KY-55A01 28 Key Stainless Steel Side Keypad
KY-55A01 is an embedded side keypad with 28 stainless steel buttons on a SUS304 panel. The larger key count suits terminals that present long option lists or need dedicated function keys next to the display.
Product Overview
KY-55A01 is an embedded side keypad with 28 stainless steel buttons on a SUS304 panel. The larger key count suits terminals that present long option lists or need dedicated function keys next to the display. Black text is etched into the keys and embossing can be added where operators work by feel.
- 28 buttons handle longer menu columns and dedicated function keys in one panel
- SUS304 stainless steel keeps the panel serviceable in corrosive and high abuse locations
- Etched legends will not peel like printed overlays on heavily used terminals
- Embossing gives a tactile reference without adding separate key caps
- Customized layouts let you place function keys where your software expects them
Application Scenarios
- Financial equipment with extended menu selections
- Communications equipment operator panels
- Military equipment consoles
- Self service terminals needing dedicated function keys
- Kiosk fascias where keys flank the display on one side
Who It Is For
- Financial terminal manufacturers
- Defence and communications equipment builders
- Self service machine OEMs with complex menu trees
Problems It Solves
- Short key columns force nested menus that slow operators down
- Overlay printed keys become illegible on high traffic machines
- Off the shelf keypads rarely match a custom fascia layout
- Exposed keys on public terminals are targets for damage
Technical Features
- 28 buttons made of stainless steel
- High quality SUS304 stainless steel side keypad construction
- Rugged vandal proof and anti-corrosion design
- SUS304 stainless steel keys with black text etching
- Embossing available as a surface option
- Embedded mounting behind the equipment fascia
Specifications
| Buttons | 28 |
|---|---|
| Panel Material | SUS304 stainless steel |
| Key Material | SUS304 stainless steel |
| Marking | Black text etched |
| Surface Option | Embossing available |
| Installation | Embedded device |
Materials
- SUS304 stainless steel panel
- SUS304 stainless steel keys
Manufacturing Process
- Panel forming from SUS304 sheet
- CNC machining of 28 key openings
- Chemical etching of black text legends
- Optional embossing of key faces
- Contact assembly and electrical verification
Quality Control
- All 28 key positions function tested
- Legend etch inspection against the approved artwork
- Dimensional check of the key field against the fascia drawing
- Corrosion resistance verification on the stainless finish
Customisation Options
- Customized layout across the 28 key field
- Etched legend content and symbol set
- Embossed key faces for tactile location
- Panel outline and fixing pattern to your drawing
- Cable exit position and connector type
How It Compares
| KY-55A02 side keypad | 28 buttons instead of 20 for terminals with longer option lists |
|---|---|
| Membrane overlay keypad | Etched SUS304 keys survive vandalism and cleaning chemicals |
| Generic catalogue keypad | The layout is customized so keys line up with your fascia and software |
Use Guide
- Map your menu structure onto the 28 key field before finalising the layout
- Fit as an embedded device behind the fascia panel
- Confirm etched legends at sample stage because marking is permanent
- Add embossing where operators work without looking at the panel
Industries
Related Products
Questions About This Model
How many buttons does KY-55A01 have?
28 buttons made of stainless steel.
What grade of stainless steel is used?
SUS304 for both the panel and the keys.
Can legends be etched in colour?
Black text can be etched into the SUS304 keys.
Is the layout fixed?
No, customized layouts are available.
What equipment is it designed for?
Financial, communications, military and other self service equipment.
Is embossing possible?
Yes, embossing is available.
