Mirror Finish Stainless Steel Sheet
A mirror finish is a bright non directional surface polished with a 1000 grit abrasive belt and then buffed. EN 10088-2 classifies it as a 2P surface finish and ASTM A480/A480M as the No.8 finish, both achieved by…
What This Product Is For
A mirror finish is a bright non directional surface polished with a 1000 grit abrasive belt and then buffed. EN 10088-2 classifies it as a 2P surface finish and ASTM A480/A480M as the No.8 finish, both achieved by mechanical polishing with successively finer abrasives. The surface is highly reflective with a high degree of image clarity, and very faint buffing or polishing lines may still be visible on the finished sheet.
Key Benefits
- Non directional finish, so panels can be installed in any orientation without grain matching
- High image clarity for architectural and display work
- Surface roughness can be specified rather than left to the polisher
- Seven grades from 201 through 317L to match the corrosion duty
- Shipped with plastic protective film so the finish survives transport and fit out
Who It Is For
- Architectural metalwork fabricators working to a specified finish standard
- Interior fit out contractors
- Signage and display manufacturers
- Buyers who need EN 2P or ASTM No.8 named on the certificate
Problems It Solves
- Finish disputes when mirror is specified without naming EN 2P or ASTM No.8
- Scratched panels caused by shipping unprotected polished sheet
- Grain matching problems that directional finishes create on site
- Grade mismatch when a decorative finish is needed in a corrosive location
Application Scenarios
- Architectural feature panels and column cladding
- Lift interiors and entrance surrounds
- Display fittings and signage
- Reflector and light diffusing panels
Specifications
Every value below is taken from the published product data. Where a figure is not published it is left out rather than estimated.
| Grade | 201, 304, 304L, 316, 316L, 317, 317L |
|---|---|
| Finish Standard | EN 10088-2 2P, ASTM A480/A480M No.8 |
| Polishing | 1000 grit abrasive belt then buffing |
| Cold Rolled Thickness | 0.3 to 3 mm |
| Hot Rolled Thickness | 3 to 20 mm |
| Width | Up to 2000 mm |
| Length | Up to 6000 mm |
| Standard | ASME, ASTM, EN, GB, DIN, JIS |
| Packing | Plastic protective film |
Technical Features
- Polished by 1000 grit abrasive belt then buffed
- EN 10088-2 2P surface finish and ASTM A480/A480M No.8 surface finish
- Non directional, reflective, with a high degree of image clarity
- Surface roughness can be specified on the order
- Packed with plastic protective film
Materials
- 201, 304, 304L, 316, 316L, 317 and 317L stainless steel
Manufacturing Process
- Cold rolling
- Mechanical polishing
- Buffing
- Film lamination
Quality Control
- Finish compared against the EN 2P and ASTM No.8 reference
- Surface roughness measured where the order specifies a value
- Sheet inspected for residual buffing lines under raking light
- Protective film checked for continuity before packing
Customisation Options
- Surface roughness specified as part of the order
- Seven grades available for the same mirror finish
- Cut to size within the width and length range
Use Guide
- Name EN 10088-2 2P or ASTM A480 No.8 on the order rather than the word mirror alone
- Leave the protective film in place until the installation is complete
- Expect very faint buffing lines to remain visible, as this is normal for a No.8 finish
- Blend any site rework back with successively finer abrasives to match the surrounding surface
How It Compares With the Alternatives
| Hairline finish sheet | Hairline is directional and hides marks, mirror is non directional and reflective but shows fingerprints |
|---|---|
| BA bright annealed finish | BA is produced by annealing in a controlled atmosphere, while No.8 mirror is produced by mechanical polishing and buffing to a higher image clarity |
| No.6 finish | No.6 is a softer satin sheen, No.8 is the fully reflective mirror level |
Related Products
409 Stainless Steel Plate and Sheet
Grade 409 is a thermostable ferritic stainless steel with better oxidation and corrosion resistance than carbon steel. This…
View specifications →
316L Stainless Steel Sheet
Grade 316 is the standard molybdenum bearing austenitic stainless steel, second only to 304 in importance. The molybdenum gives it…
View specifications →
2205 Duplex Stainless Steel Sheet
2205 duplex stainless steel, UNS S32205 and S31803, is a 22 percent chromium, 3 percent molybdenum, 5 to 6 percent nickel and…
View specifications →
Hairline Finish Stainless Steel Sheet
A hairline finish is a directional surface where the metal carries a straight, fine grain running the length of the sheet. The…
View specifications →Mirror Finish Stainless Steel Sheet Questions
How is the mirror finish produced
Which standards describe this finish
Will polishing lines be visible
Which grades can carry the mirror finish
How is the sheet packed
Can the surface roughness be specified
Quote Mirror Finish Stainless Steel Sheet
Send the size, wall or thickness, quantity and destination port. Certificates, packing and lead time are confirmed on the quotation.
