Horizontal Bench Type Lathe Machine C0632A
The C0632A is a horizontal small bench type lathe for workshops that need engine-lathe behaviour in a machine that will sit on a bench or a light stand. The bed ways are precision ground and supersonic frequency hardened and the spindle runs in precision roller bearings, so the machine keeps working accuracy where a so...
What This Machine Does
The C0632A is a horizontal small bench type lathe for workshops that need engine-lathe behaviour in a machine that will sit on a bench or a light stand. The bed ways are precision ground and supersonic frequency hardened and the spindle runs in precision roller bearings, so the machine keeps working accuracy where a soft-way bench lathe would wear under the chuck within a year of daily use. Headstock gears are ground and hardened steel and the spindle covers 70 to 2000RPM, wide enough to rough steel and finish small brass and aluminium parts without changing machines. The feed box is sealed against swarf and carries both feed rates and thread cutting positions. Workholding is supplied as a working set rather than a single chuck: three-jaw and four-jaw chucks, face plate, steady rest and follow rest, with a live centre, quick change tool post, taper turning attachment and brake available as options. Under HS classification 8459 it is exported as a metalworking machine tool.
Why Buyers Choose This Machine
- Bench footprint with engine-lathe features so a small shop gets 70-2000RPM turning without floor space for a full machine
- Precision ground and frequency hardened ways keep the carriage true after repeated daily use
- Sealed feed box keeps swarf out of the gears that set feed rate and thread pitch
- Three-jaw four-jaw and face plate supplied together so round irregular and flat work are all covered
- Steady rest and follow rest included for slender shaft work
- Optional taper turning attachment adds tapers without offsetting the tailstock
- Optional quick change tool post cuts setup time on jobs with several tools
Where Horizontal Bench Type Lathe Machine C0632A Earns Its Place
Problems It Solves
- A full engine lathe will not fit or load-bear in a small shop, but hobby-grade bench lathes cannot hold accuracy
- Soft bed ways wear quickly near the chuck and the machine starts turning taper
- Swarf in an open feed box makes feed and thread selection stiff and unreliable
- Round-only workholding cannot take castings or flat off-centre parts
- Offsetting the tailstock for tapers loses the centre setting and has to be reset afterwards
- Slender shafts chatter and bend away from the tool without a steady or follow rest
Who It Is For
- Workshops with limited floor area that still need a capable manual lathe
- Toolrooms and prototype shops making one-off turned parts
- Repair businesses turning replacement components in house
- Training workshops teaching turning threading and taper work
- Importers supplying light engineering shops
Application Scenarios
- Small shaft pin and bush turning in a bench-equipped repair shop
- Boring irregular castings held in the four-jaw chuck
- Face plate work on flat or off-centre components
- Cutting replacement threads on studs and adjusters
- Taper turning with the optional attachment for cone and seat work
- Toolroom and prototype turning alongside larger production machines
Technical Detail
Technical Features
- Precision ground and supersonic frequency hardened bed ways
- Spindle supported on precision roller bearings
- Headstock gears of ground and hardened steel
- Spindle speed range 70-2000RPM
- Sealed feed box with multiple feeds and thread cutting functions
- Three-jaw and four-jaw chucks face plate steady rest and follow rest as standard
- Optional live centre quick change tool post taper turning attachment and brake
- Horizontal bench-type frame for bench or light stand mounting
Specifications
| Machine type | Horizontal small bench type lathe |
|---|---|
| Models | C0632A |
| Spindle speed range | 70-2000RPM |
| Bed ways | Precision ground and supersonic frequency hardened |
| Spindle bearings | Precision roller bearings |
| Headstock gears | Ground and hardened steel |
| Feed box | Sealed with feeds and thread cutting functions |
| Standard accessories | Three-jaw chuck four-jaw chuck face plate steady rest follow rest |
| Optional accessories | Live centre quick change tool post taper turning attachment brake |
| HS classification | 8459 machine tools for drilling boring milling and similar work |
Figures above are taken from the product information we hold. Send us your application and we will confirm the exact specification for the model quoted.
How It Is Built and What Can Be Changed
Operations Performed
- Turning
- Facing
- Boring
- Thread cutting
- Taper turning
- Parting
- Drilling from the tailstock
Quality Control
- Bed ways checked for straightness and hardness after grinding and frequency treatment
- Spindle run-out measured at the nose with the roller bearings preloaded
- Speed range verified from 70 to 2000RPM before assembly is signed off
- Feed box exercised through every feed and thread position
- Trial turning and a thread sample taken on the finished machine before packing
Customisation Options
- Supply voltage frequency and phase built for your market
- Optional live centre quick change tool post taper turning attachment and brake added with the order
- Chuck sizes specified to the work you hold most often
- Manual and machine plates in your working language
- Export packing for sea or air freight
How It Compares With the Alternatives
| Floor-standing engine lathe | The C0632A gives the same hardened ways roller bearing spindle and 70-2000RPM range in a bench-type frame that fits a small shop |
|---|---|
| Hobby-grade bench lathe | Hardened ground ways and a sealed feed box are the difference between a machine that holds size after a year and one that does not |
| Engine Lathe Machine C0630A | Same series and the same spindle range; C0632A is configured as a horizontal bench type machine, so choose it when floor space rather than capacity is the constraint |
| Offsetting the tailstock for tapers | The optional taper turning attachment cuts the taper without disturbing the centre alignment you need for the next job |
Running the Machine
Step 1
Mount the lathe on a rigid bench or stand and level it before the first cut
Step 2
Select the three-jaw for round bar the four-jaw for castings and the face plate for flat work
Step 3
Set the spindle speed within 70-2000RPM to suit diameter and material
Step 4
Choose the feed rate or thread pitch on the sealed feed box and engage the lead screw only for threading
Step 5
Fit the steady rest or follow rest when turning long slender work
Step 6
Use the taper turning attachment rather than offsetting the tailstock when tapers are needed
Step 7
Clean and oil the ways and lead screw at the end of each shift
