Ton Bag Filling And Discharge
500 kg to 2000 kg FIBC filling with high-precision sensors and three-stage feeding, plus a matching ton bag discharge station with dust collection.
Every Step From Design To After Sales
A line is only as good as its weakest handover. These are the stages we cover, and what we take responsibility for at each one.
Ton bag stations need headroom, a forklift path and a clean discharge route. Published external dimensions on the HNWT2000 are 5200 x 1800 x 3500 mm, designed to the actual application.
Bulk density and flow decide the feeding valve sizing. Three-stage coarse, slow and fine feeding is what holds the weight on a 1000 kg bag.
Bag loop type, spout diameter and liner all affect the hook arrangement and the de-dusting seal. Send us the FIBC specification with the enquiry.
A metering control system of high-precision sensors and high-resolution control instruments, with automatic feeding, measuring, packaging and counting under PLC and touch screen control.
Published accuracy is 0.1% static to OIML class III and 0.2 to 0.3% dynamic. Packing speed is 6 to 20 bags an hour across the 500 to 2000 kg range.
The discharge station handles the other end: 500 to 2000 kg an hour with a 1.5 cubic metre hopper and dust collection included.
Load cells and the pneumatic gate valves are the service items. Both are stocked and both can be diagnosed remotely from the HMI.
Machines That Make It Up
HNWT2000 series ton bag packing machine
It is a metering control system composed of high-precision sensors and high-precision resolution control instruments, with hi...
View machineJumbo Bag Packing Machine
1000kg ton jumbo bag weighing filling packing packaging machine
View machine
Jumbo Bag Unpacking Machin
Ton bag discharge machine Ton bag unpacking machine
View machine
Bucket Lifting Elevator
China Manufacturer Bucket Elevator Ne Plate Chain Bucket Lifting Elevator for Coal, Grain
View machine
Metal Detector
China Manufacturer Enhanced Anti-interference Best Metal Detector For Food Industry
View machineWhat We Commit To
30 Days
Standard machine lead time from order confirmation.
50 Days
Custom line lead time, with production tracking available.
95%
On-time delivery rate from our own production base.
4 Hours
Guaranteed response on a critical stoppage, 24/7.
Where To Go Next
Industry Pages
The same line, described in the language of your own sector, with the duty and the pain points that come with it.
Knowledge Centre
Accuracy, dosing heads, bag types, palletising patterns and commissioning, written by the engineers who do it.
Download Centre
Catalogue, datasheets, specification sheets and the selection checklist we work through with you.
Ton Bag Filling And Discharge FAQ
Questions buyers ask before they order. If yours is not here, message us and an engineer will answer.
What is included in the scope of supply?
Can I buy part of the line now and the rest later?
Who does the installation?
What lead time should I plan for?
How do I start?
Send Us Your Floor Plan
A dimensioned sketch of the space, the product data and the output you need is enough for us to draw the line and quote it.
Send a drawing, a bag sample photo or a video of your current line on WhatsApp or by email — that is usually enough for us to quote.
