KY2168 26 Key Stainless Steel Side Keypad
KY2168 is an embedded side keypad with 26 stainless steel buttons on a SUS304 panel. The key count sits between a short soft key column and a full alphanumeric pad, which suits terminals that need menu keys plus a numeric group.
Product Overview
KY2168 is an embedded side keypad with 26 stainless steel buttons on a SUS304 panel. The key count sits between a short soft key column and a full alphanumeric pad, which suits terminals that need menu keys plus a numeric group. Layouts are customized and black text can be etched into the keys.
- 26 buttons combine menu selection and numeric entry in one embedded panel
- SUS304 stainless steel construction is rugged against prying and corrosion
- Etched black text resists the wear that removes printed legends
- Embossing gives a raised tactile reference on selected keys
- Customized layouts align the key grid with your fascia and software
Application Scenarios
- Financial equipment combining menu and numeric entry
- Communications equipment operator panels
- Military equipment terminals
- Self service machines in public locations
- Embedded fascia builds with a fixed key column
Who It Is For
- Financial and payment terminal manufacturers
- Communications equipment OEMs
- Self service equipment integrators
Problems It Solves
- Two separate keypads are otherwise needed for menu keys and numbers
- Printed key legends wear away on frequently used terminals
- Plastic keypads are damaged on unattended public equipment
- Fixed catalogue layouts rarely fit a custom fascia
Technical Features
- 26 buttons made of stainless steel
- High quality SUS304 stainless steel side keypad
- Rugged vandal proof and anti-corrosion design
- SUS304 stainless steel keys with black text etching
- Embossing available
- Embedded installation behind the equipment fascia
Specifications
| Buttons | 26 |
|---|---|
| Panel Material | SUS304 stainless steel |
| Key Material | SUS304 stainless steel |
| Marking | Black text etched |
| Surface Option | Embossing available |
| Installation | Embedded device |
Materials
- SUS304 stainless steel panel
- SUS304 stainless steel keys
Manufacturing Process
- SUS304 panel forming
- CNC machining of 26 key openings
- Etching of black text legends
- Embossing where specified on the drawing
- Contact assembly and function verification
Quality Control
- Function test across all 26 key positions
- Etch legibility and alignment inspection
- Panel flatness and key protrusion check
- Anti-corrosion verification of the SUS304 surface
Customisation Options
- Customized layout across the 26 key field
- Etched legend content to your artwork
- Embossed keys for tactile identification
- Panel outline and fixing pattern to your drawing
- Connector and cable specification
How It Compares
| KY-55A01 28 key keypad | KY2168 uses 26 keys for fascias where the longer column will not fit |
|---|---|
| KY-55A02 20 key keypad | Six extra keys allow menu selection and a numeric group on one panel |
| Plastic membrane keypad | Etched SUS304 keys survive vandalism and repeated cleaning |
Use Guide
- Plan the 26 key grid against your fascia and display before tooling
- Install as an embedded device behind the panel
- Approve etched legends at sample stage since marking is permanent
- Request embossing on keys that operators locate by touch
Industries
Questions About This Model
How many buttons does KY2168 have?
26 buttons made of stainless steel.
What material is used?
SUS304 stainless steel for both panel and keys.
Can the layout be changed?
Yes, customized layouts are available.
How are keys marked?
Black text can be etched into the stainless steel keys.
Is embossing offered?
Yes, embossing is available.
What equipment is it used on?
Financial, communications, military and other self service equipment.
Request A Quote On KY2168
Tell us quantity, interface and mounting method. Drawings and panel cutouts are welcome by WhatsApp or email.
