LED Lightbox 11
Fascia panels that combine a background colour with raised illuminated wording in one box.
View specification
LED Sign Letters · Other LED Signs
A letter that lights front and back at the same time, with a stainless steel return side, a translucent acrylic front and separate frontlit and backlit LED inside. It is the combination build rather than a choice between the two effects.
A letter that lights front and back at the same time, with a stainless steel return side, a translucent acrylic front and separate frontlit and backlit LED inside. It is the combination build rather than a choice between the two effects.
Best for. Flagship stores that want the face lit for daytime readability and the halo for a night look.
Watch out. Two LED circuits mean two channels of power draw; confirm the transformer capacity on site.
Flagship stores that want the face lit for daytime readability and the halo for a night look. It sits in our hotels restaurants and bars work more often than anywhere else.
Some signs are read from the side of the street rather than from in front of it, and some interiors need a glow rather than a lit letter. Neither is a channel letter problem. These builds are the answers we actually produce, with the longer 7 to 10 day production times stated up front.
Hospitality signage is read at night, at close range, and in rooms whose lighting has already been designed. The sign has to join that lighting scheme rather than fight it. See the export packing and door to door delivery route for how this is specified on a live job.
These points are reproduced from our own production specification for LED Letters signage01. Nothing has been added to them.
| Construction | Fabricated sheet metal, folded and soldered into a closed letter |
|---|---|
| Material | Stainless steel, aluminium alloy, translucent or solid acrylic |
| Face material | Translucent acrylic, standard stock colours or film matched to a brand colour |
| Return material | Stainless steel, aluminium or painted metal |
| Surface finish | Specified per order: polished or brushed stainless, aluminium, or powder coated metal |
| Illumination | Internally illuminated |
| LED module | Built-in high quality waterproof LED, described by our supplier as CE, RoHS and UL approved |
| Transformer | Supplied with the letters |
| Return rim | Metal rim over the acrylic face |
| Fixing method | Back stud |
| Supplied with the order | 1:1 scale mounting template, transformer |
| Environment | Outdoor and indoor use |
| Production time | 5 to 7 days |
| Shipping | DHL or UPS express door to door, approximately 4 to 5 days |
| Payment terms | T/T, Western Union, PayPal |
| Minimum order quantity | None; any order quantity accepted |
TBC means the figure is not stated on our original specification and has not been estimated.
Stainless steel, aluminium alloy, translucent or solid acrylic Finish: specified per order: polished or brushed stainless, aluminium, or powder coated metal.
Fabricated sheet metal, folded and soldered into a closed letter. Artwork in AI, EPS or CDR fixes the geometry before anything is cut.
Joints are dressed before finishing, and illuminated builds are wired and lit before the back is closed. Formal QC documentation is TBC.
The internal LED module is described by our supplier as CE, RoHS and UL approved. Factory level certification is TBC and is not claimed on this site.
Fourteen products that are not channel letters: lightboxes, double-sided projecting flag signs, edge-lit solid acrylic, push-through faces and RGB programmable builds.
The alternative constructions in this catalogue are set out in fabricated or flat cut which construction to use, and the illumination choices in frontlit backlit or edge lit.
Two LED circuits mean two channels of power draw; confirm the transformer capacity on site.
Fascia panels that combine a background colour with raised illuminated wording in one box.
View specification
Directory panels, menu boards and internally lit fascia signs on a tight budget.
View specification
Bars, arcades and entertainment venues that change the colour of the sign through the evening.
View specification
Pharmacies, hotels and street-level shops that need to be seen by pedestrians walking past the facade.
View specificationThe venue is read by people walking along the street rather than standing in front of it, so a flat fascia sign would have been invisible until the customer had already passed.
Buying GuideThe numbers a buyer needs to work backwards from a handover date, and what actually travels in the carton.
DownloadsMaterials, finishes, fixings and lead times in one PDF, plus the full catalogue as a CSV.
Stainless steel, aluminium alloy, translucent or solid acrylic. The construction is fabricated sheet metal, folded and soldered into a closed letter. Surface finish: specified per order: polished or brushed stainless, aluminium, or powder coated metal.
Production runs 5 to 7 days. Add roughly 4 to 5 days for DHL or UPS express door to door, and allow time for artwork approval before production starts.
Fixing is by back stud. The order includes 1:1 scale mounting template, transformer. Set the letters out from the template rather than by eye.
Two LED circuits mean two channels of power draw; confirm the transformer capacity on site.
Yes. There is no minimum order quantity on this catalogue and any order quantity is accepted. Shipping cost per letter falls sharply once several travel in the same carton, so order a full word together where you can.
Send the artwork and the finished letter height and the quotation comes back with the production window and the shipping estimate attached.
