Separate Slip Rings With Split Rotor and Brush Assemblies
A separate slip ring supplies the ring stack and the brush block as two independent parts, so the machine builder mounts each one directly on the structure instead of fitting a packaged unit.
All 4 Separate Slip Rings Models
Listed in full, each with its own parameter table.
What This Family Is For
The constraint
Very large diameters, very thin axial space or a rotor that is already part of the machine make a packaged slip ring impossible to install.
How INGIANT answers it
INGIANT supplies the rotor ring assembly and the brush holder separately with the mounting interfaces you specify, so the bearing function stays in the machine and the slip ring only carries current.
Who buys this family
Designers of large rotary tables, turntables, antenna pedestals, wind and process equipment and heavy machinery.
Standard Values Across This Family
These are the catalogue values that appear on most models in this family. Every one of them can be changed on a customised build.
Rotating speed
Catalogue units are rated 0–600 rpm. Lower and higher speed designs are built to order.
Working temperature
-40 °C to +65 °C on standard builds, with wider ranges designed against the application.
Protection level
IP54 as standard, with sealing grades up to IP68 where the environment demands it.
Insulation
Insulation resistance ≥1000 MΩ at 500 VDC, insulation strength 1500 VAC at 50 Hz for 60 s.
Contact system
Precious metal ring and brush pairs with dynamic resistance variation below 10 mΩ.
Lead wire
Colour-coded Teflon insulated tinned stranded flexible wire, 500 mm + 20 mm as standard.
Industries Using Separate Slip Rings
Cranes and Material Handling
Crane superstructures, jibs, grabs and cable reels rotate under heavy load, indoors and outdoors, and everything hanging over people and…
Wind and New Energy
Wind turbines transfer the power generated at the rotating blades to the stationary generator and control systems, and pitch control adds…
Amusement and Exhibition
Carousels, Ferris wheels, VR platforms and rotating exhibition displays all need power, light, sound and signal delivered to a part that…
Articles About Separate Slip Rings
Conductive slip ring used in automatic labeling machine
Facebook Twitter LinkedIn Conductive slip ring used in automatic labeling machine As the name implies, the automatic labeling…
Separate Slip Rings Questions Engineers Ask
Who takes care of the alignment in a separate slip ring?
The machine does. Because the rotor and the brush block are mounted independently, the machine's own bearing sets the running clearance, so state the runout and the axial float in your enquiry.
Why choose a separate assembly instead of a packaged unit?
It suits very large diameters, very thin axial envelopes and machines that already have a suitable bearing, where a packaged housing would add size without adding function.
Can separate assemblies carry signal channels too?
Yes, signal rings can be included, and the contact material and ring spacing are chosen for the signal type.
Need Help Narrowing 4 Models Down to One
Send the rotating speed, the installation size, the circuit count, the voltage and current per ring, the signal types, the temperature range and the IP requirement. You get a model number and a drawing back.
