Wall-mounted-jib-crane
Wall mounted jib crane provides 0-180 degrees of rotation and can be easily mounted on any substantial steel structure building column at any desired height.The crane has the advantages of high efficiency, energy saving, labor saving, less
- Capacity
- 0.25-5T
- Lift Height
- 1-40m
- Radius
- 2-8m
- Lift Speed
- 0-8 m/min/Customized
- Traveling
- 0-20m/min/Customized
- Rotation Speed
- 0.76-0.53 m/min
Quotation in 24 hours · CAD drawing in 48 hours · FEM / DIN / ISO design
Product Overview
<
p
>
Product Gallery
Technical Features
- Adopt high-strength bolt connection for installation.
- The classification is up to A6
- All the movement speed can be drived by Inverter and inverter brand adoped the Schneider/ABB/Siemens
- All the electric component adopts the Scheider or ABB
- Easy to operate, safe, flexible steering.
- Low noise, spacious and beautiful engine room.
- The overall structure is reasonable and simple, light weight, in line with national standards.
- Compact structure, light weight, high lifting height.
- Improve your productivity.
- Reliable quality and guaranteed after-sales service.
Where It Is Used
- The wall mounted jib crane can be wilding used in manufacturing workshop, metallurgy, petroleum, petrochemicals, ports, railway, civil aviation, power station, food industry, paper making, building material, warehouses and other material handling application.
- Reduce your cost of building buildings and workshops.
- Suitable for different operating conditions, to provide you with one-stop solutions.
Specifications
Values below are the published standard configuration. Anything outside this range is a customisation question, not a catalogue lookup.
| Capacity | 0.25-5T |
|---|---|
| Lift Height | 1-40m |
| Radius | 2-8m |
| Lift Speed | 0-8 m/min/Customized |
| Traveling | 0-20m/min/Customized |
| Rotation Speed | 0.76-0.53 m/min |
| Rotation | 180 Degree |
| Hoist Type | Electric Rope Hoist/Chain Hoist |
| Capacity –T | 0.25-5 |
|---|---|
| Lift Height – m | 3-40 |
| Drive Type | Electric Motor/Manual |
| Hoist Type | Wire Rope Hoist/Electric Chain Hoist/Manual Hoist |
| Radius – m | 2-8 |
| Lift Speed – m/min | 0-8/Customized |
| Traveling – m/min | 0-20/Customized |
| Rotation Speed-r/min | 0.76-0.53 |
| Rotation – Degree | 180 |
| Control way | Pendent / Remote Control |
| Working Tempreture | 40~+40℃ |
| Control Voltage | 24V/36V/48V |
Quality Control
Raw steel arrives with a Material Test Certificate and is spot inspected. Welders hold Class I international qualification. Girders are shot blasted to Sa2.5 before paint, and paint thickness is checked.
Customisation
Capacity, span, lifting height, duty group, power supply, control mode and service environment are all specified per order. Special products customisation is a standard service.
Documentation and Support
Equipment and main parts qualification certificates, electrical drawing diagram, installation operation and maintenance manual, and commissioning instructions ship with the equipment. Online support runs 24/7.
Use Guide
- Confirm the duty group. Count average lifts per hour and average load, not peak tonnage. This sets the FEM classification and drives the whole design.
- Check the building. Wheel load, headroom and hook approach decide whether the unit fits. Ask for the CAD drawing before ordering.
- Specify the environment. Temperature, dust, humidity and any hazardous area classification change the motor, brake and enclosure rating.
- Plan the power supply. Long travel needs a conductor rail or festoon system, which is quoted separately and must match the runway length.
- Book commissioning. Installation supervision or online commissioning support, plus operator training, before the unit goes into production.
Related Products
Wall-mounted-tie-rod-jib-cranes
- Capacity
- Up to 5 tons
- Lifting Height
- 3-10m
1-20-ton-din-overhead-crane
- Capacity
- 1~32 T
- Span
- ≤50M
Fem-overhead-crane
- Design Standard
- FEM/DIN/ISO
- Capacity
- 1 T -160T
Double-girder-overhead-shop-crane
- Capacity
- 5~800t
- Lift Height
- Max. 160m
Frequently Asked Questions
What information do you need to quote a wall-mounted-jib-crane?
Capacity, span rail centre to rail centre, lifting height, duty or working condition, power supply, travel distance and the service area conditions. A workshop drawing speeds it up considerably.
Can the wall-mounted-jib-crane be customised?
Yes. Sinomac provides a special products customisation service, and free production drawings for regional partners and clients buying crane kits.
How long does a quotation take?
A quotation is issued within 24 hours and a CAD drawing within 48 hours, both free of charge.
What testing is done before shipment?
Every hoist is pre-commissioned before packing and the crane is pre-assembled for a factory acceptance test. A third party inspection can be arranged at your request.
Are your cranes built to FEM and DIN standards?
Yes. Sinomac designs to FEM, DIN and ISO. Duty group is set from your real lifting cycle, so the classification on the nameplate matches how the crane is actually used.
Can you supply a crane kit instead of a complete crane?
Yes. Sinomac supplies hoist, end carriages, drives, control system and anti-sway as a kit, and provides free production drawings of the girder for regional partners and clients buying kits, which lowers shipping cost.
Request a Quotation for the Wall-mounted-jib-crane
Send capacity, span, lifting height and duty. A quotation follows within 24 hours.
