PVC Wall Panel & Board
PVC Co-Extruded Panel
Co-extruded PVC panel with a heavier wall and a bonded sealing strip on the joining edge for impact positions.
Co-extruded PVC600×350 mmHard wear skin
Product Overview
The RXP-G panel is the reinforced member of the PVC board family. The wall is drawn at 2.5 mm instead of the usual 2.0 mm, the edge is the R-profile that mates with the rest of the range, and a rubber sealing strip is co-extruded onto the joint so the panel-to-panel line closes tight.
It is specified where a pen face takes direct impact — gates, alley walls, corners on a pig route — and where a sealed joint matters for washdown.
Technical Features
- Co-extruded rigid PVC
- 2.5 mm wall, 1.2 mm rib
- Bonded sealing strip on the joining edge
- R-edge profile with mating fit
- White and grey
- Cut to length
Made by the factory that sells it.
Extruded rigid PVC, produced on our own lines in Ningbo and shipped flat-packed for container export.
Application Scenarios
- Room dividers
- Pen partitions
- Corridor walls
Used In
Key benefits
Why Buyers Specify This Product
Thicker wall where it is hit
2.5 mm wall against the standard 2.0 mm gives the face more to give before it marks.
Sealed joint line
The co-extruded strip closes the panel-to-panel joint so wash water and manure do not sit in the gap.
Two working widths
500 × 35 mm and 600 × 35 mm cover most pen and alley modules without cutting.
Fits the standard profile set
The R-edge mates with the same H-connectors and channel as the rest of the PVC range.
Problems It Solves
Panel joints collect manure
A co-extruded seal closes the joint instead of leaving a shoulder.
Alley walls scuff and crack at pig height
A 2.5 mm wall resists the repeated knock a gateway takes.
Mixed suppliers means mismatched profiles
This panel shares the edge profile of the whole JGM PVC board range.
Who It Is For
- Farms replacing damaged alley and gateway panels
- Builders detailing wash-critical rooms
- Producers who want a sealed joint without applied silicone
One-factory supply
Flooring, penning, feeding, water and climate are made on the same site, so a room can be specified and shipped as one order.
See the turnkey packageSpecifications
Sizes Codes and Materials
Figures below are taken from the JGM product catalogue. Anything we cannot source from it is marked TBC and confirmed with your quotation rather than estimated.
| Item | Specification |
|---|---|
| LW50035RXP-G | 500 × 35 mm, 2.5 mm wall, 1.2 mm rib |
| LW60035RXP-G | 600 × 35 mm, 2.5 mm wall, 1.2 mm rib |
| Edge | R-profile with co-extruded sealing strip |
| Colours | White, grey |
| Material | Rigid PVC |
| Packing | Quantity |
|---|---|
| 500 × 35 mm | 120 pcs per standard pallet, 136 per high pallet · (L+20) × 1030 × 2250 / 2500 mm |
| 600 × 35 mm | 120 pcs per standard pallet, 136 per high pallet · (L+20) × 1230 × 2250 / 2500 mm |
| Lengths over 3 m | Packed to agreement |
Ask for the full size chart and carton-loading data for your order.
Materials and Manufacturing
Extruded rigid PVC. The PVC Co-Extruded Panel is extruded as a continuous profile: rigid PVC compound is fed through a heated screw and drawn through a die that forms both the outer wall and the internal rib pattern in one pass. The profile is then cooled, sized and cut to the length the order calls for, which is why length is a customer dimension rather than a catalogue one.
Customisation Options
- Sizes and sections produced to customer requirement on a full-container order
- Colour matched to your existing equipment where the material allows
- Lengths cut to your room rather than to a catalogue dimension
- OEM and private-label production accepted
- Packing and carton marking to your import requirements
Quality Control
- Wall and rib thickness measured against the profile drawing at set intervals
- Section dimensions checked on cut samples through the run
- Colour consistency checked batch to batch against a retained reference
- Cut lengths measured and squareness checked before palletising
Certifications. We do not publish certification claims we cannot evidence.
Tell us what your market requires and we will confirm in writing what can be supplied for this product.
Comparison
How It Compares With Other JGM Products
| Alternative | When to choose it instead |
|---|---|
| PVC Hollow Board | The plain hollow board is lighter and cheaper where impact is not the issue. |
| PVC Panel (Herringbone Rib) | The herringbone panel is the answer to bending across a wide face; this one is the answer to impact and joint sealing. |
| Pig PP Panel (Colour Range) | A PP panel takes repeated animal contact better still, at a higher price per square metre. |
Use guide
Installing and Running It
Step 1
Use the co-extruded panel on the pig side of an alley or gateway and the plain board elsewhere.
Step 2
Push panels fully home so the sealing strip compresses along the whole joint.
Step 3
Do not cut through the sealing strip when trimming to length — trim from the opposite edge.
Step 4
Check the joint line after the first washdown and reseat any panel that has not closed.
Answers
PVC Co-Extruded Panel FAQs
What does the -G suffix mean?
It marks the version with the co-extruded rubber sealing strip on the joining edge.
How much stronger is the 2.5 mm wall?
It is 25% thicker than the standard 2.0 mm board, which is the difference that matters at pig height in an alley or gateway.
Can I mix it with the standard boards?
Yes. The R-edge profile mates with the rest of the PVC board range, so you can use the co-extruded panel only where it is needed.
Are longer lengths available?
Lengths over 3 m are produced and packed by agreement — send the run length with your enquiry.
