Single-Bowl Feeder · PB-F500W
5L Smart Pet Feeder In White
The volume seller: five litres, sealed freshness, app scheduling. Manufactured in our own Shenzhen facility with food-grade materials and full CE, FCC and RoHS documentation.
- 5L large capacity, no frequent refills
- Anti-jam design for all food types
- Sealed lock-fresh system, moisture-proof
- APP remote control for schedules
- Uninterrupted feeding during outages
CAD and 3D files are shared on request via WhatsApp after a mutual NDA.
Product Overview
What This Model Is Built To Do
Experience the future of pet care with the PAWBILT 5L Smart Pet Feeder. This innovative device takes the hassle out of feeding time through its advanced automation technology and intelligent design. The generous 5-liter capacity ensures your pets are always cared for, while the sophisticated system guarantees precise meal distribution at scheduled times. This represents the next evolution in intelligent pet feeder technology.
Advanced Engineering for Perfect Performance
Beyond basic functionality, this feeder incorporates groundbreaking anti-jam technology that prevents food blockages and ensures consistent portion control. The sealed lock-fresh system creates a completely airtight environment, effectively blocking moisture and preserving food freshness for extended periods. Every component is crafted with precision engineering to deliver unmatched reliability in automatic feeding solutions.
Key Benefits
Technical Features In Detail
01
5L large capacity, no frequent refills
02
Anti-jam design for all food types
03
Sealed lock-fresh system, moisture-proof
04
APP remote control for schedules
05
Uninterrupted feeding during outages
06
Easy to maintain and clean
Who It Is For
Buyers Who Choose This Model
Brands needing a dependable core SKU
Retail chains at the mainstream price point
Distributors ordering full containers
Private label programmes starting their range
Problems It Solves
Issues This Design Removes
- Ranges that lack a reliable mid-volume anchor
- Feeders that stale food within a week
- High return rates on unreliable dispensing
- Buyers who need volume pricing at moderate MOQ
Application Scenarios
Where This Model Sells
Cats and small to medium dogs
Mainstream retail shelf
Bundle and promotion campaigns
Baseline of a brand ladder
Specifications
Standard Configuration
Every line below can be changed on an ODM project. Capacity, colour, camera module, app branding and packaging are the parameters buyers adjust most often.
| Food capacity | 5 L |
|---|---|
| Colour | White, custom colours from 3000 units |
| Schedule | Up to 10 meals per day |
| Portion | 10 g per portion, tolerance +/- 2 g |
| Seal | Silicone-sealed lid with desiccant seat |
| Connectivity | Wi-Fi 2.4 GHz |
| Power | DC 5 V plus 3 x AA backup |
| Food contact material | Food-grade ABS and PP |
| Anti-jam | Reverse-rotation auger |
| Net weight | 2.2 kg |
| Certification | CE, FCC, RoHS |
Materials And Quality
- Food contact parts in food-grade ABS and PP with material certificates on file
- Silicone sealing ring on the hopper lid, tested for 5000 open and close cycles
- 100 percent function test and 24-hour ageing test before packing
- Drop test at 80 cm on six faces in export carton
- Batch records retained for two years for traceability
Product Detail
Structure And Finish
Factory photography of the housing, dispensing path and control panel. These are the images your marketing team can localise for listings and retail packaging.
Manufacturing Process
How This Unit Is Made
Housing parts are moulded in our own mould workshop, so a tooling change on an ODM project does not depend on an outside supplier's queue. PCBA, assembly, ageing and packing all happen in the same building, which keeps the feedback loop between a test failure and a process fix down to hours.
Customisation Options
What You Can Change On This Model
Logo And Colour
Silk screen, pad print or IML logo. Custom Pantone colour from 3000 units.
App And Brand
Your brand name, icon and colour scheme inside the app, plus your own account system.
Packaging
Full colour retail box, manual, insert design and barcode to your market standard.
Hardware Changes
Camera module, capacity, bowl material and motor specification adjusted on ODM projects.
Certification
CE, FCC, RoHS, UKCA, PSE and additional test reports arranged for your destination market.
Firmware
Feeding logic, alert wording and language packs adjusted for your market.
Comparison
How This Model Compares
| Model | Capacity | Camera | Best For |
|---|---|---|---|
| 5L Feeder White This model | 5L | No | Cats and small to medium dogs |
| 3L Smart Feeder | 3L | No | Kittens, small cats, toy breeds |
| 4L Smart Feeder | 4L | No | Apartment households |
| 5L Feeder Black | 5L | No | Design-led retail |
Need a side-by-side on parameters not shown here, such as motor torque or carton dimensions? Ask on WhatsApp and we will send the full comparison sheet.
Use Guide
Setup In Four Steps
- 1
Unpack And Wash
Remove the hopper, bowl and rotor. Wash with warm water and dry fully before the first fill. Do not put electronic parts under a tap.
- 2
Connect Power And App
Plug in the DC adapter, install the backup batteries, then scan the code in the manual to pair over Wi-Fi. Keep the phone on the same network during pairing.
- 3
Set The Feeding Plan
Create meals in the app with time and portion count. Start with the portion size stated on the food packaging and adjust after the first week.
- 4
Check And Maintain
Rinse the bowl daily, wash the hopper monthly and replace filters or desiccant on the schedule in the app.
Answers
5L Feeder White Questions From Buyers
What makes the Pawbilt 5L Smart Pet Feeder stand out?
It features a 5L capacity with an anti-jam, sealed design.
Can it handle different types of food?
Yes, the anti-jam design works with dry or wet food.
How do I set a feeding schedule?
Use the APP for remote control and customized plans.
What if the power goes out?
Uninterrupted feeding ensures meals during outages.
Is it easy to keep clean?
Yes, designed for easy maintenance and hygiene.
Is this available for wholesale?
Yes, contact us for wholesale options
What is the minimum order quantity
The standard MOQ for the 5L Feeder White is 500 units in a stock colour and 3000 units for custom tooling or a new colourway. Sample orders start at one unit.
Can we put our own brand on this model
Yes. Logo printing, custom colour, app skin, retail packaging and manual design are all available. Full ODM changes to the housing require tooling.
How long is production
Around 15 days for stock configurations after the deposit clears, and 25 to 35 days for private label runs that need printed packaging.
Next Step
Ready To Quote The 5L Feeder White
Send your target quantity, destination market and any branding requirement. You will get pricing, lead time and the full specification sheet within one working day.
Replies within 24 hours on working days. No enquiry forms, we answer on WhatsApp and email directly.
