Brush Wheel For Monforts Stenters 220 x 167
The large Monforts brush wheel at 220 by 167, the size most Monforts pin beds use.
Product Overview
The brush wheel presses the fabric onto the pins and keeps the pin bed clear of loose fibre. On a Monforts frame the large size is 220 by 167, and it is the size we sell most of across the whole brush range.
Bristle choice matters as much as size. We offer PP bristle, nylon for high temperature, brown pig hair, black pig hair and hard hair with glue, so the wheel can be specified for the chamber temperature and the article rather than taken as a single standard.
Key Benefits
- The standard large Monforts size at 220 by 167, held as running stock
- Five bristle options so the wheel matches chamber temperature and article
- Nylon bristle available specifically for high temperature positions
- Wheel body available in red, green and purple to code positions on the machine
Who It Is For
- Monforts users buying brush wheels as a routine consumable
- Maintenance stores holding one standard size across several frames
- Engineers specifying bristle type rather than accepting a default
Problems It Solves
- Cloth not being pressed fully onto the pins because the brush has worn down
- PP bristle deforming in a chamber position that runs hot
- Loose fibre building up in the pin bed and causing pin marks
Application Scenarios
- Monforts pin beds where the large brush wheel size is fitted
- Positions running hot enough that PP bristle softens
- Plants colour coding brush wheels by position or by change interval
Technical Features
- Size 220 by 167
- Bristle options: PP, nylon for high temperature, brown pig hair, black pig hair, hard hair with glue
- Wheel body colours: red, green, purple
- Made for Monforts stenter machines
Specifications
| Size | 220 x 167 |
|---|---|
| Machine | Monforts stenter |
| Bristle options | PP, nylon (high temperature), brown pig hair, black pig hair, hard hair with glue |
| Wheel colours | red, green, purple |
| Origin | Zhejiang, China |
| Lead time | within 7 days for standard items |
| Origin | Shaoxing, Zhejiang, China |
Quality Control
- Outside diameter and width measured on every wheel
- Bristle pull test on a sample from each batch
- Bore concentricity checked so the wheel runs true
Customisation Options
- Bristle type selected per position rather than per order
- Wheel colour chosen for position coding
- Non-standard sizes made from your sample wheel
Certifications. We make no certification claim for this part. The original company statement is that products comply with international quality standards; no certificate is named and none is asserted here. Ask us directly if your procurement process requires documentation.
Comparison With Other Options
Against the small Monforts wheel at 180 by 22, this is the main pressing wheel rather than a narrow auxiliary. Against PP bristle, nylon costs more but holds its form in high temperature positions, which is where PP fails first.
Use Guide
Record which bristle type is fitted at each position before ordering replacements
Set brush pressure so the cloth is fully seated on the pins without the brush riding the plate
Use nylon bristle where the position runs hot enough to soften PP
Replace wheels in matched sets across a position
Clear fibre from the wheel at every shift change on dusty articles
More Images
Additional Views
FAQ
Questions About Brush Wheel For Monforts Stenters 220 x 167
Which bristle should I choose?
PP is the general purpose option. Nylon is the one for high temperature positions. Brown and black pig hair and hard hair with glue are available where a stiffer or more natural bristle is wanted. Tell us the position temperature and the article and we will recommend.
What size is the large Monforts wheel?
220 by 167. We also make the small Monforts size at 180 by 22.
Why are wheels available in different colours?
Red, green and purple bodies let a plant code wheels by position or by change interval, which makes maintenance auditing much easier.
Can you make a size you do not list?
Yes, from a sample wheel. That is routine work.
What is the minimum order?
No fixed minimum. Most orders are by the set for a position.
Lead time?
Within 7 days for standard sizes.
