Low Flatbed/Low Bed Semi-Trailer Direct sales from China factory
LHL9382TDP three-axle lowbed with 13750mm deck option, 8090mm wheelbase and 1300mm rear overhang.
Overview
What This Trailer Is Built For
The LHL9382TDP is the long-deck member of the three-axle lowbed range, offered at 13750mm, 12990mm or 12500mm deck length on a 3000mm width, all on a single 8090+1300+1300mm wheelbase. Total weight is 38000kg with 21000kg over the three axles. Deck height can be built at 880, 930, 980, 1030 or 1100mm. The departure angle is 24 degrees and the rear overhang 1300mm. Without the optional ladder the overall height is 1750mm. Reflective markings are already fitted to the side and rear.
Key Benefits
What You Get
- 13750mm deck carries long plant such as pipe-layers and long-boom excavators that will not fit a 12m deck
- One 8090+1300+1300mm wheelbase across all three deck lengths keeps axle loading predictable
- Five deck heights from 880mm to 1100mm let you tune the loaded height to your route
- Reflective markings fitted to the side and rear as delivered, which most roadworthiness checks look for
- Optional ladder can be left off to keep overall height at 1750mm
Problems Solved
What It Fixes
- A 12m deck forces long machines to overhang, which is often refused on public roads
- Mixed wheelbases across a lowbed fleet make axle-load planning inconsistent
- Trailers delivered without reflective markings fail roadworthiness inspection
- A fixed ladder adds height that can matter on low-clearance routes
Who It Is For
Operators Who Buy This Model
- Heavy haulage operators carrying long machines
- Pipeline and civil contractors with oversized plant
- Plant hire fleets moving two machines per trip
- Dealers delivering long equipment from port to site
Application Scenarios
Where It Works
- Long-boom excavator and pipe-layer transport
- Moving multiple mid-size machines on one deck
- Prefabricated structure and steelwork delivery
- Plant relocation for pipeline and road construction projects
Technical Features
Build Specification
- Low-bed semi-trailer, total weight 38000kg
- Length x width x height 13750, 12990 or 12500 x 3000 x 1750, 3100, 3300 or 3500mm
- Wheelbase 8090+1300+1300mm, rear suspension 1300mm
- Axle load 21000kg over three axles, departure angle 24 degrees
- 12 tires in 8.25R20 14PR, 8.25R16LT 18PR or 235/75R17.5 16PR
- Rear wheel base 2180, 2250 or 2330mm, spring pieces 4/4/4 or 8/8/8
- Deck height 880, 930, 980, 1030 or 1100mm above ground
Specifications
Manufacturer Data Sheet
| Type | Low-bed semi-trailer |
|---|---|
| Dimensions L x W x H | 13750,12990,12500x3000x1750,3100,3300,3500 |
| Total Weight | 38000 |
| Approach / Departure Angle | 24 |
| Front/Rear Suspension | 1300 |
| Wheelbase | 8090+1300+1300 |
| Axle Load | 21000(Three axes) |
| Number of Spring Pieces | 4/4/4,-/8/8/8 |
| Number of Tires | 12 |
| Tire Specifications | 8.25R20 14PR,8.25R16LT 18PR,235/75R17.5 16PR |
| Rear Wheel Base | 2180/2180/2180,2250/2250/2250,2330/2330/2330 |
Figures are taken from the SINOHENG data sheet for this model. Final dimensions and weights are confirmed on the approved order drawing.
Quality Control
Checks Before Dispatch
- Long main beams checked for camber and straightness after welding
- Deck length and height verified against the order drawing
- Reflective marking placement checked before dispatch
- Axle alignment and brake test on the completed trailer
Customization
What You Can Change
- Deck length 13750mm, 12990mm or 12500mm
- Deck height chosen from 880 to 1100mm
- Ladder fitted or omitted to control overall height
- Exposed or unexposed tire arrangement
- Loading surface style selected to suit tracked or wheeled plant
Comparison
How It Compares
| Compared With | How This Model Differs |
|---|---|
| LHL9383TDP | The 9382 offers a longer 13750mm deck on a single wheelbase; the 9383 offers a steeper 33 degree departure angle for difficult loading. |
| Extendable lowbed | A fixed 13750mm deck is simpler and cheaper to maintain; an extendable deck handles occasional loads longer than 13.75m. |
| Flatbed semi-trailer | The lowbed keeps tall machines under height limits; a flatbed carries containers and palletised cargo more efficiently. |
Use Guide
Operating This Trailer
- Position the machine so its weight sits over the axle group, not the rear overhang
- Check loaded height and length against route restrictions before departure
- Keep the gooseneck clear of cargo
- Confirm reflective markings are clean and undamaged before each trip
- Inspect the spring packs after heavy off-road loading
Related Products
Related Trailers
Low Flatbed Semi-Trailer LHL9381TDP China Factory for Sale
LHL9381TDP lowbed with a raised 3200-3700mm profile and tire-linked deck heights from 880mm.
View Specification
Low Flatbed/Bed Six-Axle Semi-trailer LHL9380TDPA China Customizable
Three-line six-axle lowbed with 7000kg per line, 24 tires and deck heights from 750mm.
View Specification
Low Flatbed Semi-trailer LHL9375TDP Direct Sale from Chinese Factories
LHL9375TDP short-deck lowbed, 11000 or 10500mm, 37000kg gross and four wheelbase settings.
View SpecificationFAQ
Questions About This Model
How Long Is the Deck
13750mm, 12990mm or 12500mm, all on the same 8090+1300+1300mm wheelbase. The 13750mm option is the one to choose for long machines.
What Is the Departure Angle
24 degrees on this model. If your machines have low ground clearance, the LHL9383TDP at 33 degrees may load more easily.
What Is the Height Without the Ladder
1750mm. The ladder is optional, so you can leave it off where overall height is tight.
Are Reflective Markings Included
Yes. Vehicle reflective markings are installed on the side and rear before the trailer leaves the factory.
Can the Tires Be Enclosed
Yes. Both exposed and unexposed tire arrangements are available, along with a choice of loading surface styles.
What Is the Axle Load
21000kg across the three axles, within a 38000kg total weight.
Can You Ship It in a Container
A trailer of this length usually moves by bulk or roll-on roll-off. We confirm the method and quote FOB or CIF with the order.
