Slatted Floors
LW Plastic Slat
LW-series PP slat floor with wide drainage gaps and a saw-tooth anti-slip face, made in spans from 200 to 600 mm.
PP / HDPE600×400 / 600×500 / 600×600 mmAnti-slip surface
Product Overview
The LW plastic slat is the general-purpose floor of the JGM range. It is injection-moulded in high-density polypropylene with a saw-tooth anti-slip surface and wide, round-edged drainage gaps, so manure and water leave the pen without a hose in most rooms.
Panels lock together on the long edges and sit on FRP or concrete beams at 200, 400, 500 or 600 mm spans. The B versions are built for sow weight; the C version has a closed edge where the floor meets a wall or a pen boundary. Colour is produced to customer requirement.
Technical Features
- Injection-moulded high-density polypropylene
- Saw-tooth anti-slip top surface
- Round-edged drainage gaps that protect claws
- Interlocking long edges for a continuous floor
- Sow (B) and closed-edge (C) versions in the same series
- Colour produced to customer requirement
Made by the factory that sells it.
Injection-moulded polypropylene, produced on our own lines in Ningbo and shipped flat-packed for container export.
Application Scenarios
- Farrowing rooms
- Nursery / weaner pens
- Grow-finish housing
Used In
Key benefits
Why Buyers Specify This Product
Drainage without daily hosing
Wide, round-edged gaps let manure and urine pass on hoof pressure alone, which cuts washdown water and labour in the dunging area.
Grip that does not polish away
The saw-tooth surface is moulded into the panel, not applied to it, so the anti-slip texture stays after years of cleaning.
One floor, four spans
600×200, 600×400, 600×500 and 600×600 mm share the same edge profile, so a room can mix spans over different beam layouts without special parts.
Loading quantities already worked out
Every code has a published carton size and 40 ft / 40 ft HQ piece count, so freight can be costed before the order is placed.
Problems It Solves
Concrete floors stay wet and cold
A slatted floor drops the slurry into the pit instead of holding it against the animal, so bedding stays drier and room temperature is easier to hold.
Slippery floors injure young stock
The moulded saw-tooth face gives grip on a wet surface without the sharp edges that damage claws.
Metal floors corrode under washdown
PP does not rust or scale, so a high-pressure gun and a disinfectant cycle do not shorten the floor's life.
Who It Is For
- Pig producers building or re-flooring nursery and grow-finish rooms
- Turnkey house builders who need one floor system across several room types
- Distributors stocking a general-purpose slat in container quantities
One-factory supply
Flooring, penning, feeding, water and climate are made on the same site, so a room can be specified and shipped as one order.
See the turnkey packageSpecifications
Sizes Codes and Materials
Figures below are taken from the JGM product catalogue. Anything we cannot source from it is marked TBC and confirmed with your quotation rather than estimated.
| Item | Specification |
|---|---|
| LW6020 | 600 × 200 mm (span 200) |
| LW6040 | 600 × 400 mm (span 400) |
| LW6050 | 600 × 500 mm (span 500) |
| LW6060 | 600 × 600 mm (span 600) |
| LW6020B / LW6040B | Sow (B) version |
| LW6040C | Closed-edge (C) version |
| Material | PP / HDPE |
| Colour | To customer requirement |
| Packing | Quantity |
|---|---|
| LW6040 | Bagged 4 pcs · 600×400×200 mm · 220 pcs per pallet · approx. 4,480 pcs per 40 ft, 5,100 pcs per 40 ft HQ |
| LW6050 | Bagged 4 pcs · 600×500×230 mm · 176 pcs per pallet · approx. 3,400 pcs per 40 ft, 3,800 pcs per 40 ft HQ |
| LW6060 | Bagged 4 pcs · 600×600×210 mm · 180 pcs per pallet · approx. 3,000 pcs per 40 ft, 3,400 pcs per 40 ft HQ |
| LW6020 | Bagged 8 pcs · 600×400×200 mm · approx. 10,400 pcs per 40 ft, 11,600 pcs per 40 ft HQ |
| LW6040B | Bagged 4 pcs · 600×400×220 mm · approx. 3,680 pcs per 40 ft, 4,100 pcs per 40 ft HQ |
| LW6040C | Bagged 4 pcs · 600×400×240 mm · approx. 3,480 pcs per 40 ft, 4,080 pcs per 40 ft HQ |
Ask for the full size chart and carton-loading data for your order.
Materials and Manufacturing
Injection-moulded polypropylene. The LW Plastic Slat is injection-moulded on JGM's own presses in Ningbo. Polypropylene granulate is dried, dosed and shot into a steel tool, so the part that leaves the press is the part the tool was cut for — there is no secondary forming stage where the dimension can drift. Colour is added as masterbatch at the press, which is why colour goes all the way through the part instead of sitting on it as a coating.
Customisation Options
- Sizes and sections produced to customer requirement on a full-container order
- Colour matched to your existing equipment where the material allows
- Lengths cut to your room rather than to a catalogue dimension
- OEM and private-label production accepted
- Packing and carton marking to your import requirements
Quality Control
- First-off part from every tool change checked against the drawing before the run continues
- Shot weight monitored through the run as the check on wall thickness and fill
- Surface and edge inspection on every part as it is packed
- Assembled items function-checked before boxing
Certifications. We do not publish certification claims we cannot evidence.
Tell us what your market requires and we will confirm in writing what can be supplied for this product.
Comparison
How It Compares With Other JGM Products
| Alternative | When to choose it instead |
|---|---|
| LWD Fine-Gap Plastic Slat | Choose the LWD fine-gap slat instead when the room holds piglets and foot protection matters more than maximum drainage area. |
| Waterdrop (LWS) Plastic Slat | Choose the LWS waterdrop slat when you want rounded perforations and the fastest washdown in farrowing and nursery pens. |
| Cast Iron Slat | Add cast iron in the dunging zone of the same room where wear and weight are highest. |
Use guide
Installing and Running It
Step 1
Set FRP or concrete beams at the span printed on the panel code — a 600×400 panel needs support at 400 mm centres.
Step 2
Lay panels with the interlock along the beam run and finish the pen edge with a closed-edge C panel or a U-channel.
Step 3
Leave the manufacturer's expansion allowance at the room ends; PP moves slightly between day and night temperature.
Step 4
Wash down with a high-pressure gun at the normal angle; no sealing or coating is needed before first use.
Answers
LW Plastic Slat FAQs
What beam spacing does each LW panel need?
The last two digits of the code are the span in millimetres. LW6040 spans 400 mm, LW6050 spans 500 mm and LW6060 spans 600 mm, so beams are set at that centre distance.
Can I get the slats in a colour other than blue?
Yes. Colour is produced to customer requirement — the catalogue codes are supplied in the colour agreed for your order.
How many slats fit in a 40 ft container?
It depends on the code: roughly 4,480 pcs of LW6040, 3,400 pcs of LW6050 and 3,000 pcs of LW6060 in a standard 40 ft, with higher counts in a 40 ft high cube.
What is the difference between the B and C versions?
B is the sow version, built for the heavier load of gestation and farrowing housing. C is a closed-edge panel used where the floor meets a wall or pen boundary.
