Low Flat/Flatbed Semi-Trailer LHL9374TDP China Manufacturer Directly for Sale
LHL9374TDP with a 700mm deck height, long 8920mm wheelbase and four deck length options.
Overview
What This Trailer Is Built For
The LHL9374TDP sits on the lowest standard deck in the range at 700mm or 800mm above ground, which gives the most clearance headroom for tall machinery on height-restricted routes. Deck lengths are 12990mm, 12500mm, 12000mm and 11600mm on a 3000mm width, at 37000kg total weight and 21000kg over three axles. The long 8920+1060+1060mm wheelbase and tight 1060mm axle spacing keep the load spread forward, and the approach and departure angle is 32 degrees.
Key Benefits
What You Get
- 700mm deck height is the lowest standard setting here, giving the most room under bridges and cables
- Long 8920+1060+1060mm wheelbase places more load over the tractor and less on the rear overhang
- Four deck lengths from 11600mm to 12990mm cover most mid-size plant without over-specifying
- 32 degree angle at both ends clears low-slung machines during loading
- Tight 1060mm axle spacing reduces tire scrub in tight turns
Problems Solved
What It Fixes
- Standard lowbeds leave tall machines a few centimetres over the height limit
- Load carried too far back overloads the rear axles and lightens the kingpin
- Wide axle spacing scrubs tires in tight site turns
- Shallow ramp angles ground low-clearance machines
Who It Is For
Operators Who Buy This Model
- Heavy haulage operators on height-restricted corridors
- Contractors moving tall drilling and piling equipment
- Plant hire fleets carrying machines close to the height limit
- Operators who repeatedly apply for over-height permits and want to stop
Application Scenarios
Where It Works
- Transporting tall machines under low bridges and overhead cables
- Moving excavators and drilling rigs on height-restricted routes
- Industrial equipment relocation with tight overall height limits
- Plant transport where clearance matters more than deck length
Technical Features
Build Specification
- Low-bed semi-trailer, total weight 37000kg
- Length x width x height 12990, 12500, 12000 or 11600 x 3000 x 3100, 3300 or 3500mm
- Deck height 700mm or 800mm above ground
- Wheelbase 8920+1060+1060, 8500+1060+1060 or 8110+1060+1060mm
- Axle load 21000kg over three axles, rear suspension 950mm
- Approach and departure angle 32 degrees
- 12 tires in 8.25R20 14PR or 235/75R17.5 16PR, rear wheel base 2330 or 2400mm
Specifications
Manufacturer Data Sheet
| Type | Low-bed semi-trailer |
|---|---|
| Dimensions L x W x H | 12990,12500,12000,11600x3000x3100,3300,3500 |
| Total Weight | 37000 |
| Approach / Departure Angle | 32 |
| Front/Rear Suspension | 950 |
| Wheelbase | 8920+1060+1060,8500+1060+1060,8110+1060+1060 |
| Axle Load | 21000(three axes) |
| Number of Spring Pieces | 4/4/4,-/8/8/8 |
| Number of Tires | 12 |
| Tire Specifications | 8.25R20 14PR,235/75R17.5 16PR |
| Rear Wheel Base | 2330/2330/2330,2400/2400/2400 |
Figures are taken from the SINOHENG data sheet for this model. Final dimensions and weights are confirmed on the approved order drawing.
Quality Control
Checks Before Dispatch
- Deck height measured on the finished trailer, not calculated from drawings
- Main beam camber checked after welding on the long deck
- Axle spacing and alignment verified as a set
- Brake and roll test before dispatch
Customization
What You Can Change
- Deck length 12990mm, 12500mm, 12000mm or 11600mm
- Deck height 700mm or 800mm
- Wheelbase selected from three settings
- Tire size 8.25R20 14PR or 235/75R17.5 16PR
- Spring pack 4-leaf or 8-leaf per axle
Comparison
How It Compares
| Compared With | How This Model Differs |
|---|---|
| LHL9383TDP | The 9374 has a lower 700mm deck for maximum clearance; the 9383 has a steeper 33 degree departure angle for difficult loading. |
| Six-axle lowbed | The 9374 solves height problems, the six-axle model solves axle-load problems. Choose by which restriction binds on your route. |
| Extendable lowbed | A fixed deck is cheaper and needs less maintenance; an extendable deck is only worth it for occasional over-length loads. |
Use Guide
Operating This Trailer
- Measure the loaded height of your tallest machine before selecting the deck height
- Load so the machine sits over the forward part of the deck
- Keep the gooseneck free of cargo
- Check ground clearance under the low deck on rough site accesses
- Inspect the deck underside for strike damage after off-road work
Related Products
Related Trailers
Low Flatbed/Low Bed Semi-Trailer Direct sales from China factory
LHL9382TDP three-axle lowbed with 13750mm deck option, 8090mm wheelbase and 1300mm rear overhang.
View Specification
Low Flatbed Semi-Trailer LHL9381TDP China Factory for Sale
LHL9381TDP lowbed with a raised 3200-3700mm profile and tire-linked deck heights from 880mm.
View Specification
Low Flatbed/Bed Six-Axle Semi-trailer LHL9380TDPA China Customizable
Three-line six-axle lowbed with 7000kg per line, 24 tires and deck heights from 750mm.
View SpecificationKnowledge
Related Guides
Flatbed Trailer and Lowbed Trailer Compared
Flatbeds and lowbeds both have open platforms and are easily confused. The structural difference decides which one your cargo can legally travel on.
FAQ
Questions About This Model
How Low Is the Deck
700mm or 800mm above ground, which is the lowest standard deck in this range and gives the most clearance for tall machines.
What Deck Lengths Are Available
12990mm, 12500mm, 12000mm and 11600mm, all on a 3000mm width.
What Is the Wheelbase
8920+1060+1060mm, 8500+1060+1060mm or 8110+1060+1060mm. The long setting shifts more load onto the tractor.
What Total Weight Can It Carry
37000kg total weight with 21000kg across the three axles.
Will a Low Deck Ground Out on Site
It can on rough accesses. Where site ground is uneven, the higher deck setting or a model with a steeper ramp angle is usually the better choice.
What Tires Does It Use
Twelve tires in 8.25R20 14PR or 235/75R17.5 16PR.
Do You Supply Spare Parts Later
Yes. Spare parts supply is guaranteed for the whole service life of the trailer, however long ago it was bought.
Get A Price For The Low Configuration You Need
Send your country of use, cargo, load weight and axle limits. We confirm the configuration and quote FOB or CIF in one to three days.
