Wear Castings For Recycling And Demolition
Wear parts built for feed that contains steel as well as stone
What Makes Wear Parts Difficult In This Sector
- Chrome blow bars shattering on rebar in concrete feed
- Jaw dies flattening quickly on abrasive recycled material
- Tramp metal damage moving into frames because toggles were over-specified
- Mobile plant working far from any parts counter
The Requirements We Build Around
- Manganese grades that deform instead of cracking on tramp steel
- Toggle plates cast to the original break load
- Complete wear packages that ship together
- Mn22Cr2 and Mn22Cr3 for the most abrasive recycled feed
Typical Scenarios
- Concrete recycling with rebar in the feed
- Asphalt reclaim and road planings
- Demolition waste reduction
- Mobile crushing on urban sites
Product Families Used In This Industry
Where Most Enquiries In This Sector Start
Impact Crusher Blow Bar
Manganese, chrome, ceramic-insert and TIC-insert bars for horizontal shaft impactors
View Part →
Swing Jaw Plate
Movable jaw dies cast to the same profile and heat as the fixed half
View Part →
Jaw Crusher Toggle Plate
The designed weak point that protects the whole crusher from uncrushable feed
View Part →
Jaw Crusher Cheek Plate
Side liners that keep the crushing chamber square and protect the frame
View Part →Getting The Parts To Site
Finished parts are packed on steel pallets for forklift handling, to international standards for road, rail, sea and air. Door-to-door delivery to your warehouse is available.
Air Freight
Chongqing Jiangbei International Airport (CKG) is one of the largest airports in China, for parts that cannot wait.
Rail To Europe
Chongqing is the start of the Chongqing–Xinjiang–Europe railway, running through Kazakhstan, Russia, Belarus and Poland to Duisburg, Germany.
Sea Freight
Inland transport to Shanghai Port takes about three days, from where normal sea freight schedules apply.
Work Delivered Into This Sector
Swing Jaw Plate 600/3012 For A Pegson 1100 × 800 In Liberia
600/3012 swing jaw plate in Mn22Cr2
Read The Case →
Extec C10 Jaw Dies J6920000 And J6930000 In Mn18Cr2
J6920000 fixed jaw die and J6930000 swing jaw die in Mn18Cr2
Read The Case →
Repeat Cone Sets 603/9052 And 603/9106 For A Pegson 1000 Maxtrak
603/9052 bowl liner and 603/9106 mantle in Mn22Cr2
Read The Case →Recycling And Demolition Questions
Which blow bar material survives rebar?
High manganese. It deforms rather than shatters. Chromium bars last far longer on clean rock but are the wrong choice where steel reaches the rotor.
Why will you not supply a stronger toggle plate?
The toggle is the crusher's mechanical fuse. A toggle that does not break at the designed load moves the damage into the frame and the bearings.
Which jaw die grade for concrete recycling?
Mn18Cr2 or Mn22Cr2. Recycled feed is abrasive and dirty, and the higher manganese grades work harden further before deforming.
Discuss Your Recycling And Demolition Wear Parts
Tell us the machines, the feed and the wear life you are getting now. The material recommendation follows from those three answers.
