Postal Totes and Trays
Colour coded totes and trays for mail and parcel handling
- MaterialCorrugated polypropylene sheet
- Sheet Thickness2 mm to 12 mm depending on tote size
- Sheet Weight250 g/m² to 2000 g/m²
- StyleTotes and trays in various colours and styles
Send a drawing by WhatsApp or email for a custom size. Samples are free of charge and sent by FedEx UPS or DHL.
Product Overview
Corrugated plastic sheet can be fabricated into postal totes and trays in a variety of colours and styles.
Postal operations sort, move and return the same containers thousands of times, so the container has to survive handling, stack reliably and be easy to identify. Because the tote is cut and fabricated rather than moulded, footprint and height are matched to the sorting equipment already in use.
Key Benefits
Light Weight Rigid Strong and Long-Time Durable
Totes survive repeated sorting and handling cycles.
Waterproof Moisture Resistant with Excellent Weatherability
Yard and vehicle storage does not weaken the tote.
Chemical Resistance Impact Resistance and Fade Resistance
Colour coding stays readable through the life of the tote.
Environmentally Friendly Recycled Use Washable Non-Toxic and Anti-Corrosion
Totes wash between cycles and recycle at end of life.
Easy to Fabricate with Custom-Made Cut Shape
Hand holes, lids and stacking features are cut to your drawing.
Excellent Surface for Paints and Inks
Route codes and depot marks print directly on the tote.
Cost-Efficient and Economical for Any End User
Lower cost per cycle than replacing cartons.
Applications and Fit
Application Scenarios
- Mail sorting totes
- Parcel trays and letter trays
- Depot to depot transport containers
- Returnable delivery containers
Who It Is For
- Postal operators and courier companies
- Fulfilment centres and 3PL providers
- Retail returns processing operations
Problems It Solves
- Cartons fail after a handful of sorting cycles.
- Wet weather ruins paper-based trays in transit.
- Containers that do not stack reliably waste vehicle space.
Technical Data
Specifications
| Material | Corrugated polypropylene sheet |
|---|---|
| Sheet Thickness | 2 mm to 12 mm depending on tote size |
| Sheet Weight | 250 g/m² to 2000 g/m² |
| Style | Totes and trays in various colours and styles |
| Colour | To customer request for route or depot coding |
| Options | Hand holes, lids, dividers and printing |
Technical Features and Materials
Corrugated polypropylene sheet fabricated into totes and trays.
Manufacturing Process
- Raw Material High impact co-polymer polypropylene resin, with anti-static, conductive, UV or flame retardant masterbatch added at the extruder when a modified grade is ordered.
- Extrusion The sheet is extruded on one of six production lines to the ordered thickness and weight per square metre. Printing grade stock is corona treated on both surfaces during extrusion.
- Cutting and Creasing Sheets are cut to the ordered panel size and creased where the part has to fold.
- Fabrication Boxes, totes, trays, sleeves and layer pads are formed by welding, riveting or sealing the edges and corners, and accessories are fitted.
- Inspection and Packing Finished goods are inspected, then packed in plastic shrink film on wooden pallets or to the packing method the customer specifies.
From Enquiry to Delivered Goods
Quality Control
ISO 9001:2000 Quality Management System
Operations run to an ISO 9001:2000 quality management system so that the process meets international standards.
100% Inspection Before Delivery
Quality control is carried out inside our own factory and every product is 100% tested before it is released for delivery.
Extrusion Line Control
Thickness, weight per square metre, flute geometry and colour are set and checked on the extrusion line so each sheet matches the ordered specification.
Fabrication Check
Cut sizes, crease positions, welded corners and sealed edges are checked against the approved sample before packing.
Certifications and Standards
Operations run to an ISO 9001:2000 quality management system. Container resin can be specified as ESD safe or flame retardant meeting UL 94 HB flame retardant grade. Where food contact packing is required, 100% new virgin materials are used. We do not publish certificates we have not been given — ask and we will send what applies to your order.
Customization and Comparison
Customization Options
- OEM and customised orders are welcome. Send the drawing and the requirements of the style you want and we will submit samples for your approval.
- Thickness, weight per square metre, panel size, colour and grade are all set per order.
- Boxes and containers can be produced in different colours, thicknesses and styles to your detailed requirements, including dividers, layer pads and accessories.
- Printing and self-adhesive vinyl application are available on corona treated printing grade stock.
Comparison With Other Options
| Option | What It Means for You |
|---|---|
| Corrugated Plastic Tote | Reusable, washable, waterproof, colour coded, no tooling |
| Cardboard Tray | Lowest unit price, few cycles, fails when wet |
| Injection Moulded Tote | Very durable but needs tooling and fixed geometry |
Use Guide
- Give the footprint your sorting equipment and vehicles already use so the tote drops into the existing system.
- Use colour to code route, depot or service level; the sheet is extruded in the colour you choose.
- Specify hand hole size and position for the handling your staff actually do.
Related Products
Corrugated Plastic ContainersCollapsible Corrugated Plastic BoxesFoldable reusable boxes that return flat and save storage spaceView Details
Corrugated Plastic ContainersAuto Parts Packaging ContainersReusable boxes, containers and bulk boxes without mould costView Details
Corrugated Plastic ContainersAgricultural Packaging ContainersFood-approved reusable boxes for fruit, vegetables and seafoodView Details
Corrugated Plastic SheetPlastic Layer PadSealed-edge divider sheet for stacking glass bottles, cans and containersView Details Related Industry Applications
Related Solutions
Related Articles
FAQ
FAQ About Postal Totes and Trays
Can You Match Our Existing Tote Size
Yes. Totes and trays are fabricated from sheet, so the footprint is made to your requirement.
What Colours Are Available
Corrugated plastic sheet can be fabricated into totes and trays in a variety of colours and styles.
Are They Washable
Yes. They are washable, non-toxic, anti-corrosion and recyclable.
Can They Be Printed
Yes. The surface takes paints and inks easily.
How Do I Get Samples
Samples are free of charge. We send them as soon as possible by FedEx, UPS or DHL international air express.
How Long Does Production Take
From order and payment confirmation it takes 7 to 10 days to arrange production and book shipping space in advance before the goods are ready for shipment.
Get a Quotation for Postal Totes and Trays
Send thickness colour weight per square metre and end use and we quote against that specification
Samples are free of charge and sent by FedEx UPS or DHL · Production 7 to 10 days after order confirmation
