Block Machine Moulds And The Wear Parts Around Them
Wire cutting, carburising, 54-58 HRC and 100,000 cycles: what mould specifications mean in daily production.
How The Moulds Are Made
Moulds are processed with precision line cutting technology and professional carburising heat treatment. Both raise surface hardness, wear resistance and deformation resistance, which is what keeps block dimensions consistent and reduces material waste as the mould ages.
What The Hardness Figure Means
The QT12-15 specification publishes a mould strength of 54-58 HRC and states the mould can be used more than 100,000 times. That is a planning number: at 2,880 blocks per hour in twelve-block cycles, it tells you roughly when to budget for a replacement rather than waiting for rejects to appear.
The Parts Around The Mould
The wear items on a block line are predictable: vibration box, imported bearings, hydraulic pump and valves, conveyor belt, mixing blades, mould, PLC touch screen, frequency converter and servo motors. All of them are held in stock and supplied at factory cost with fast delivery.
Upgrading Rather Than Replacing
Mould replacement, vibration system reinforcement, automatic batching system conversion and control system upgrades are offered as customised packages, which is usually cheaper than replacing a machine whose frame is still sound.
Machines Referenced In This Guide
QT12-15 Full Automatic Concrete Block Production Line
Largest line in the range: twelve blocks per cycle, 102 kN vibration and 96000 standard bricks per 8 hour shift.
2880 pcs/hour at 400 x 200 x 200
QT4-15 Automatic Concrete Hollow Block Making Machine
Full hydraulic automatic machine producing 5000 to 7000 standard blocks per 8 hour shift from sand, fly ash, slag, gangue or construction waste.
5000-7000 standard blocks per shift
QT6-15 Medium Large Scale Cement Brick Machine
Hydraulic automatic press moulding six hollow blocks per cycle at 40.5 kW, for plants moving into medium large scale output.
1440 pcs/hour at 400 x 200 x 200Questions About This Guide
How do we know when a mould needs replacing?
Are moulds interchangeable between models?
What does a wear parts catalogue include?
Put This Into Practice
Send the block sizes and the output you need, and a machine recommendation with the published capacity table comes back.
