Drum and Disc Brake Cutting Lathe Machine C9350C/C9370C
The C9350C and C9370C skim medium and small brake discs and drums back to a true running surface, which is what removes judder and restores even pad contact without replacing the part. Three spindle speeds are set by moving the belt position, and the spindle feed is infinitely variable with feeding capacity adjustable ...
What This Machine Does
The C9350C and C9370C skim medium and small brake discs and drums back to a true running surface, which is what removes judder and restores even pad contact without replacing the part. Three spindle speeds are set by moving the belt position, and the spindle feed is infinitely variable with feeding capacity adjustable anywhere between 0.05 and 0.5, so a roughing pass and a fine finish cut are both available without changing gears. Feeding is by mechanical transmission, which is what gives the drive its working life in a busy brake shop. The main casting is aluminium alloy, so the whole machine is light for its capacity and can be moved into position in a workshop. Variable speed gears are made from 38CrMoAl alloy steel. The machine comes with moulds and clamps covering cars and light trucks, so it suits a shop that sees many vehicle types rather than one fleet.
Why Buyers Choose This Machine
- Skims discs and drums back to true so judder and uneven pad contact are cured without new parts
- Infinitely variable spindle feed adjustable from 0.05 to 0.5 covers roughing and finishing on one setup
- Three spindle speeds set by belt position so speed matches disc or drum diameter
- Mechanical feeding transmission is built for a long working life in a production brake shop
- Aluminium alloy main casting keeps the whole machine light and movable
- 38CrMoAl alloy steel variable speed gears in the drive train
- Clamps and moulds supplied for cars and light trucks so many vehicle types are covered
Where Drum and Disc Brake Cutting Lathe Machine C9350C Earns Its Place
Problems It Solves
- A scored or warped disc causes judder that no pad change will fix
- Replacing every marked disc and drum is far more expensive than skimming them
- Fixed feed rates force a compromise between cut rate and surface finish
- Machines without a clamp and mould set will not mount the range of hubs a shop sees
- Heavy brake lathes are difficult to reposition in a small workshop
Who It Is For
- Brake and general automotive repair workshops
- Tyre and fast-fit service centres adding brake machining
- Light truck fleet workshops servicing their own brakes
- Distributors supplying vehicle service equipment in export markets
Application Scenarios
- Skimming a brake disc that is causing pedal judder
- Machining a scored brake drum back to a clean bore
- Truing new discs that run out after fitting
- Brake service work across mixed car and light truck models
- Routine brake reconditioning in a general repair workshop
Technical Detail
Technical Features
- Suitable for repairing medium and small brake discs and drums
- Three spindle speeds adjusted by changing belt position
- Infinitely variable spindle feed
- Feeding capacity adjustable from 0.05 to 0.5
- Mechanical feeding transmission
- Aluminium alloy main casting for low machine weight
- 38CrMoAl alloy steel variable speed gears
- Moulds and clamps for cars and light trucks
Specifications
| Machine type | Brake drum and disc cutting lathe |
|---|---|
| Models | C9350C / C9370C |
| Applications | Medium and small brake discs and drums on cars and light trucks |
| Spindle speeds | 3 speeds by belt position |
| Spindle feed | Infinitely variable |
| Feeding capacity | 0.05 - 0.5 adjustable |
| Feed transmission | Mechanical |
| Main casting material | Aluminium alloy |
| Gear material | 38CrMoAl alloy steel |
| Workholding | Moulds and clamps for car and light truck hubs |
Figures above are taken from the product information we hold. Send us your application and we will confirm the exact specification for the model quoted.
How It Is Built and What Can Be Changed
Operations Performed
- Turning
- Disc skimming
- Drum boring
Materials Handled
- Aluminium alloy
- 38CrMoAl alloy steel
Quality Control
- Spindle run-out measured before the machine is released from assembly
- Surface finish checked on a test disc after a finishing pass
- Feed adjustment verified across the 0.05 to 0.5 range
- Belt speed positions checked for correct engagement on all three steps
- Machine run in and a sample disc and drum machined before packing
Customisation Options
- C9350C or C9370C selected from the disc and drum sizes you work on
- Clamp and adaptor set specified for the hub types in your market
- Cutting tip package supplied with the machine
- Supply voltage and frequency set for your market
- Manual prepared in your working language
How It Compares With the Alternatives
| Brake drum and disc lathe machine T8445 / T8465 | The T8465 uses a twin perpendicular spindle layout for work from mini cars up to heavy trucks; the C9350C and C9370C are the lighter machines for medium and small discs and drums |
|---|---|
| Replacing discs and drums | Skimming restores a true surface on a part that still has material left, which is a fraction of the cost of new discs on every brake job |
| On-car brake lathes | An on-car lathe avoids removing the hub but this bench machine gives three spindle speeds and a full 0.05 to 0.5 feed range for both roughing and finishing |
Running the Machine
Step 1
Check the disc or drum thickness against its service limit before machining
Step 2
Mount the part with the correct clamp and mould for the hub type
Step 3
Set the spindle speed by moving the belt to one of the three positions
Step 4
Set a coarse feed within the 0.05 to 0.5 range for the first pass
Step 5
Take a light cut and confirm the tool is picking up across the whole surface
Step 6
Reduce the feed for the finishing pass
Step 7
Measure the finished thickness and deburr before refitting
