TTG And TIWP Rice Polisher
TTG and TIWP rice polishing machines finish the surface of milled rice.
What This Machine Does
TTG and TIWP rice polishing machines finish the surface of milled rice. With a blade shaped polish screen, bran powder is fully polished off, so the rice is cleaner, brighter and smoother to the touch. Polishing also improves resistance to oxidation, which extends the period the rice stays fresh.
Key Benefits
- Blade shaped polish screen removes bran powder completely from the grain surface
- Polished rice resists oxidation and keeps fresh longer
- Single roll and double roll structures with double roll machines connected in series
- Rice surface clean enough that washing before cooking is not required
- Capacity from 2.5 to 10 t/h across the two ranges
Problems It Solves
- Bran powder left on the grain dulls the appearance and shortens shelf life
- Rice that has to be washed before cooking loses value in the retail market
- Whitened rice that does not meet the buyer's appearance standard
- Capacity limits in the finishing stage of the line
Who It Is For
- Rice mills producing premium and export grades
- Processors packing retail rice
- Plants improving commercial value of existing output
- Line builders completing a milling section
Application Scenarios
- Final finishing stage after whitening
- Export rice where appearance decides the price
- Mills selling ready to cook rice
- Capacity upgrades using double roller machines
Technical Features
- Blade shaped polish screen for full bran powder removal
- Single roll and double roll structures available
- Water pressure 0.25 to 0.3 MPa for the mist system
- Air volume from 3500 to 5000 m3/h depending on model
- Double roller machines connected in series for large capacity
TTG And TIWP Rice Polisher Model Table
Figures below are taken from the TITAN model sheets. Where a figure depends on the crop or the contamination level it is stated that way rather than averaged.
| Model | Output | Power | Air volume | Weight |
|---|---|---|---|---|
| TTG7B | 4 to 8 t/h | 2 x (37 to 45) kW | 3500 to 4000 m3/h | 2400 kg |
| TTG12A | 6 to 10 t/h | 2 x (45 to 55) kW | 4000 to 5000 m3/h | 2750 kg |
| TMPG 158x2 | 5 to 8 t/h | 2 x (45 to 55) kW | 4000 to 5000 m3/h | 3100 kg |
| TIWP50 | 2.5 to 4 t/h paddy | 37 to 45 kW | Wind power 7.5 kW | 1500 kg |
| TIWP100 | 4 to 5 t/h paddy | 45 to 75 kW | Wind power 7.5 kW | 2000 kg |
How This Machine Is Built
Quality Control
- Water pressure system checked at 0.25 to 0.3 MPa
- Screen and roller clearance verified
- Machine run tested before packing
Materials And Wear Parts
- Polishing screens supplied as wear parts
Customisation Options
- Single or double roller configuration
- Screen specification per rice type
- Series connection for higher capacity
Use Guide
- Run polishing after whitening, not instead of it
- Keep water pressure in the 0.25 to 0.3 MPa range
- Replace polishing screens when surface finish drops
- Check the polished rice against the buyer's appearance sample regularly
How It Compares With The Alternatives
| Whitening alone | Whitening removes bran, polishing finishes the surface and extends freshness. |
|---|---|
| Single roll polisher | Double roll machines in series give large capacity with a gentler action per pass. |
TTG And TIWP Rice Polisher Questions
Does polishing reduce head rice?
Polishing works on the surface. Breakage is mostly decided at drying, husking and whitening, which is where to look if the broken rate rises.
What capacity is available?
4 to 10 t/h on the TTG range and 2.5 to 5 t/h of paddy on the TIWP range.
Why does polished rice keep longer?
Polishing improves anti oxidation performance by removing the bran powder that oxidises first.
Is water required?
The mist system operates at 0.25 to 0.3 MPa water pressure.
Which parts wear?
The polishing screens. TITAN supplies polisher and whitener screens from its own factory.
