Radial Drilling Machine Z3040x16/2 Z3050x16/2 and ZQ3050x20/2
The /2 series is the same hydraulic radial drill layout with a digital readout added, and that changes how holes are positioned: the arm and head are moved to a displayed coordinate instead of being set from scales and judgement, so a pattern of holes lands where the drawing puts it. The machine brings mechanical elect...
What This Machine Does
The /2 series is the same hydraulic radial drill layout with a digital readout added, and that changes how holes are positioned: the arm and head are moved to a displayed coordinate instead of being set from scales and judgement, so a pattern of holes lands where the drawing puts it. The machine brings mechanical electrical and hydraulic functions together, with clamping of the assemblies and spindle speed changing both done by hydraulic power and all controls grouped on the head stock. The feed range is wide and covers manual power and fine feeds, and the feed can be engaged and disengaged at any point in a stroke, with a feed safety device fitted. Main parts are cut on machining centres, castings are produced on casting equipment to control the quality of the basic parts, and the spindle parts are made from special steel and heat treated for strength and wear life. The result is a machine intended for extensive use rather than occasional hole work.
Why Buyers Choose This Machine
- Digital readout gives accurate hole positioning instead of setting from scales by eye
- Feed can be engaged and disengaged at any point in the stroke without stopping the spindle
- Feed safety device protects the drive when the tool binds
- Hydraulic clamping and speed change keep the operator at the head stock controls
- Wide speed and feed range including manual power feed and fine feeds
- Main parts machined on machining centres so bores and faces stay in alignment
- Spindle parts made from special steel and heat treated for strength and durability
- Castings produced on casting equipment to control the quality of the basic parts
Where Radial Drilling Machine Z3040x16 Earns Its Place
Problems It Solves
- Setting hole position from machine scales leaves cumulative error across a pattern
- Disengaging the feed mid stroke on a plain machine means stopping the spindle
- A drive without a feed safety device breaks tools and gears when the drill binds
- Misaligned bores in a head made on general machines cause heat and wear
- Untreated spindle parts wear quickly under continuous heavy drilling
Who It Is For
- Machine shops drilling to positional tolerance on large parts
- Heavy fabrication and structural workshops
- Machinery and equipment builders
- Subcontract shops whose hole positions are inspected on delivery
- Distributors supplying radial drilling machines with digital readout
Application Scenarios
- Positional hole patterns where the coordinates come straight off a drawing
- Drilling large weldments and plates where repositioning by scale would be slow
- Fine feed finishing passes on thin or delicate sections
- Tapping and reaming after drilling in the same setting
- Production drilling of repeat parts where hole position is inspected
- Heavy continuous drilling in a shop running the machine across full shifts
Technical Detail
Technical Features
- Digital readout for hole positioning
- Combined mechanical electrical and hydraulic functions
- Hydraulic clamping of assemblies and hydraulic spindle speed changing
- All controls centralised on the head stock
- Wide range of speed and feed including manual power feed and fine feeds
- Feed engaged and disengaged at any time
- Feed safety device fitted
- Main parts machined on machining centres
- Castings produced on casting equipment for the basic parts
- Spindle parts made from special steel and heat treated
Specifications
| Machine type | Hydraulic radial drilling machine with digital readout |
|---|---|
| Models | Z3040x16/2 / Z3050x16/2 / ZQ3050x20/2 |
| Positioning | Digital readout |
| Clamping | Hydraulic clamping of assemblies |
| Speed change | Hydraulic |
| Controls | Centralised on the head stock |
| Feed | Wide range with manual power feed and fine feeds; engaged and disengaged at any time |
| Feed protection | Feed safety device |
| Main part manufacture | Machined on machining centres |
| Spindle parts | Special steel heat treated |
| Operations | Drilling counter boring reaming tapping spot facing |
Figures above are taken from the product information we hold. Send us your application and we will confirm the exact specification for the model quoted.
How It Is Built and What Can Be Changed
Operations Performed
- Drilling
- Counter boring
- Reaming
- Tapping
- Spot facing
- Heat treatment
Materials Handled
- Cast iron basic parts
- Special steel spindle parts
Quality Control
- Digital readout calibrated against the machine axes before shipment
- Hydraulic clamping and speed change circuits pressure tested
- Feed engagement and disengagement tested at points through the stroke
- Feed safety device tested under a simulated bind
- Spindle parts checked after heat treatment for hardness and run-out
- Castings inspected before machining and test drilling carried out before packing
Customisation Options
- Model selected from Z3040x16/2 Z3050x16/2 and ZQ3050x20/2 for your drilling diameter and arm reach
- Digital readout display units and axis configuration set for your shop
- Coolant system and work light specified with the machine
- Supply voltage frequency and phase built for your market
- Operating language manual and control plate text prepared for your workshop
How It Compares With the Alternatives
| Radial drilling machines Z3040x16/1 and ZQ3050x20/1 | The /1 machines share the hydraulic clamping and speed change; the /2 series adds the digital readout so hole positions are set to a displayed coordinate |
|---|---|
| Mechanical radial drilling machines Z3032x8/1 and Z3040x8 | The mechanical machines clamp by hand and have no readout; the /2 series is the choice where hole position is inspected and the head moves constantly |
| Marking out and drilling to a punched centre | Centre punching carries the marking error into the hole; the readout positions the spindle from the coordinate itself |
Running the Machine
Step 1
Clamp the workpiece on the base plate and establish a datum corner
Step 2
Zero the digital readout on the datum
Step 3
Move the arm and head to the displayed coordinate for the first hole and clamp hydraulically
Step 4
Select the spindle speed and feed at the head stock controls
Step 5
Engage the feed and drill, disengaging at any point if the cut needs checking
Step 6
Move to the next coordinate on the readout without re-marking the part
Step 7
Leave the feed safety device set rather than overriding it to push a heavier cut
Other Machines in Drilling
Drill Machine DP30013B (1213B) and DP30016B (1216B)
View Machine →
Mechanical Radial Drilling Machine Z3032x8/1 and Z3040x8
View Machine →
Radial Drilling Machine ZQ3040x10/1 Z3040x10 and Z3032x10
View Machine →
Radial Drilling Machine Z3050x12/1 Z3040x13/1 Z3040x10/1 and Z3032x10/1
View Machine →Related Applications and Guides
General Machining Job Shops
Job shops take whatever work comes through the door, which means their equipment has to cover a wide range rather than do one thing perfectly. XAIMC s
Heavy Equipment and Plant Maintenance
Mines quarries plantations and processing plants cannot wait for imported spares. XAIMC supplies the boring gear cutting turning and grinding machines
Radial Drilling Machine vs Bench Drilling Machine
A bench drilling machine brings the work to a fixed spindle, while a radial drilling machine moves the spindle over a heavy stationary workpiece on an
Questions About Radial Drilling Machine Z3040x16
What does the digital readout do?
It displays the spindle position so the arm and head are moved to a coordinate from the drawing instead of being set from the machine scales. That is what keeps a hole pattern accurate across a large part.
Can the feed be stopped mid hole?
Yes. The feed is easily engaged and disengaged at any time, and a feed safety device is fitted to protect the drive.
How are the main parts made?
Main parts are machined on machining centres, castings are produced on casting equipment, and spindle parts are made from special steel and heat treated.
What is the difference between the /1 and /2 series?
The /2 series adds the digital readout. Hydraulic clamping hydraulic speed change and head stock controls are on both.
Which model should I choose?
Z3040x16/2 Z3050x16/2 and ZQ3050x20/2 differ in drilling diameter and arm reach. Send us your largest hole size and the furthest hole from the column and we will confirm the model.
What are the shipping arrangements?
The machines are packed in wooden cases. Send us the model and we will confirm case dimensions net weight gross weight and foundation requirements before shipment.
What are your trade and payment terms?
We quote FOB CFR and CIF. Payment is 30 percent by T/T with the order and 70 percent before shipment, or an irrevocable L/C at sight.
Request a Quote on the Radial Drilling Machine Z3040x16
Send us the work you need it to do, the voltage on your site and the port you ship to. We will come back with the model, the tooling and the lead time.
