PVC Corner Post
Corner and junction posts that tie panels together wherever a pen changes direction.
PVC extrusion4-way postPen junction
Product Overview
A pen layout is a grid of junctions: corners, T-junctions where a division meets a wall, and crossings where four pens meet at a point. Each needs a post with the right number of panel slots, and improvising one from a square tube and two channels is how pen runs end up out of square.
JGM produces the full set — one, two, three and four-way posts in 30 and 35 mm board versions — so every junction in a layout has a purpose-made part.
Technical Features
- Extruded rigid PVC
- One-way post 30/35: 35 × 100 × 35 × 4 and 30.5 × 100 × 35 × 4 mm
- Two-way post: 30.5 × 79 × 4 and 36 × 84 × 4 mm
- Three-way post: 30.5 × 119 × 79 × 4 and 36 × 125 × 85 × 4 mm
- Four-way post 35: 36 × 124 × 4 mm
- White and grey
Made by the factory that sells it.
Extruded rigid PVC, produced on our own lines in Ningbo and shipped flat-packed for container export.
Application Scenarios
- Panel assembly
- Penning systems
Used In
Key benefits
Why Buyers Specify This Product
A post for every junction type
One, two, three and four-way sections cover corners, T-junctions and crossings.
Panels land square
A moulded slot sets the angle instead of relying on site alignment.
30 and 35 mm versions
The post matches the board thickness used in the run.
Ordered with the layout
Posts are counted from the pen drawing, so nothing is missing on site.
Problems It Solves
Pen runs drift out of square
Purpose-made posts set the angle at each junction.
Improvised corners collect dirt
A moulded post has no crevices from site fabrication.
Missing junction parts stop a build
Counting posts from the layout removes the gap.
Who It Is For
- Installers building pen grids from PVC board
- Farms extending an existing penning run
- Builders who want a counted parts list
One-factory supply
Flooring, penning, feeding, water and climate are made on the same site, so a room can be specified and shipped as one order.
See the turnkey packageSpecifications
Sizes Codes and Materials
Figures below are taken from the JGM product catalogue. Anything we cannot source from it is marked TBC and confirmed with your quotation rather than estimated.
| Item | Specification |
|---|---|
| One-way (1-1Z35 / 1-1Z30) | 35 × 100 × 35 × 4 mm and 30.5 × 100 × 35 × 4 mm |
| Two-way (21016 / 21017) | 30.5 × 79 × 4 mm and 36 × 84 × 4 mm |
| Three-way (21014 / 21015) | 30.5 × 119 × 79 × 4 mm and 36 × 125 × 85 × 4 mm |
| Four-way (21023) | 36 × 124 × 4 mm |
| Material | Rigid PVC |
| Colours | White, grey |
| Packing | Quantity |
|---|---|
| Method | Single pack or standard pallet |
| Notes | Cut to height; quantities counted from your pen layout |
Ask for the full size chart and carton-loading data for your order.
Materials and Manufacturing
Extruded rigid PVC. The PVC Corner Post is extruded as a continuous profile: rigid PVC compound is fed through a heated screw and drawn through a die that forms both the outer wall and the internal rib pattern in one pass. The profile is then cooled, sized and cut to the length the order calls for, which is why length is a customer dimension rather than a catalogue one.
Customisation Options
- Sizes and sections produced to customer requirement on a full-container order
- Colour matched to your existing equipment where the material allows
- Lengths cut to your room rather than to a catalogue dimension
- OEM and private-label production accepted
- Packing and carton marking to your import requirements
Quality Control
- Wall and rib thickness measured against the profile drawing at set intervals
- Section dimensions checked on cut samples through the run
- Colour consistency checked batch to batch against a retained reference
- Cut lengths measured and squareness checked before palletising
Certifications. We do not publish certification claims we cannot evidence.
Tell us what your market requires and we will confirm in writing what can be supplied for this product.
Comparison
How It Compares With Other JGM Products
| Alternative | When to choose it instead |
|---|---|
| PVC H-Connector | H-connectors join panels in line; posts join them at an angle. |
| PVC Square Tube | Square tube is for top rails and frame members, not for panel junctions. |
| Partition Panel System | Order the full panel-and-post system where the whole pen layout is being built. |
Use guide
Installing and Running It
Step 1
Count each junction type off the pen layout before ordering — corners, T-junctions and crossings all take different posts.
Step 2
Match the post to the board thickness, 30 or 35 mm.
Step 3
Set posts plumb and fix at the floor before sliding panels in.
Step 4
Keep a few spare posts on site; a mis-cut post stops a run.
Answers
PVC Corner Post FAQs
What is a four-way post for?
A point where four pens meet, so all four panel runs land in one post rather than in an improvised junction.
Do posts come in 30 and 35 mm?
Yes — the one, two and three-way posts are produced in both board thicknesses; the four-way post is the 35 mm version.
How are they cut to height?
They are supplied cut to the panel height you specify with the order.
Can you count the posts from my drawing?
Yes. Send the pen layout and we will return a counted schedule with the quotation.
