp or email to [email protected] and we will come back with a quotation.
Get A Quotation For Guide Bar Frames And Ball Bearings
Send the machine brand, machine type, gauge and quantity. Quick delivery is done for any order, even for a small order size.
