White Appliance Top Cover
Smooth white cover shell with a recessed control pocket and a clean parting line.
White Appliance Top Cover
White Appliance Top Cover is one of the parts molded on tooling built at our Dongguan shop. Smooth white cover shell with a recessed control pocket and a clean parting line.
Our engineering team reads customer mold standards and special requirements in English, so a specification written for a European or North American tool shop does not have to be rewritten for us.
The product surface finish review and the part and steel tolerance review both sit inside the DFM, so the finish and the tolerances are agreed in writing before the cavity is finished.
Key Benefits
- ISO 9001:2015 quality management covering design, manufacture and service
- CNC, EDM, grinding and CMM equipment under one roof
- Mold motion simulation on complex multi-action tooling
- Trial report with a sample dimension report (FAI) on delivery
Problems It Solves
- Molds that arrive with no design record and no one able to explain the cooling layout
- Mold base components that cannot be replaced locally once the tool is in production
- Weld lines landing on a visible face because gating was chosen for fill alone
Who It Is For
- Small domestic appliance brands
- Office equipment and printer OEMs
- Air treatment and climate product makers
- Contract manufacturers assembling finished appliances
Application Scenarios
- Top covers and housings on visible product faces
- Grilles, louvres and vent panels
- Chassis and base panels carrying assemblies
- Handles, bezels and internal frame rails
How the Tool Behind White Appliance Top Cover Is Built
- Design
Full 3D mold design completed to one hundred percent and checked in a design review meeting.
- DFM and MoldFlow
A written DFM for your comment, and filling, packing, warpage and cooling analysis on mass production tools.
- Machining
CNC and EDM work with steel inspected dimensionally after machining and electrodes inspected before burning.
- Trial and inspection
Mold trial with trial report and sample dimension report, then final mold and packing inspection.
Technical Data
The source material for this site records the part, its category and the photograph. Dimensions, resin grade, cavity count and tolerances are project data and are confirmed in the quotation.
| Product name | White Appliance Top Cover |
|---|---|
| Reference on our catalogue | OA Part 2 |
| Category | Home & Office Appliance Parts |
| Process | Plastic injection molding |
| Tooling built by | Dongguan JEC Mold Co., Limited, Dongguan, China |
| Designed tool life | More than 1 million shots |
| Mold standard | Customer standard, or DME / Meusburger / HASCO / Progressive / MISUMI |
| Design data formats | STEP, IGES, Parasolid, CATIA, SolidWorks |
| Quality system | ISO 9001:2015 — Design, Manufacture and Service of Injection Molded Moulds; Manufacture and Service of Plastic Injection Molded Parts |
| Part dimensions | TBC — confirmed in the quotation |
| Resin or alloy grade | TBC — confirmed in the quotation |
| Cavity count | TBC — confirmed in the quotation |
| Dimensional tolerance | TBC — confirmed in the quotation |
| Surface finish | TBC — confirmed in the quotation |
| Annual volume | TBC — confirmed in the quotation |
What Is Checked
- Customer mold specification and requirement review and discussion during the kick-off meeting
- 3D and 2D mold design review meeting before the design is sent to you, and a final check before fabrication
- Incoming material inspection
- Steel hardness inspection and steel certification
- Electrode dimension and surface finish inspection
- Steel dimension inspection after machining
- Mold trial reports with a sample dimension report (FAI)
- Final mold inspection and packing inspection
Certification
ISO 9001:2015 — scope: Design, Manufacture and Service of Injection Molded Moulds; Manufacture and Service of Plastic Injection Molded Parts.
Customization
Mold standard, cavity count, gating strategy, surface finish and mold base supplier are all specified per project. Tell us what your own standard requires and it is folded into the DFM rather than handled as a change later.
Compared With a Prototype Tool
A production mold for White Appliance Top Cover is built to run for more than 1 million shots and is documented with a trial report and a sample dimension report. A rapid prototype mold answers a different question — is the design right — at a lower price and a faster lead time, and is not built for that life. If the design is still moving, the prototype stage is usually the cheaper route into the production tool.
Rapid Prototype MoldsUse Guide
- Send 3D part data in STEP, IGES, Parasolid, CATIA, SolidWorks
- State the resin or alloy, the annual volume and the mold standard
- Comment on the DFM before fabrication — that is the cheapest point to change anything
- Review the trial report and sample dimension report against your own drawing before release
- Keep the mold standard on file so spares stay available locally
Others in Home & Office Appliance Parts
Appliance Front Grille Panel
White frame panel carrying a fine louvre grille and snap features on both ends.
View details →
Appliance Curved Handle Cover
Long curved white cover with a sweeping Class-A face and hidden fixing bosses.
View details →
Vented Appliance Housing
White housing shell with a circular top aperture and a molded ventilation louvre bank.
View details →
Appliance Chassis Base Panel
Large flat light-grey base panel with stiffening ribs and multiple mounting pads.
View details →White Appliance Top Cover — Buyer Questions
How are molds packed for export?
Final mold inspection is followed by a packing inspection before the tool leaves. Ninety percent of our molds go to overseas markets, so export packing is the normal case here rather than the exception.
Who do we talk to during the project?
Our engineering team has been trained on customer mold standards and corresponds in English. Response to customers is no later than 24 hours.
Are you certified?
Yes — ISO 9001:2015, with the scope recorded on the certificate as: Design, Manufacture and Service of Injection Molded Moulds; Manufacture and Service of Plastic Injection Molded Parts. The certificate is shown on our quality page.
Do you make the part as well as the mold for White Appliance Top Cover?
We can. Mold-making is ninety percent of our business and injection production is the other ten percent, and both sit inside the same ISO 9001:2015 scope.
Quote White Appliance Top Cover
Send the 3D data, the resin and the annual volume. A professional quotation with technical comment comes back within two working days.
