Product Overview
CHY200 Hydraulic Welder for Aluminium Strip and Wire
The CHY200 is the hydraulic machine specifically designed for rectangular strip as well as round wire. It welds copper, aluminium and other non-ferrous wire, covering copper from 2.00 mm to 5.00 mm and aluminium from 2.00 mm to 8.00 mm at 6.5 MPa, driven by a 1.5 kW motor in a 650 × 560 × 1000 mm frame at 230 kg.
Specifications
- Hydraulic pressure welding machine ModelCHY200
- Copper wire2.00mm-5.00mm
- Aluminium wire2.00mm-8.00mm
- DimensionL650mm*W560mm*H1000mm
- Net weight230kgs
- Motor power1.5KW
- Working pressure6.5MPa
- Operating voltageaccording to the customer's industrial voltage in your country.
- Packagepacked in strong wooden case.
Key Benefits
What This Model Gives You
Built for Rectangular Strip
Not an exception on the datasheet — strip is what this machine is designed for.
230 kg and 650 mm Long
The lightest and most compact hydraulic machine in the range, so it fits on a busy floor.
1.5 kW at 6.5 MPa
Low installed power with the full hydraulic working pressure.
Non-Ferrous Generally
Rated for copper, aluminium and other non-ferrous wire.
Application Scenarios
Where It Is Used
- Aluminium strip and busbar
- Transformer winding strip
- Medium-section copper wire
- Rectangular conductor production
Industries
Problems It Solves
Why Buyers Specify It
- Round-wire dies cannot upset a rectangular section evenly
- Strip joints made by brazing anneal the section
- A full-size hydraulic press is more machine than a 5 mm section needs
Compared With Other Models
The CHY200-B is the heavier 380 kg build reaching 6.00 mm copper, with rectangular sections subject to evaluation. This CHY200 is the 230 kg machine designed specifically for rectangular strip, at 6.5 MPa.
Use Guide
How It Is Set Up and Run
- Send the strip dimensions — the range for rectangular sections is calculated from the cross-sectional area.
- Fit CHY200 dies cut for the section.
- Set the working pressure to 6.5 MPa.
- Weld, shear the flash and pull-test the first joint of the batch.
Customisation and Supply
What Is Built to Order
Dies to Your Wire
Dies are manufactured for wire between 0.10 mm and 25.0 mm to suit round or profile wire and rod, to the customer's own specification, at -1% / +2% of the wire diameter.
Your Electrical Supply
On the motorised and hydraulic machines, operating voltage is built to the industrial supply of the destination country. State voltage, phase and frequency with the order.
Export Packing
Machines are packed in a strong wooden or plywood case as stated per model. Carry cases are supplied with the portable welders and the DA10.
Related Articles
Background Reading
Related Products
Others in Hydraulic Pressure Welders
Hydraulic Pressure Welders
CHY200-B Hydraulic Pressure Welding Machine
Copper 2.00-6.00 mm and aluminium 2.00-8.00 mm on a 380 kg frame with a 1.5 kW motor.
View specifications
Hydraulic Pressure Welders
CHY400-B Hydraulic Pressure Welding Machine
Copper 4.00-9.00 mm and aluminium 4.00-12.00 mm, supplied 3P 380 V 50 Hz on a 760 kg frame.
View specificationsFAQ
CHY200 Hydraulic Welder for Aluminium Strip and Wire Questions
Can it really weld rectangular strip
Yes. The CHY200 is designed for rectangular strip as well as wire.
How is the strip range calculated
The range for rectangular non-ferrous wire is calculated according to the cross-sectional area.
What voltage is it built for
According to the customer's industrial voltage in their country.
How is it packed
In a strong wooden case. Net weight is 230 kg.
Quote the CHY200 Hydraulic Welder for Aluminium Strip and Wire
Give the wire material, the diameter and the country the machine will run in, and the quote comes back with the die set and the voltage build already decided.
