Heavy Truck Trailer 3 Axles Dump Semi Side Trailer 80ton Hydraulic Side Tipping Trailer
80 tonne hydraulic side tipping trailer on an Hg60 main beam with 12 twist locks.
Overview
What This Trailer Is Built For
An 80 tonne side tipping trailer built on an Hg60 high strength main beam, with twelve twist lock positions so the same chassis can carry containers as well as tip bulk. Overall dimension is 10500*2500*3100mm on three axles with mechanical spring suspension, 12R22.5 tires in 12 pieces and a 28T heavy capacity landing gear. Side tipping empties the load alongside the trailer rather than behind it, which is what road and trench work needs when there is no room to stand a body up at the rear.
Key Benefits
What You Get
- 80 tonne loading capacity puts this among the heaviest tipping trailers in the range
- Hg60 high strength main beam carries the bending load that an 80 tonne side tip creates
- Twelve twist lock positions let the chassis double as a container carrier between tipping jobs
- Side discharge places material directly along a trench or road edge in one pass
- 28T heavy capacity landing gear holds the loaded trailer safely when uncoupled
Problems Solved
What It Fixes
- Rear tipping needs clear space behind the trailer that roadworks rarely have
- Standard beams flex and crack under an 80 tonne side tipping load
- Separate container and tipping trailers double the fleet investment
- Light landing gear buckles under a loaded trailer when uncoupled
Who It Is For
Operators Who Buy This Model
- Road construction contractors placing material in line
- High-tonnage mine and quarry hauliers
- Operators who need one chassis for containers and bulk
- Pipeline and trenching contractors
Application Scenarios
Where It Works
- Road base and shoulder material placement along a carriageway
- Trench backfill where material must land beside the vehicle
- Mine and quarry haulage at high tonnage
- Alternating container and bulk work on the same chassis
Technical Features
Build Specification
- Loading capacity 80 tonnes
- Overall dimension 10500*2500*3100mm
- Main beam material Hg60 high strength steel
- Three axles with mechanical spring suspension
- 12R22.5 tires, 12 pieces
- 12 twist lock positions for container carriage
- 28T heavy capacity landing gear
Specifications
Manufacturer Data Sheet
| Loading Capacity | 80T |
|---|---|
| Overall Dimension | 10500*2500*3100 |
| Main Beam Material | Hg60 |
| Tire | 12R22.5 12pieces |
| Landing Gear | 28T heavy capacity |
Figures are taken from the SINOHENG data sheet for this model. Final dimensions and weights are confirmed on the approved order drawing.
Quality Control
Checks Before Dispatch
- Main beam weld inspection under the tipping mounts
- Hydraulic circuit pressure test and full tipping cycle
- Twist lock position and locking function check
- Brake and stability test before dispatch
Customization
What You Can Change
- Body volume and side height set to your material
- Axle and suspension brand chosen to suit local service
- Tire specification changed to local supply
- Twist lock layout arranged for 20 or 40 foot boxes
- Tipping angle and cylinder sizing matched to load density
Comparison
How It Compares
| Compared With | How This Model Differs |
|---|---|
| Rear tipping trailer | Side tipping places material beside the trailer where roadworks leave no rear clearance; rear tipping is more stable on soft ground. |
| Standard beam side tipper | The Hg60 main beam is specified for the bending that an 80 tonne side tip creates; ordinary beams fatigue at that load. |
| Dedicated container skeletal trailer | Twelve twist locks let this chassis carry containers between tipping jobs, which a tipping-only trailer cannot. |
Use Guide
Operating This Trailer
- Tip only on level, firm ground and never across a cross slope
- Confirm the discharge side is clear of people and structures before lifting
- Lower the body fully before moving off
- Check twist lock condition before container carriage
- Inspect the main beam around the tipping mounts at each service
Related Products
Related Trailers
Rear Flip Tipper Semi Trailer 40cubic 3 Axle Heavy Duty for Sale
40 cubic metre rear flip tipper, HYVA or China lifting brand, mechanical or air suspension.
View Specification
Heavy Duty Tipping Truck Trailer Dump Semi Trailer China Manufacturer
Gooseneck rear dump trailer, 30m3 body at 9600kg tare with a full HYVA 196 lifting set.
View Specification
Dump Tipper Semi-Trailer Bucket 6 Axles Tipper Truck Trailer China Factory Direct for Sale
Six-axle bucket dump tipper, 10500*2500*3800mm, 70 tonne payload on FUWA 16 tonne axles.
View SpecificationKnowledge
Related Guides
Four Reasons the Side Dump Truck Market Keeps Growing
Structure, load capacity, safety devices and cycle time: why side-unloading trailers have taken market share from conventional tippers.
FAQ
Questions About This Model
What Is the Loading Capacity
80 tonnes. Confirm the axle-load limits in your market, since the legal payload may be lower than the structural rating.
What Is the Main Beam Material
Hg60 high strength steel, specified for the bending that side tipping at this tonnage produces.
Can It Carry Containers
Yes. Twelve twist lock positions are fitted, so the same chassis can be used for container work between tipping jobs.
Is Side Tipping Safe on Uneven Ground
Side tipping needs level, firm ground and must never be done across a cross slope. Where site ground is poor, a rear tipper is the safer choice.
What Suspension Is Fitted
Mechanical spring suspension on three axles, with 12R22.5 tires in twelve pieces.
What Landing Gear Is Used
A 28T heavy capacity unit, which holds the trailer safely when uncoupled under load.
Is Customization Possible
Yes. Body volume, side height, axle brand, tire size and twist lock layout can all be set to your requirement before production.
