Ingiant 1 air tube pneumatic rotary joint slip ring
This is a rotating unit with the envelope you specify, carrying the circuit count you specify across a continuously rotating joint. Power and signals cross the joint through sliding precious metal contacts, so the moving assembly can turn indefinitely in…
Ingiant at a Glance
This is a rotating unit with the envelope you specify, carrying the circuit count you specify across a continuously rotating joint. Power and signals cross the joint through sliding precious metal contacts, so the moving assembly can turn indefinitely in either direction. On this model sealing is rated IP51 Structural material Aluminum alloy, rated speed is 0~300RPM.
- IP51 Structural material Aluminum alloy
- 0~300RPM
- -20°C~+80°C
What This Model Gives the Machine
Unlimited rotation without cable wind-up
The rotating side keeps its electrical connection through continuous 360° turning, so the machine never has to stop and unwind. Rated speed is 0~300RPM.
Maintenance-free contact system
Precious metal Technical Parameter Number of channels According to customer’s actual requi contact pairs are designed to run without lubrication or servicing for the rated life, so there is nothing to schedule on this axis. Dynamic resistance variation stays <10mΩ.
Built to your installation envelope
The mounting interface, lead exit and connector termination are set against your drawing.
Sealed to IP51 Structural material Aluminum alloy
Housing and seals are matched to the environment so dust, splash or washdown does not reach the contact surfaces.
Backed by a 12 month warranty
12 months from date of sale; free repair or replacement for quality problems not caused by human damage
Engineers Who Specify This Part
Builders of inspection and subsea systems, radar and antenna positioners, filling and packaging lines, gimbals and pan-tilt platforms, and semiconductor and test equipment.
Application scenarios
Three Failures It Removes
Failure 1
Rotation limited to ±180° forces an unwind move into every cycle, and that time is lost on every part the machine makes.
Failure 2
A rotating joint that is not sealed for its environment lets dust or wash water reach the contact surfaces, and the symptom looks like an electrical fault.
Failure 3
Fitting a rotating connector after the mechanical design is frozen usually means cutting into the envelope somewhere it was not planned.
Materials Contacts and Construction
Contact system
Precious metal Technical Parameter Number of channels According to customer’s actual requi rings and brushes, selected for low contact resistance and long wear life.
Insulation
Insulation resistance >500MΩ@500VDC Insulator strength 500VAC@50Hz, 60s, 2mA.
Operating environment
Working temperature -20°C~+80°C. Working humidity <70%. Protection level IP51 Structural material Aluminum alloy.
Full Parameter Table
Values published for this model. Anything in this table can be changed on a customised build.
| Product family | Hybrid Slip Rings |
|---|---|
| Manufacturer | JiuJiang Ingiant Technology Co., Ltd, Jiujiang, Jiangxi, China |
| Standard lead time | 7–15 days |
| Warranty | 12 months from date of sale |
| Rated voltage | 0~440VAC/240VDC |
| Rated current | 2A/5A/10A |
| Rotating speed | 0~300RPM |
| Working temperature | -20°C~+80°C |
| Working humidity | <70% |
| Protection level | IP51 Structural material Aluminum alloy |
| Insulation resistance | >500MΩ@500VDC Insulator strength 500VAC@50Hz, 60s, 2mA |
| Dynamic resistance variation | <10mΩ |
| Electrical contact material | Precious metal Technical Parameter Number of channels According to customer’s actual requi |
How the Unit Is Built and Checked
Machining runs on the in-house CNC centre across roughly 6000 m² of research and production space, and assembly is done by the production team in Jiujiang.
Before despatch each unit is checked for insulation resistance, insulation strength, dynamic resistance variation and functional signal performance, using the test equipment and procedures held under the ISO 9001 and GJB9001C quality systems.
Certifications
- ISO 9001
- GJB9001C
- GB/T 19001-2008 / ISO 9001:2008
What Can Be Changed on This Build
- Circuit count, and the current and voltage rating of each ring
- Body diameter, overall length and mounting interface
- Added channels — Ethernet, USB, HD-SDI, optical fibre, RF coaxial, pneumatic or hydraulic passages
- Sealing grade from IP51 to IP68, and housing material
- Lead length, lead specification, connector termination and outlet direction
- Quality grade S Standard, I Industrial or P Premium against the revolutions expected
Simple customisation 10–20 days. Complex customisation 15–40 days.
How It Compares With the Other Formats
The alternative formats are the capsule, the through bore and the separate rotor and brush assembly. Which one is right depends on whether anything has to pass through the centre of the axis and how much space is left around it.
Fitting and Commissioning
Mount the stator, not the load
Fix the stator to the frame through the flange or the anti-rotation arm and couple the rotor to the rotating part. The slip ring must never be used as a bearing — the machine's own bearing carries the load.
Respect the lead route
Leave a service loop at both ends and keep the bend radius above the cable's own minimum. Most field failures start at a lead that was pulled straight.
Separate power and signal runs
Route the power leads and the signal leads apart from each other after they leave the unit, and ground the shield at one end only.
Commission at low speed
Rated speed is 0~300RPM. Turn the assembly by hand first, check continuity on every circuit, then run up to speed and confirm the signal quality before the machine goes into production.
Related Models
Other models in the same family and nearby sizes.
DHS120-39-2F hybrid slip ring for power, signal and HD-SDI (1080p)…
DHS078-35-2A-1Q Hybrid slip rings combined 35 electrical channels and 1…
DHS099-18-5A-1Q Electric-pneumatic hybrid slip ring 18 channels 5A electric…
DHS055-45-2F-002 Optoelectronic slip ring diameter 55mm 45 channel…
Related Reading
Deepening Global Rotary Connection Market Layout | Jiujiang Ingiant Technology Concludes 2026 Moscow International Packaging & Printing Exhibition, Upcoming Attendance at Top South African Mining Equipment Expo
1. Review of Moscow Packaging & Printing Exhibition From June 16 to 19, 2026, the international packaging and printing industry…
Primary Applications of Slip Rings in Karting
Primary Applications of Slip Rings in Karting The fundamental role of a slip ring is to transmit signals, data, and power…
“Ascend Celestial Peak · Unite Hearts and Minds · Forge Top Talents” — 2025 Jiujiang Ingiant Technology Autumn Outing Chronicles
“Ascend Celestial Peak · Unite Hearts and Minds · Forge Top Talents” — 2025 Jiujiang Ingiant Technology Autumn Outing Chronicles…
About Ingiant
Is IP51 Structural material Aluminum alloy enough for my application?
IP51 Structural material Aluminum alloy is the rating on this build. Tell INGIANT the real exposure — dust, splash, washdown, outdoor weather or immersion — and the sealing grade is set against it, with options available up to IP68.
How long does delivery take?
Standard products ship in 7–15 days. Simple customised products take 10–20 days and complex customised products take 15–40 days. The delivery port is Jiujiang, China Mainland.
Can this model be modified for my machine?
Yes. Send the rotating speed, the installation type and size, the circuit count, the voltage and current per ring, the signal types and their parameters, the operating temperature and the IP requirement, and the unit is redesigned around them.
Get a Price and Lead Time for Ingiant
Tell us the application and the quantity. A standard unit ships in 7–15 days; a modified build comes back with a drawing first.
