Double-girder-overhead-shop-crane
Electric double girder overhead shop crane is an important equipment to realize the mechanization and automation of the production process in modern industrial production and lifting transportation.It is widely used in indoor and
- Capacity
- 5~800t
- Lift Height
- Max. 160m
- Span
- 5~50m or Customized
- Work Duty
- M3~M8
- Protection Class
- IP54, IP65
- Working Temperature
- 40~+40℃
Quotation in 24 hours · CAD drawing in 48 hours · FEM / DIN / ISO design
Product Overview
<
p
>
Product Gallery
Technical Features
- Raw Material from Famous Steel Mills.
- CNC Cutting for Complete Cover Plate, Web Plate & Rib Plate, High Deflection Accuracy.
- High Quality Automatic Welding and NDT Inspection.
- Shot-blasting Sa2.5 to make sure the paint adhesion.
- The Main Girder with High Temperature Resistance can be working under the temperature up to 40℃
- Larger Span Main Girder (Over 12M) can be designed into high strength bolts connection with positioning hole, which can lower the shipment cost and easy to assemble the main girder.
- Thickness of Paint ≥ 120 μm.
- Adopted Planetary Gearbox with ABB Motor, Lowest Noises, Free Maintenance, Free Lubricant Oil Fill, Lower Headroom.
- Full Inverter (VFD) Drive. Inverter adopted Schneider Inverter Company
- The Hook Block adopted the forged hook, Material of hook: 35CrMo.
Where It Is Used
- Widely used in indoor and outdoor industrial and mining enterprises, iron and steel chemical industry, railway transportation, port and wharf, logistics and other places
- Galvanized Steel Rope adopted the crane industrial famous brand. High Strength 2160N/m2 with long Service Life and 1.8 times safety factor.
- Excellent and strong performance, suitable for a variety of harsh working environment
Specifications
Values below are the published standard configuration. Anything outside this range is a customisation question, not a catalogue lookup.
| Capacity | 5~800t |
|---|---|
| Lift Height | Max. 160m |
| Span | 5~50m or Customized |
| Work Duty | M3~M8 |
| Protection Class | IP54, IP65 |
| Working Temperature | 40~+40℃ |
Quality Control
Raw steel arrives with a Material Test Certificate and is spot inspected. Welders hold Class I international qualification. Girders are shot blasted to Sa2.5 before paint, and paint thickness is checked.
Customisation
Capacity, span, lifting height, duty group, power supply, control mode and service environment are all specified per order. Special products customisation is a standard service.
Documentation and Support
Equipment and main parts qualification certificates, electrical drawing diagram, installation operation and maintenance manual, and commissioning instructions ship with the equipment. Online support runs 24/7.
Use Guide
- Confirm the duty group. Count average lifts per hour and average load, not peak tonnage. This sets the FEM classification and drives the whole design.
- Check the building. Wheel load, headroom and hook approach decide whether the unit fits. Ask for the CAD drawing before ordering.
- Specify the environment. Temperature, dust, humidity and any hazardous area classification change the motor, brake and enclosure rating.
- Plan the power supply. Long travel needs a conductor rail or festoon system, which is quoted separately and must match the runway length.
- Book commissioning. Installation supervision or online commissioning support, plus operator training, before the unit goes into production.
