SMC Type Valve Positioner From a China OEM Factory
Built to replace SMC IP8000 and IP8100 series electro pneumatic positioners directly on existing actuator brackets, offering compact IP65 housings, large pressure gauges, split range calibration and remote 4 to 20 mA feedback options without original-brand lead times.
Every Model in This Range
Problems This Range Solves
- A plant needs to replace a damaged SMC IP6000 or IP8000 unit without redesigning mounting brackets or pneumatic tubing
- Field operators cannot clearly see supply or output pressure gauge readings on older compact positioner installations
- Vibration and mechanical shock on the pipeline throw standard valve positioners out of calibration during plant operation
- Remote control systems lack position feedback from rotary valves that only have basic visual pointers fitted
- Sourcing replacement SMC pattern positioners from original channels involves long backorders and unplanned plant downtime
Who Buys It
- Plant instrument technicians replacing worn or damaged IP8000 and IP8100 positioners on process control valves
- Valve and actuator package manufacturers needing SMC pattern electro pneumatic positioners branded under their own nameplate
- EPC contractors sourcing drop-in replacement positioners for skid packages and facility maintenance contracts
- Instrumentation distributors maintaining local replacement stock for industrial facilities using SMC pneumatic valve systems
- Maintenance engineers upgrading older IP6000 installations to IP65 enclosures with improved gauge visibility
Industries
What You Get From This Range
- Directly interchangeable mounting with SMC IP6000 and IP8000 series eliminates bracket modifications in the field
- Enclosure rating of IP65 protects internal electro pneumatic components against water washdown and dusty plant environments
- Simple span adjustment enables half split range control without purchasing specialised electronics or separate control boards
- Rotary IP8100 provides a 4 to 20 mA DC feedback signal for continuous remote valve position detection
- Enlarged pressure gauge diameter and external scale plate make valve position and pressures legible from walkway distance
- Standard models dispatch in 2 to 3 days with project quantities completed in 7 to 10 days
- Backed by an 18 month warranty with direct unit replacement upon photo or video evidence
Typical Applications
- Upgrading an IP6000 positioner on a process line to IP65 sealing while keeping the existing mounting bracket
- Rotary quarter turn valve automation where a 4 to 20 mA DC output is required for PLC monitoring
- High vibration slurry or compressor piping skids that require rugged shock resistant positioner assemblies
- Split range valve applications where two valves sequence operations from a single controller output loop
- Building an OEM valve package that requires custom painted housings in black, blue, yellow or specified corporate colours
Units From This Range Built for Customers
Documents for This Range
Download the datasheet before you order so you can check the signal range, output pressure and mounting against your valve.
SMC Type Valve Positioner Questions
Are IP8000 and IP8100 positioners interchangeable with the older IP6000 series?
Yes. They feature interchangeable mounting with the IP6000 series, so you can bolt them directly onto existing brackets without modifying your setup.
What is the difference between the IP8000 and IP8100 models?
The IP8100 is specifically a rotary type positioner featuring an external scale plate, enlarged pressure gauges and an optional 4 to 20 mA DC remote position detection output.
Can these positioners handle split range operation?
Yes. The IP8000 allows a 1/2 split range calibration through a simple span adjustment on site.
Can we order positioners with our own branding and housing colour?
Yes. We provide OEM and ODM customization including customer logos, nameplates and housing painting in black, blue, yellow or custom colours.
What is your standard lead time for delivery?
Regular quantities normally ship in 2 to 3 days from stock. Large project quantities take 7 to 10 days to dispatch.
How is warranty handled if a unit fails in service?
We provide an 18 month warranty. If a failure occurs, provide photo or video evidence and we ship a replacement unit rather than requiring return for repair.
Tell Us Which Model You Need
Send a photo of the unit you are replacing, or the model number you want quoted. We confirm the match, the price and the lead time before you commit to anything.
